Vortex Tool Series 5600 Single-Edge Upcut O-Flute Router Bit, 1/8 in × 1/2 in
Single-Edge
Upcut O-Flute
A Vortex Tool Series 5600 single-edge solid-carbide upcut O-flute router bit with a 1/8-inch cutting-edge diameter, 1/2-inch cutting-edge length, 1/4-inch shank, and 2-inch overall length. Its polished flute supports chip formation and upward chip removal when routing compatible hard plastics on CNC equipment.
Main Product Description
The Vortex Tool 5610 is part of the Series 5600 single-edge O-flute upcut spiral range for plastic machining. Vortex identifies this family for clean cutting in hard plastics with upward chip removal that can support surface-finish quality.
Its polished single-edge O-flute provides an open flute area that helps chips curl and form, while the upcut spiral directs chips upward and away from the cutting zone. Vortex notes that the polished flute reduces heat and adds lubricity without the use of coatings.
The verified 5610 configuration uses a 1/8-inch cutting-edge diameter, 1/2-inch cutting-edge length, 1/4-inch shank, and 2-inch overall length. Correct collet condition, spindle runout, tool projection, feed rate, RPM, cutting depth, workholding, and chip-removal strategy remain essential to finish quality and tool life.
Best Fit Applications
Product Highlights
Polished O-Flute Geometry
Series 5600 uses a polished single-edge O-flute that supports chip formation, reduced heat, and lubricity without an added coating.
Open Single-Edge O-Flute
The one-flute O-flute design provides an open chip path, while the upcut spiral carries plastic chips upward from the cutting zone.
Verified Compact Configuration
The 1/8-inch cutting diameter is paired with a 1/2-inch cutting length, 1/4-inch shank, and 2-inch overall length.
Compatibility & Installation Notes
Confirm a clean, undamaged 1/4-inch collet or compatible holder, correct right-hand spindle rotation, adequate shank engagement, safe tool projection, machine RPM limits, feed rate, cutting depth, chip evacuation, workholding, and plastic-material suitability before use. Upcut geometry directs chips upward and can apply lifting force to the workpiece, so fixturing and cutting strategy must securely support the part throughout the operation.
Hard-Plastic Chip Evacuation
Vortex Tool 5610 combines solid-carbide construction, polished single-edge O-flute geometry, and upward chip removal with a verified 1/8-inch cutting diameter and 1/2-inch cutting length for compatible hard-plastic CNC routing operations.
Correct spindle condition, collet fit, tool projection, feed, RPM, cutting depth, chip evacuation, and workholding are essential to achieving the intended finish and service life.
