Vortex Tool Series 5600 Single-Edge Upcut O-Flute Router Bit for Hard Plastics, 5 mm × 16 mm
Hard-Plastic
Upcut O-Flute
A solid-carbide, single-edge upcut O-flute router bit developed for clean CNC routing in compatible hard plastics. SKU 5675 combines a 5 mm cutting diameter, 16 mm cutting length, 6 mm shank, 64 mm overall length, polished flute, and right-hand rotation.
Main Product Description
The Vortex Tool 5675 is the 5 mm metric model in the Series 5600 single-edge O-flute upcut family. Vortex specifies this series for clean cutting in hard plastics where upward chip removal is preferred.
Its polished flute is designed to help chips curl and form more effectively, reduce heat at the cutting edge, and add lubricity without a coating. The upcut spiral evacuates chips upward through the routed path and can enhance the finished bottom surface when the material and machining setup are appropriate.
The verified configuration uses a 5 mm cutting-edge diameter, 16 mm cutting-edge length, 6 mm shank, 64 mm overall length, one cutting edge, and right-hand rotation. Correct collet condition, tool projection, workholding, entry strategy, feed, spindle speed, and chip evacuation remain essential to controlled plastic routing.
Best Fit Applications
Product Highlights
Polished O-Flute
The polished flute supports chip curling and formation while reducing heat and adding lubricity without a coating.
Single-Edge Upcut Design
The single cutting edge directs chips upward and can enhance bottom-surface finish in compatible hard plastics.
Metric 5 mm Format
The 5 mm cutting diameter and 16 mm cutting length are paired with a verified 6 mm shank and 64 mm overall length.
Compatibility & Installation Notes
Use a clean, undamaged precision 6 mm collet or compatible holder with adequate shank engagement and minimum practical projection. Confirm that the workpiece is a compatible hard plastic and verify clearance for the 16 mm cutting length and 64 mm overall length. Upcut geometry can lift inadequately secured material, so use rigid workholding and confirm the programmed rotation, entry strategy, spindle speed, feed, and chip evacuation before production. Inspect the flute and shank before use and remove damaged tooling from service.
Polished O-Flute Control for Hard-Plastic Routing
Vortex Tool 5675 combines solid-carbide construction, a polished single-edge O-flute, right-hand rotation, and upward chip removal in a compact 5 mm cutting configuration.
Correct plastic identification, collet fit, tool projection, workholding, cutting parameters, and chip evacuation are essential for controlled CNC routing and clean bottom-surface results.
