Double-Edge O-Flute Geometry
Two cutting edges reduce chip load per edge and create a stronger cross section than a comparable single-edge configuration.
Vortex Tool Double-Edge Right-Hand Straight O-Flute Router Bit, 1/8" × 5/8", 1/4" Shank – 1/4" Shank
CA$999.99
In stock
SKU
5512
Product Type
Double-edge right-hand straight O-flute router bit
Series
Vortex Tool Series 5500
Cutting Geometry
Two O-flute cutting edges · Straight flute · Right-hand rotation
Cutting Diameter
1/8 in
Cutting Edge Length
5/8 in
Shank / Overall Length
1/4 in shank · 4 in overall length
Cutting Material
Solid carbide
Material Focus
Compatible slightly harder plastics
Manufacturer Note
Not guaranteed against breakage due to extreme cutting-edge length
Double-Edge
Straight O-Flute
Series 5500
A Vortex Tool Series 5500 solid-carbide double-edge straight O-flute router bit with right-hand rotation, a 1/8-inch cutting-edge diameter, 5/8-inch cutting-edge length, 1/4-inch shank, and 4-inch overall length. Its two cutting edges reduce chip load per edge and create a stronger cutting cross section for compatible plastic-routing applications.
1/8 inCutting Diameter
5/8 inCutting Edge Length
1/4 inShank Diameter
2Flutes
2-Flute Straight O-Flute
This Series 5500 solid-carbide router bit combines double-edge O-flute geometry with a straight flute and right-hand rotation. Vortex identifies the two-edge design for reduced chip load per cutting edge, a stronger cross section, and effective performance in compatible, slightly harder plastics.
Solid CarbideStraight FluteRight-HandSKU 5512
Designed for compatible CNC routers and machining systems using standard right-hand spindle rotation and a clean, correctly sized 1/4-inch collet or toolholder. Confirm tool projection, spindle runout, RPM, feed, cutting depth, workholding, and chip evacuation before production use.
Main Product Description
The Vortex Tool 5512 is part of the Series 5500 double-edge O-flute straight range for plastic machining. The verified configuration combines a 1/8-inch cutting diameter, 5/8-inch cutting length, 1/4-inch shank, 4-inch overall length, two cutting edges, a straight flute, and right-hand rotation.
Vortex states that the double-edge O-flute offers the same general cutting characteristics as its single-edge O-flute design while providing two cutting edges that reduce chip load per edge and produce a stronger cross section. The manufacturer notes that this geometry can provide additional tool life in some materials and generally performs better in slightly harder plastics.
The 5512 uses an extended 5/8-inch cutting edge on a 1/8-inch diameter tool with a 4-inch overall length. Vortex marks this configuration as not guaranteed against breakage because of the extreme cutting-edge length, so conservative tool projection, correct spindle direction, minimal runout, controlled cutting depth, suitable feed and RPM, secure workholding, and effective chip evacuation are especially important.
Technical Specifications
Series 5500 · SKU 5512
- Vortex Tool
- Double-Edge Right-Hand Straight O-Flute Router Bit
- 5512
- 5500 — Double-Edge O-Flute Straight
- 1/8 in
- 5/8 in
- 1/4 in
- 4 in
- 2
- Right-Hand
- Solid Carbide
- Cutting Direction: Straight Flute · Manufacturer Limitation: Not Guaranteed Against Breakage Due to Extreme Cutting-Edge Length
- Material Focus: Compatible Slightly Harder Plastics
- Designed for compatible CNC routers and machining systems using standard right-hand spindle rotation and a clean, correctly sized 1/4-inch collet or toolholder. Confirm tool projection, spindle runout, RPM, feed, cutting depth, workholding, and chip evacuation before production use.
Best Fit Applications
Hard-Plastic Profile Routing
Plastic Slot Routing
Plastic Groove Cutting
Extended-Reach Plastic Routing
Right-Hand CNC Plastic Routing
Product Highlights
Extended 5/8-Inch Cutting Edge
The 1/8-inch cutting diameter is paired with a verified 5/8-inch cutting length and 4-inch overall length for extended-reach plastic routing.
Right-Hand Straight-Flute Format
The straight O-flute geometry is supplied in the standard right-hand configuration for compatible CNC routers and programmed toolpaths.
Compatibility & Installation Notes
Use this right-hand tool only in a compatible spindle and programmed cutting direction. Install the 1/4-inch shank in a clean, undamaged collet or holder with adequate engagement and the shortest practical projection. Vortex marks SKU 5512 as not guaranteed against breakage because of its extreme cutting-edge length. Verify spindle runout, machine RPM limits, feed rate, cutting depth, workholding, chip evacuation, dust extraction, and plastic-material suitability before use.
Extended-Reach Straight-Flute Performance
Vortex Tool 5512 combines solid-carbide construction, double-edge O-flute geometry, a straight flute, and right-hand rotation with a 1/8-inch cutting diameter, 5/8-inch cutting length, 1/4-inch shank, and 4-inch overall length for compatible plastic-routing operations.
Because Vortex identifies the cutting edge as an extreme-length configuration, controlled projection, low runout, appropriate feed and RPM, conservative cutting depth, secure workholding, and effective chip evacuation are essential setup priorities.
