Aluminum-Specific Geometry
Series 5600A geometry is developed for finish quality and chip evacuation across compatible aluminum sheet, block, and extrusion grades.
Vortex Tool Single-Edge Upcut O-Flute Router Bit for Aluminum, 1/8" × 1/2"
CA$999.99
In stock
SKU
5610A
Product Type
Single-edge upcut O-flute spiral router bit for aluminum
Series
Vortex Tool Series 5600A
Cutting Geometry
One-flute O-flute · Upcut spiral · Right-hand rotation
Cutting Diameter
1/8 in
Cutting Edge Length
1/2 in
Shank / Overall Length
1/4 in shank · 2 in overall length
Cutting Material
Solid carbide
Material Focus
Compatible aluminum sheet,block and extrusion grades
Application
CNC aluminum routing with upward chip evacuation
Single-Edge
Aluminum O-Flute
Series 5600A
A Vortex Tool Series 5600A single-edge solid-carbide upcut O-flute router bit with a 1/8-inch cutting-edge diameter, 1/2-inch cutting-edge length, 1/4-inch shank, and 2-inch overall length. The aluminum-specific geometry is developed for finish quality and chip evacuation when machining compatible sheet, block, and extrusion grades on CNC equipment.
1/8 inCutting Diameter
1/2 inCutting Edge Length
1/4 inShank Diameter
1Flute
1-Flute Aluminum O-Flute
This Series 5600A solid-carbide router bit combines single-edge O-flute geometry with an upcut spiral developed for aluminum finish quality and chip evacuation in compatible CNC routing applications.
Solid CarbideUpcutAluminumSKU 5610A
Designed for compatible CNC routers and machining systems using a clean, correctly sized 1/4-inch collet or toolholder. Confirm right-hand spindle rotation, tool projection, RPM, feed, cutting depth, workholding, chip evacuation, and aluminum-grade suitability before production use.
Main Product Description
The Vortex Tool 5610A is part of the Series 5600A single-edge O-flute upcut spiral range for aluminum. Vortex developed this family with specific cutting geometry for finish quality and chip evacuation when machining compatible sheet, block, and extrusion grades of aluminum.
Its single-edge O-flute design provides an open flute area for chip formation and removal, while the upcut spiral directs chips upward and away from the cutting zone. This geometry is intended for CNC aluminum-routing operations where chip clearance, heat management, and a controlled finish depend on correct tooling and process parameters.
The verified 5610A configuration uses a 1/8-inch cutting-edge diameter, 1/2-inch cutting-edge length, 1/4-inch shank, and 2-inch overall length. Correct collet condition, spindle runout, tool projection, feed rate, RPM, cutting depth, workholding, and chip-removal strategy remain essential to finish quality and tool life.
Technical Specifications
Series 5600A · SKU 5610A
- Vortex Tool
- Single-Edge Upcut O-Flute Spiral Router Bit for Aluminum
- 5610A
- 5600A — Single-Edge O-Flute Upcut Spirals for Aluminum
- 1/8 in
- 1/2 in
- 1/4 in
- 2 in
- 1
- Right-Hand
- Solid Carbide
- Cutting Direction: Upcut · Primary Cut Behaviour: Upward Chip Removal with Aluminum-Specific O-Flute Geometry
- Material Focus: Compatible Aluminum Sheet, Block, and Extrusion Grades
- Designed for compatible CNC routers and machining systems using a clean, correctly sized 1/4-inch collet or toolholder. Confirm right-hand spindle rotation, tool projection, RPM, feed, cutting depth, workholding, chip evacuation, and aluminum-grade suitability before production use.
Best Fit Applications
Aluminum Sheet Routing
Aluminum Block Machining
Aluminum Extrusion Routing
Slot and Groove Machining
CNC Contour and Profile Cutting
Product Highlights
Open Single-Edge O-Flute
The one-flute O-flute design provides an open chip path, while the upcut spiral carries aluminum chips upward from the cutting zone.
Verified Compact Configuration
The 1/8-inch cutting diameter is paired with a 1/2-inch cutting length, 1/4-inch shank, and 2-inch overall length.
Compatibility & Installation Notes
Confirm a clean, undamaged 1/4-inch collet or compatible holder, correct right-hand spindle rotation, adequate shank engagement, safe tool projection, machine RPM limits, feed rate, cutting depth, chip evacuation, workholding, and aluminum-grade suitability before use. Upcut geometry directs chips upward and can apply lifting force to the workpiece, so fixturing and cutting strategy must securely support the part throughout the operation.
Aluminum Chip Evacuation
Vortex Tool 5610A combines solid-carbide construction, single-edge O-flute geometry, and upward chip removal with a verified 1/8-inch cutting diameter and 1/2-inch cutting length for compatible CNC aluminum-routing operations.
Correct spindle condition, collet fit, tool projection, feed, RPM, cutting depth, chip evacuation, and workholding are essential to achieving the intended finish and service life.
