Soft-Plastic S Geometry
The verified S suffix identifies O-flute geometry specifically manufactured for cutting compatible softer plastics.
Vortex Tool Single-Edge Upcut O-Flute Router Bit for Softer Plastics, 1/4" × 1-1/4"
CA$999.99
In stock
SKU
5632S
Product Type
Single-edge upcut O-flute spiral router bit
Series
Vortex Tool Series 5600
Variant
S geometry specifically manufactured for softer plastics
Cutting Geometry
One polished O-flute cutting edge · Upcut spiral · Right-hand rotation
Cutting Diameter
1/4 in
Cutting Edge Length
1-1/4 in
Shank / Overall Length
1/4 in shank · 3-1/4 in overall length
Cutting Material
Solid carbide
Application
CNC routing in compatible softer plastics with upward chip removal
Soft-Plastic
Upcut O-Flute
Series 5600
A solid-carbide, single-edge upcut O-flute router bit specifically manufactured for CNC routing in compatible softer plastics. SKU 5632S combines a 1/4-inch cutting diameter, 1-1/4-inch cutting length, 1/4-inch shank, 3-1/4-inch overall length, polished flute, and right-hand rotation.
1/4 inCutting Diameter
1-1/4 inCutting Edge Length
Single EdgeSoft-Plastic O-Flute
UpcutChip Direction
Single-Edge Soft-Plastic O-Flute
The S suffix identifies geometry specifically manufactured for softer plastics. Series 5600 uses a polished O-flute and upward chip removal to support chip formation, reduced cutting heat, and clean routed surfaces without a coating.
Solid CarbideSoft-Plastic GeometrySingle EdgeRight-Hand Rotation
Designed for compatible CNC routers and routing equipment using a precision 1/4-inch collet or holder. Confirm the plastic grade, workholding method, chip extraction, tool projection, and programmed cutting parameters before production.
Main Product Description
The Vortex Tool 5632S is the softer-plastic variant in the Series 5600 single-edge O-flute upcut family. Vortex defines the S suffix as geometry specifically manufactured for cutting softer plastics.
Its polished flute is designed to help chips curl and form more effectively, reduce heat at the cutting edge, and add lubricity without a coating. The upcut spiral moves chips upward through the routed path and can enhance surface finish when the material and machining setup are appropriate.
The verified configuration uses a 1/4-inch cutting-edge diameter, 1-1/4-inch cutting-edge length, 1/4-inch shank, 3-1/4-inch overall length, one cutting edge, and right-hand rotation. Correct collet condition, minimum practical projection, secure workholding, entry strategy, feed, spindle speed, and chip evacuation remain essential for controlled routing.
Technical Specifications
Soft-Plastic Upcut O-Flute · SKU 5632S
- Vortex Tool
- Single-Edge Upcut O-Flute Spiral Router Bit
- 5632S
- Series 5600
- 1/4 in
- 1-1/4 in
- 1/4 in
- 3-1/4 in
- Single Edge / One Flute
- Right Hand
- Solid Carbide
- Variant Suffix: S — Specifically Manufactured for Softer Plastics · Cutting Direction: Upcut · Flute Form: Polished O-Flute for Softer Plastics · Coating: Uncoated · Cut Behaviour: Upward Chip Removal
- Verified Workpiece: Compatible Softer Plastics
- Designed for compatible CNC routers and routing equipment using a precision 1/4-inch collet or holder. Confirm the plastic grade, workholding method, chip extraction, tool projection, and programmed cutting parameters before production.
Best Fit Applications
Softer-Plastic CNC Routing
Extended-Depth Profiling
Groove & Slot Routing
Upward Chip Evacuation
Polished-Flute Cutting
Product Highlights
Polished Single Edge
The polished flute supports chip curling and formation, reduced heat, and added lubricity without a coating.
Extended 1-1/4-Inch Cut
The 1/4-inch cutting diameter and shank are paired with a verified 1-1/4-inch cutting length and 3-1/4-inch overall length.
Compatibility & Installation Notes
Use a clean, undamaged precision 1/4-inch collet or compatible holder with adequate shank engagement and minimum practical projection. Confirm that the workpiece is a compatible softer plastic and verify clearance for the 1-1/4-inch cutting length and 3-1/4-inch overall length. Upcut geometry can lift inadequately secured material, so use rigid workholding and confirm right-hand spindle rotation, entry strategy, spindle speed, feed, and chip evacuation before production. Inspect the polished flute and shank before use and remove damaged tooling from service.
Dedicated O-Flute Geometry for Softer Plastics
Vortex Tool 5632S combines solid-carbide construction, softer-plastic-specific S geometry, a polished single-edge O-flute, right-hand rotation, and upward chip removal.
Correct plastic identification, collet fit, tool projection, workholding, cutting parameters, and chip evacuation are essential for controlled CNC routing and consistent surface quality.
