Traditional Square Edge
The verified INS-9282 profile creates the square-edge dovetail style used in Vortex flat-table drawer-component tooling.
Vortex Tool Square-Edge Dovetail Replacement Insert
CA$999.99
In stock
SKU
INS-9282
Product Type
Replacement dovetail profile insert
Tooling System
Vortex Flat Table Dovetail Drawer System
Profile Style
Traditional square-edge dovetail
Compatible Bodies
Vortex 9101 and 9101 1/2
Quantity / Sales Unit
Two required per body · Sold individually
Cutting Material
Solid carbide
Profile Angle
27.4° on official assembly drawing
Service Hardware
67115 retaining screw · 7000W T15 driver
Application
Square-edge dovetail drawer components in flat-table nested-base production
Square-Edge
Dovetail Insert
Square Dovetail Insert
A sold-individually solid-carbide Vortex replacement insert that produces the traditional square-edge dovetail profile in compatible 9101 and 9101 1/2 insert bodies. It supports Vortex flat-table routing systems used to machine nested-base dovetail drawer components.
SquareDovetail Edge Style
Solid CarbideCutting Material
9101 SeriesCompatible Bodies
2Inserts Per Body
Square Dovetail Insert
This solid-carbide replacement insert provides the square-edge cutting profile used by compatible Vortex 9101-series dovetail bodies for flat-table drawer-component production.
Solid CarbideSquare EdgeSold IndividuallySKU INS-9282
Compatible with Vortex 9101 and 9101 1/2 insert bodies, which are sold separately. Two INS-9282 inserts are required for each compatible body, and the complete square-edge system may be paired with Vortex 3115 compression spirals.
Main Product Description
The Vortex Tool INS-9282 is the square-edge replacement insert for the Vortex Flat Table Dovetail Drawer System. Its profile is used to create the traditional square-edge dovetail style in drawer components machined with a compatible flat-table router and nested-base production format.
Vortex manufactures the insert from solid carbide and supplies it individually for service or profile replacement. The INS-9282 fits both the standard 9101 body and the 9101 1/2 body variant, allowing the same square-edge insert profile to be used across the verified body options.
The official Vortex assembly drawing identifies a 27.4-degree profile angle and retaining screw 67115 with a 4.0 mm × 0.7 thread and 0.230-inch length. Correct insert seating, clean contact surfaces, matched hardware, and even tightening are essential before returning the body to production.
Technical Specifications
Square Dovetail Insert · SKU INS-9282
- Vortex Tool
- Replacement Dovetail Profile Insert
- INS-9282
- Flat Table Dovetail Drawer System
- Traditional Square Edge
- Solid Carbide
- Vortex 9101 and 9101 1/2
- 2 Inserts Per Compatible Body
- Sold Individually
- 27.4° on Official Assembly Drawing
- Vortex 67115
- 4.0 mm × 0.7 Thread · 0.230 in Length
- Service Tools: 7000W T15 Torx Driver · T15TH Torque Wrench · Companion Spiral: Vortex 3115 · 1/4 in Compression Spiral · Complete Square Kit: Vortex 7600-KIT
- Compatible with Vortex 9101 and 9101 1/2 insert bodies, which are sold separately. Two INS-9282 inserts are required for each compatible body, and the complete square-edge system may be paired with Vortex 3115 compression spirals.
Best Fit Applications
Square-Edge Dovetail Joints
Nested-Base Drawer Components
Flat-Table Router Production
9101 Body Insert Replacement
7600-KIT System Service
Product Highlights
Dual Body Compatibility
The same replacement insert works with both Vortex 9101 and 9101 1/2 dovetail bodies, which are sold separately.
Solid-Carbide Service Format
Replaceable solid-carbide construction restores the cutting profile without replacing the complete compatible cutter body.
Compatibility & Installation Notes
Insert only; the Vortex 9101 or 9101 1/2 body is sold separately. Two INS-9282 inserts are required per compatible body. Verify that the insert pocket, seating surfaces, Vortex 67115 retaining screws, and T15 service tooling are clean and undamaged. Seat both inserts fully and evenly, follow the correct tightening procedure, and confirm body condition, spindle rotation, toolpath, workholding, material support, operating speed, and the complete dovetail-system setup before machining.
Square-Edge Dovetail Production
Vortex Tool INS-9282 provides the solid-carbide square-edge replacement profile for compatible 9101-series dovetail bodies used in flat-table, nested-base drawer-component production.
Correct body selection, matched insert quantity, clean seating, verified retaining hardware, balanced tightening, companion-tool setup, and an appropriate machining program are essential for consistent dovetail fit and insert service life.
