Vortex Tool Series 5600 Single-Edge Upcut O-Flute Router Bit, 1/4 in × 1-1/4 in
Single-Edge
Upcut O-Flute
A Vortex Tool Series 5600 single-edge solid-carbide upcut O-flute router bit with a 1/4-inch cutting-edge diameter, 1-1/4-inch cutting-edge length, 1/4-inch shank, and 3-1/4-inch overall length. The 5632H hard-plastic configuration uses a polished, uncoated flute and upward chip-removal geometry for compatible CNC plastic-routing operations.
Main Product Description
The Vortex Tool 5632H is part of the Series 5600 single-edge O-flute upcut spiral range for plastic routing. Its H designation identifies a geometry specifically manufactured for harder plastics, while the single-edge format provides a large flute area for chip formation and evacuation.
Vortex manufactures the Series 5600 with a polished flute that helps chips curl and form more effectively, reduces frictional heat, and adds lubricity without a coating. The upcut spiral carries chips upward and away from the cut, supporting chip clearance and surface-finish control when the tool is matched to the material and machining conditions.
The verified 5632H configuration uses a 1/4-inch cutting-edge diameter, 1-1/4-inch cutting-edge length, 1/4-inch shank, and 3-1/4-inch overall length. Correct collet condition, spindle runout, tool projection, feed rate, RPM, cutting depth, workholding, and chip-removal strategy remain essential to finish quality and tool life.
Best Fit Applications
Product Highlights
Hard-Plastic H Geometry
The H suffix identifies this Series 5600 configuration as specifically manufactured for cutting harder plastics.
Polished O-Flute
The polished, uncoated flute supports chip formation, lower frictional heat, and lubricity without an applied coating.
Extended 1-1/4-Inch Cut
The 1/4-inch cutting diameter is paired with a verified 1-1/4-inch cutting length, 1/4-inch shank, and 3-1/4-inch overall length.
Compatibility & Installation Notes
Confirm a clean, undamaged 1/4-inch collet or compatible holder, correct right-hand spindle rotation, adequate shank engagement, safe tool projection, machine RPM limits, feed rate, cutting depth, chip evacuation, workholding, and material suitability before use. Upcut geometry directs chips upward and can apply lifting force to the workpiece, so vacuum hold-down, fixturing, and cutting strategy must securely support the part throughout the operation.
Hard-Plastic Chip Control
Vortex Tool 5632H combines single-edge O-flute geometry, a polished flute, and upward chip removal with a verified 1/4-inch cutting diameter and 1-1/4-inch cutting length for compatible hard-plastic routing operations.
Correct spindle condition, collet fit, tool projection, feed, RPM, cutting depth, chip evacuation, and workholding are essential to achieving the intended finish and service life.
