Soft-Plastic S Geometry
The S suffix identifies this Series 5600 configuration as specifically manufactured for cutting softer plastics.
Vortex Tool Single-Edge Upcut O-Flute Router Bit, 1/4" × 3/4"
CA$999.99
In stock
SKU
5630S
Product Type
Single-edge upcut O-flute spiral router bit
Series
Vortex Tool Series 5600
Cutting Geometry
One polished O-flute cutting edge · Upcut spiral · Right-hand rotation
Cutting Diameter
1/4 in
Cutting Edge Length
3/4 in
Shank / Overall Length
1/4 in shank · 2-1/2 in overall length
Cutting Material
Solid carbide
Material Focus
S configuration specifically manufactured for softer plastics
Application
CNC soft-plastic routing with upward chip evacuation
Single-Edge
Upcut O-Flute
Series 5600
A Vortex Tool Series 5600 single-edge solid-carbide upcut O-flute router bit with a 1/4-inch cutting-edge diameter, 3/4-inch cutting-edge length, 1/4-inch shank, and 2-1/2-inch overall length. The 5630S soft-plastic configuration uses a polished, uncoated flute and upward chip-removal geometry for compatible CNC plastic-routing operations.
1/4 inCutting Diameter
3/4 inCutting Edge Length
1/4 inShank Diameter
1Flute
1-Flute Upcut O-Flute
This Series 5600 solid-carbide router bit combines single-edge O-flute geometry with upward chip evacuation. The S suffix identifies the configuration specifically manufactured for cutting softer plastics.
Solid CarbideUpcutSoft PlasticsSKU 5630S
Designed for compatible CNC routers and routing machines using a clean, correctly sized 1/4-inch collet or toolholder. Confirm right-hand spindle rotation, tool projection, RPM, feed, workholding, chip evacuation, and material suitability before production use.
Main Product Description
The Vortex Tool 5630S is part of the Series 5600 single-edge O-flute upcut spiral range for plastic routing. Its S designation identifies a geometry specifically manufactured for softer plastics, while the single-edge format provides a large flute area for chip formation and evacuation.
Vortex manufactures the Series 5600 with a polished flute that helps chips curl and form more effectively, reduces frictional heat, and adds lubricity without a coating. The upcut spiral carries chips upward and away from the cut, supporting chip clearance and surface-finish control when the tool is matched to the material and machining conditions.
The verified 5630S configuration uses a 1/4-inch cutting-edge diameter, 3/4-inch cutting-edge length, 1/4-inch shank, and 2-1/2-inch overall length. Correct collet condition, spindle runout, tool projection, feed rate, RPM, cutting depth, workholding, and chip-removal strategy remain essential to finish quality and tool life.
Technical Specifications
Series 5600 · SKU 5630S
- Vortex Tool
- Single-Edge Upcut O-Flute Spiral Router Bit
- 5630S
- 5600 — Single-Edge O-Flute Upcut Spirals
- 1/4 in
- 3/4 in
- 1/4 in
- 2-1/2 in
- 1
- Right-Hand
- Solid Carbide
- Cutting Direction: Upcut · Material Variant: S — Specifically Manufactured for Softer Plastics · Flute Finish: Polished and Uncoated · Primary Cut Behaviour: Upward Chip Removal in Compatible Soft-Plastic Routing
- Soft-Plastic Sheet Routing · Upward Chip-Evacuation Cuts · Slot and Groove Routing
- Designed for compatible CNC routers and routing machines using a clean, correctly sized 1/4-inch collet or toolholder. Confirm right-hand spindle rotation, tool projection, RPM, feed, workholding, chip evacuation, and material suitability before production use.
Best Fit Applications
Soft-Plastic Sheet Routing
Upward Chip-Evacuation Cuts
Slot and Groove Routing
Contour and Profile Routing
CNC Plastic Component Cutting
Product Highlights
Polished O-Flute
The polished, uncoated flute supports chip formation, lower frictional heat, and lubricity without an applied coating.
Compact 3/4-Inch Cut
The 1/4-inch cutting diameter is paired with a verified 3/4-inch cutting length, 1/4-inch shank, and 2-1/2-inch overall length.
Compatibility & Installation Notes
Confirm a clean, undamaged 1/4-inch collet or compatible holder, correct right-hand spindle rotation, adequate shank engagement, safe tool projection, machine RPM limits, feed rate, cutting depth, chip evacuation, workholding, and material suitability before use. Upcut geometry directs chips upward and can apply lifting force to the workpiece, so vacuum hold-down, fixturing, and cutting strategy must securely support the part throughout the operation.
Soft-Plastic Chip Control
Vortex Tool 5630S combines single-edge O-flute geometry, a polished flute, and upward chip removal with a verified 1/4-inch cutting diameter and 3/4-inch cutting length for compatible soft-plastic routing operations.
Correct spindle condition, collet fit, tool projection, feed, RPM, cutting depth, chip evacuation, and workholding are essential to achieving the intended finish and service life.
