Vortex Tool Series 5600A Single-Edge Upcut O-Flute Aluminum Router Bit, 10 mm × 22 mm
Aluminum
Upcut O-Flute
A solid-carbide, single-edge upcut O-flute spiral developed for CNC machining of aluminum sheet, block, and extrusion grades. SKU 5690A combines a 10 mm cutting diameter, 22 mm cutting length, 10 mm shank, 76 mm overall length, and aluminum-specific Series 5600A geometry.
Main Product Description
The Vortex Tool 5690A is the 10 mm model in the Series 5600A single-edge O-flute upcut family for aluminum. Vortex specifies this series for machining most compatible sheet, block, and extrusion grades of aluminum in CNC applications.
Its aluminum-specific O-flute geometry is designed to support finish quality and chip evacuation. The upcut spiral directs chips upward through the routed path, making secure workholding and effective extraction important throughout profiling, pocketing, and slotting operations.
The verified configuration uses a 10 mm cutting-edge diameter, 22 mm cutting-edge length, 10 mm shank, and 76 mm overall length. Correct collet condition, tool projection, entry strategy, spindle speed, feed, chip evacuation, and the selected lubrication or cooling method remain essential for controlled aluminum machining.
Best Fit Applications
Product Highlights
Aluminum-Specific Geometry
Series 5600A geometry is developed to support finish quality and chip evacuation in compatible aluminum sheet, block, and extrusion grades.
Single-Edge O-Flute
The verified single cutting edge uses O-flute geometry for dedicated CNC aluminum-routing applications.
Metric 10 mm Format
The 10 mm cutting diameter and shank are paired with a verified 22 mm cutting length and 76 mm overall length.
Compatibility & Installation Notes
Use a clean, undamaged precision 10 mm collet or compatible holder with adequate shank engagement and minimum practical projection. Confirm that the workpiece is a compatible aluminum grade and verify clearance for the 22 mm cutting length and 76 mm overall length. Upcut geometry can lift inadequately secured material, so use rigid workholding and confirm the programmed entry, spindle speed, feed, chip evacuation, and lubrication or cooling strategy for the machine and alloy. Inspect the cutting edge and shank before use and remove damaged tooling from service.
Dedicated O-Flute Geometry for CNC Aluminum Machining
Vortex Tool 5690A combines solid-carbide construction, a single-edge upcut O-flute, and Series 5600A aluminum geometry in a metric 10 mm cutting configuration.
Correct alloy identification, collet fit, tool projection, workholding, cutting parameters, chip evacuation, and lubrication or cooling strategy are essential for controlled routing of compatible aluminum sheet, block, and extrusions.
