Polished O-Flute
The polished flute supports chip curling and formation while reducing heat and adding lubricity without a coating.
Vortex Tool Single-Edge Upcut O-Flute Router Bit for Hard Plastics, 1/2" × 1-1/4"
CA$999.99
In stock
SKU
5650
Product Type
Single-edge upcut O-flute spiral router bit
Series
Vortex Tool Series 5600
Cutting Geometry
One polished O-flute cutting edge · Upcut spiral · Right-hand rotation
Cutting Diameter
1/2 in
Cutting Edge Length
1-1/4 in
Shank / Overall Length
1/2 in shank · 3-1/2 in overall length
Cutting Material
Solid carbide
Flute Finish
Polished and uncoated
Applications
CNC routing in compatible hard plastics with upward chip removal
Hard-Plastic
Upcut O-Flute
Series 5600
A solid-carbide, single-edge upcut O-flute router bit developed for clean CNC routing in compatible hard plastics. SKU 5650 combines a 1/2-inch cutting diameter, 1-1/4-inch cutting length, 1/2-inch shank, 3-1/2-inch overall length, polished flute, and right-hand rotation.
1/2 inCutting Diameter
1-1/4 inCutting Edge Length
Single EdgeO-Flute Geometry
UpcutChip Direction
Single-Edge O-Flute
Series 5600 uses polished O-flute geometry for clean cuts in hard plastics, with upward chip removal that can support bottom-surface finish and efficient chip evacuation.
Solid CarbideSingle EdgeUpcutRight-Hand Rotation
Designed for compatible CNC routers and routing equipment using a precision 1/2-inch collet or holder. Confirm plastic grade, workholding, chip extraction, tool projection, and programmed cutting parameters before production.
Main Product Description
The Vortex Tool 5650 is the 1/2-inch model in the Series 5600 single-edge O-flute upcut family. Vortex specifies this series for clean cutting in hard plastics where upward chip removal is preferred.
Its polished flute is designed to help chips curl and form more effectively, reduce heat at the cutting edge, and add lubricity without a coating. The upcut spiral evacuates chips upward through the routed path and can enhance the finished bottom surface when the material and machining setup are appropriate.
The verified configuration uses a 1/2-inch cutting-edge diameter, 1-1/4-inch cutting-edge length, 1/2-inch shank, 3-1/2-inch overall length, one cutting edge, and right-hand rotation. Correct collet condition, tool projection, workholding, entry strategy, feed, spindle speed, and chip evacuation remain essential to controlled plastic routing.
Technical Specifications
Hard-Plastic Upcut O-Flute · SKU 5650
- Vortex Tool
- Single-Edge Upcut O-Flute Spiral Router Bit
- 5650
- Series 5600
- 1/2 in
- 1-1/4 in
- 1/2 in
- 3-1/2 in
- Single Edge / One Flute
- Right Hand
- Solid Carbide
- Cutting Direction: Upcut · Flute Form: Polished O-Flute · Coating: Uncoated · Cut Behaviour: Upward Chip Removal and Clean Bottom Finish
- Verified Workpiece: Compatible Hard Plastics
- Designed for compatible CNC routers and routing equipment using a precision 1/2-inch collet or holder. Confirm plastic grade, workholding, chip extraction, tool projection, and programmed cutting parameters before production.
Best Fit Applications
Hard-Plastic CNC Routing
Full-Depth Profiling
Groove & Slot Routing
Upward Chip Evacuation
Clean Bottom-Surface Cuts
Product Highlights
Single-Edge Upcut Design
The single cutting edge directs chips upward and can enhance bottom-surface finish in compatible hard plastics.
Extended 1-1/4-Inch Cut
The 1/2-inch cutting diameter and shank are paired with a verified 1-1/4-inch cutting length and 3-1/2-inch overall length.
Compatibility & Installation Notes
Use a clean, undamaged precision 1/2-inch collet or compatible holder with adequate shank engagement and minimum practical projection. Confirm that the workpiece is a compatible hard plastic and verify clearance for the 1-1/4-inch cutting length and 3-1/2-inch overall length. Upcut geometry can lift inadequately secured material, so use rigid workholding and confirm the programmed rotation, entry strategy, spindle speed, feed, and chip evacuation before production. Inspect the flute and shank before use and remove damaged tooling from service.
Polished O-Flute Control for Hard-Plastic Routing
Vortex Tool 5650 combines solid-carbide construction, a polished single-edge O-flute, right-hand rotation, and upward chip removal in a 1/2-inch cutting configuration.
Correct plastic identification, collet fit, tool projection, workholding, cutting parameters, and chip evacuation are essential for controlled CNC routing and clean bottom-surface results.
