Xtreme Performance Geometry
Series 5600XP builds on Vortex’s established single-edge O-flute design by incorporating Xtreme Performance geometry for compatible plastic-routing applications.
Vortex Tool Single-Edge Xtreme Performance Upcut O-Flute Router Bit for Plastics, 1/8" × 1/4"
CA$999.99
In stock
SKU
5609XP
Product Type
Single-edge Xtreme Performance upcut O-flute spiral router bit
Series
Vortex Tool Series 5600XP
Cutting Geometry
One-flute O-flute · Xtreme Performance geometry · Upcut spiral · Right-hand rotation
Cutting Diameter
1/8 in
Cutting Edge Length
1/4 in
Shank / Overall Length
1/4 in shank · 2 in overall length
Cutting Material
Solid carbide
Material Focus
Compatible hard and soft plastics
Application
CNC plastic routing with upward chip evacuation
Single-Edge XP
Upcut O-Flute
Series 5600XP
A Vortex Tool Series 5600XP single-edge solid-carbide upcut O-flute router bit with a 1/8-inch cutting-edge diameter, 1/4-inch cutting-edge length, 1/4-inch shank, and 2-inch overall length. Its Xtreme Performance geometry is designed for compatible hard and soft plastics where finish quality, chip evacuation, and tool life are important.
1/8 inCutting Diameter
1/4 inCutting Edge Length
1/4 inShank Diameter
1Flute
1-Flute XP Upcut O-Flute
This Series 5600XP solid-carbide router bit combines a single-edge O-flute, Xtreme Performance geometry, and an upcut spiral for routing compatible hard and soft plastics.
Solid CarbideUpcutHard & Soft PlasticsSKU 5609XP
Designed for compatible CNC routers and machining systems using a clean, correctly sized 1/4-inch collet or toolholder. Confirm right-hand spindle rotation, tool projection, RPM, feed, cutting depth, workholding, chip evacuation, and plastic-material suitability before production use.
Main Product Description
The Vortex Tool 5609XP is part of the Series 5600XP single-edge Xtreme Performance O-flute upcut spiral range for plastic machining. Vortex developed this series for compatible hard and soft plastics using XP geometry based on its established single-edge O-flute design.
The single-edge O-flute provides an open chip path, while the upcut spiral directs chips upward and away from the cutting zone. Vortex states that the XP geometry is intended to improve part finish and tool life compared with its existing standard geometry when applied correctly.
The verified 5609XP configuration uses a 1/8-inch cutting-edge diameter, 1/4-inch cutting-edge length, 1/4-inch shank, and 2-inch overall length. Correct collet condition, spindle runout, tool projection, feed rate, RPM, cutting depth, workholding, and chip-removal strategy remain essential to finish quality and tool life.
Technical Specifications
Series 5600XP · SKU 5609XP
- Vortex Tool
- Single-Edge Xtreme Performance Upcut O-Flute Spiral Router Bit
- 5609XP
- 5600XP — Single-Edge Xtreme Performance O-Flute Upcut Spirals
- 1/8 in
- 1/4 in
- 1/4 in
- 2 in
- 1
- Right-Hand
- Solid Carbide
- Cutting Direction: Upcut · Primary Cut Behaviour: Upward Chip Removal with Xtreme Performance O-Flute Geometry
- Material Focus: Compatible Hard and Soft Plastics
- Designed for compatible CNC routers and machining systems using a clean, correctly sized 1/4-inch collet or toolholder. Confirm right-hand spindle rotation, tool projection, RPM, feed, cutting depth, workholding, chip evacuation, and plastic-material suitability before production use.
Best Fit Applications
Hard-Plastic Profile Routing
Soft-Plastic Profile Routing
Plastic Slot and Groove Routing
Compatible Through Cuts
CNC Plastic Component Routing
Product Highlights
Hard and Soft Plastics
Vortex identifies the XP series for compatible hard and soft plastics, with the upcut spiral carrying chips upward from the cutting zone.
Verified Compact Configuration
The 1/8-inch cutting diameter is paired with a 1/4-inch cutting length, 1/4-inch shank, and 2-inch overall length.
Compatibility & Installation Notes
Confirm a clean, undamaged 1/4-inch collet or compatible holder, correct right-hand spindle rotation, adequate shank engagement, safe tool projection, machine RPM limits, feed rate, cutting depth, chip evacuation, workholding, and plastic-material suitability before use. Upcut geometry directs chips upward and can apply lifting force to the workpiece, so fixturing and cutting strategy must securely support the part throughout the operation.
XP Plastic Routing
Vortex Tool 5609XP combines solid-carbide construction, single-edge Xtreme Performance O-flute geometry, and upward chip removal with a verified 1/8-inch cutting diameter and 1/4-inch cutting length for compatible hard- and soft-plastic CNC routing operations.
Correct spindle condition, collet fit, tool projection, feed, RPM, cutting depth, chip evacuation, and workholding are essential to achieving the intended finish and service life.
