Vortex Tool Small-Bead Inside Corner Cleaning Replacement Insert, 1/4 in Radius
Small-Bead Inside
Corner Cleaner
A solid-carbide Vortex replacement insert for the 7965 MDF inside-corner cleaning body. The INS-9357 cleans the inside corner of a small-bead MDF door-frame profile with a 1/4-inch radius and is designed to work with the INS-9358 small-bead inside roughing insert in a coordinated multi-pass machining sequence.
Main Product Description
The Vortex Tool INS-9357 is the replacement solid-carbide insert for the Vortex 7965 MDF inside-corner cleaning body. It cleans the inside corner of a small-bead door-frame profile with a verified 1/4-inch radius, allowing the serviceable cutter body to be maintained without replacing the complete tool.
Vortex positions the 7965 corner cleaner within a multiple-pass MDF door workflow. The matching INS-9358 insert first creates the small-bead inside roughing profile, and the INS-9357 then refines the inside corner to help produce the appearance of a square assembled-frame corner. A compatible raised-panel operation can be added to complete the visual effect of a five-piece door.
This listing is for the INS-9357 replacement insert only. The 7965 cutter body and complete INS-9357-KIT are separate products. Correct insert seating, a clean pocket, undamaged Vortex 67115 retaining hardware, and the proper T15 Torx service tool are essential for accurate profile reproduction and reliable production use.
Best Fit Applications
Product Highlights
Verified 1/4-Inch Small-Bead Corner
The INS-9357 restores the small-bead corner-cleaning geometry used by the Vortex 7965 body for the verified 1/4-inch-radius profile.
Dedicated INS-9358 Pairing
The insert is designed to clean the inside corner after the matching INS-9358 small-bead roughing profile has been machined.
Replaceable Carbide Cutting Edge
A serviceable solid-carbide insert restores the active profile without requiring replacement of the complete 7965 cutter body.
Compatibility & Installation Notes
Use the INS-9357 only in the compatible Vortex 7965 corner-cleaning body and only with the matching INS-9358 small-bead inside roughing profile. Clean the insert pocket and seating surfaces, inspect the Vortex 67115 button-head retaining screw, and tighten with the correct T15 Torx driver according to the Vortex service procedure. Do not substitute the large-bead INS-7965 insert or a roughing-profile insert. Confirm body condition, tool balance, spindle rotation, projection, RPM, feed, workholding, and the complete MDF door toolpath before production use.
Restore the 7965 Small-Bead Corner
The Vortex Tool INS-9357 is the dedicated solid-carbide replacement insert for the 7965 MDF inside-corner cleaning body, restoring the verified 1/4-inch-radius small-bead corner profile used after the INS-9358 roughing pass.
Correct body compatibility, matched profile pairing, clean seating, proper retaining-screw condition, and the specified T15 service tooling support accurate corner reproduction and dependable production performance.
