Rounded Dovetail Profile
The verified INS-9101 profile creates the rounded-edge dovetail style used in Vortex flat-table drawer-component tooling.
Vortex Tool Round-Edge Dovetail Replacement Insert
CA$999.99
In stock
SKU
INS-9101
Product Type
Replacement dovetail profile insert
Tooling System
Vortex Flat Table Dovetail Drawer System
Profile Style
Rounded-edge dovetail
Compatible Bodies
Vortex 9101 and 9101 1/2
Quantity / Sales Unit
Two required per body · Sold individually
Body-System Shank
3/4 in
Cutting Material
Solid carbide
Service Hardware
67115 retaining screw · 7000W T15 Torx driver
Application
Rounded-edge dovetail drawer components in flat-table nested-base production
Round-Edge
Dovetail Insert
Round Dovetail Insert
A sold-individually solid-carbide Vortex replacement insert that produces the rounded-edge dovetail profile in compatible 9101 and 9101 1/2 insert bodies. It supports Vortex flat-table routing systems used to manufacture nested-base dovetail drawer components.
RoundedDovetail Edge Style
Solid CarbideCutting Material
9101 SeriesCompatible Bodies
2Inserts Per Body
Round Dovetail Insert
This solid-carbide replacement insert supplies the rounded-edge cutting profile used by compatible Vortex 9101-series dovetail bodies for flat-table drawer-component production.
Solid CarbideRounded EdgeSold IndividuallySKU INS-9101
Compatible with Vortex 9101 and 9101 1/2 insert bodies, which are sold separately. Two INS-9101 inserts are required for each compatible body, and complete rounded-edge systems are available in the Vortex 7500 kit family.
Main Product Description
The Vortex Tool INS-9101 is the rounded-edge replacement insert for the Vortex Flat Table Dovetail Drawer System. Its profile is designed for drawer components machined with a compatible flat-table CNC router and nested-base production format.
Vortex manufactures the insert from solid carbide and supplies it individually for service or profile replacement. The INS-9101 fits both the standard 9101 body and the 9101 1/2 body variant, allowing the same rounded-edge insert profile to be used across the verified body options.
The official Vortex system drawing identifies retaining screw 67115 with a 4.0 mm × 0.7 thread and 0.230-inch length. Correct insert seating, clean contact surfaces, matched hardware, and even tightening are essential before returning the cutter body to production.
Technical Specifications
Round Dovetail Insert · SKU INS-9101
- Vortex Tool
- Replacement Dovetail Profile Insert
- INS-9101
- Flat Table Dovetail Drawer System
- Rounded Edge
- Solid Carbide
- Vortex 9101 and 9101 1/2
- 3/4 in
- 2 Inserts Per Compatible Body
- Sold Individually
- Vortex 67115
- 4.0 mm × 0.7 Thread · 0.230 in Length
- Service Tools: 7000W T15 Torx Driver · T15TH Torque Wrench · Companion Spiral: Vortex 3115 · 1/4 in Compression Spiral · Complete Round Kits: Vortex 7500-KIT and 7500-KIT-1/2
- Compatible with Vortex 9101 and 9101 1/2 insert bodies, which are sold separately. Two INS-9101 inserts are required for each compatible body, and complete rounded-edge systems are available in the Vortex 7500 kit family.
Best Fit Applications
Rounded-Edge Dovetail Joints
Nested-Base Drawer Components
Flat-Table CNC Production
9101 Body Insert Replacement
7500-KIT System Service
Product Highlights
Dual Body Compatibility
The same replacement insert works with both Vortex 9101 and 9101 1/2 dovetail bodies, which are sold separately.
Solid-Carbide Service Format
Replaceable solid-carbide construction restores the cutting profile without replacing the complete compatible cutter body.
Compatibility & Installation Notes
Insert only; the Vortex 9101 or 9101 1/2 body is sold separately. Two INS-9101 inserts are required per compatible body. Verify that the insert pockets, seating surfaces, Vortex 67115 retaining screws, and T15 service tooling are clean and undamaged. Seat both inserts fully and evenly, follow the correct tightening procedure, and confirm body condition, spindle rotation, toolpath, workholding, material support, operating speed, and the complete dovetail-system setup before machining.
Rounded-Edge Dovetail Production
Vortex Tool INS-9101 provides the solid-carbide rounded-edge replacement profile for compatible 9101-series dovetail bodies used in flat-table, nested-base drawer-component production.
Correct body selection, matched insert quantity, clean seating, verified retaining hardware, balanced tightening, companion-tool setup, and an appropriate machining program are essential for consistent dovetail fit and insert service life.
