Double-Edge O-Flute Geometry
Two polished O-flute cutting edges provide the verified Series 5800 geometry for harder-plastic CNC routing.
Vortex Tool Double-Edge Upcut O-Flute Router Bit, 1/4" × 3/8"
CA$999.99
In stock
SKU
5830
Product Type
Double-edge upcut O-flute spiral router bit
Series
Vortex Tool Series 5800
Cutting Geometry
Two polished O-flute cutting edges · Upcut spiral
Cutting Diameter
1/4 in
Cutting Edge Length
3/8 in
Shank / Overall Length
1/4 in shank · 2-1/2 in overall length
Cutting Material
Solid carbide
Flute Finish
Polished and uncoated
Applications
CNC routing in harder plastics,acrylic and phenolics
Upcut
O-Flute Spiral
Series 5800
A solid-carbide, double-edge O-flute router bit developed for CNC cutting in harder plastics such as acrylic and phenolics. SKU 5830 combines a 1/4-inch cutting diameter, 3/8-inch cutting length, 1/4-inch shank, 2-1/2-inch overall length, upcut chip direction, and polished flutes.
1/4 inCutting Diameter
3/8 inCutting Edge Length
Double EdgeO-Flute Geometry
UpcutChip Direction
Double-Edge O-Flute
Series 5800 uses polished double-edge O-flute geometry with upward chip removal for smooth CNC routing and effective chip evacuation in compatible harder plastics.
Solid CarbideUpcutPolished FluteSKU 5830
Designed for compatible CNC routers and routing equipment using a precision 1/4-inch collet or holder. Confirm the plastic grade, workholding, chip extraction, programmed entry, and machine parameters before production.
Main Product Description
The Vortex Tool 5830 is the compact 1/4-inch model in the Series 5800 double-edge O-flute upcut family. It is developed for cutting harder plastics, including acrylic and phenolics, at productive CNC feed rates while maintaining a smooth routed finish.
Its polished O-flutes are designed to reduce friction at the cutting edge, help the tool run cooler, and add lubricity without a coating. The upcut spiral directs chips upward, supporting chip removal in properly programmed profiling, pocketing, and slotting operations.
The verified configuration uses a 1/4-inch cutting-edge diameter, 3/8-inch cutting-edge length, 1/4-inch shank, and 2-1/2-inch overall length. Correct collet condition, tool projection, workholding, entry strategy, feed, spindle speed, chip evacuation, and material verification remain essential to cut quality and machine operation.
Technical Specifications
Double-Edge Upcut O-Flute · SKU 5830
- Vortex Tool
- Double-Edge Upcut O-Flute Spiral Router Bit
- 5830
- Series 5800
- 1/4 in
- 3/8 in
- 1/4 in
- 2-1/2 in
- Double Edge / Two Cutting Flutes
- Upcut
- Solid Carbide
- Flute Form: Polished O-Flute · Coating: Uncoated · Primary Machine Type: CNC Routing Applications
- Verified Materials: Harder Plastics, Acrylic, and Phenolics
- Designed for compatible CNC routers and routing equipment using a precision 1/4-inch collet or holder. Confirm the plastic grade, workholding, chip extraction, programmed entry, and machine parameters before production.
Best Fit Applications
Hard-Plastic CNC Routing
Acrylic Cutting
Phenolic Routing
Upcut Chip Evacuation
Short-Depth Profiling
Product Highlights
Upward Chip Removal
The upcut spiral directs chips upward to support evacuation in compatible profiling, pocketing, and slotting toolpaths.
Compact Cutting Configuration
The 1/4-inch diameter and 3/8-inch cutting length are paired with a 1/4-inch shank and compact 2-1/2-inch overall length.
Compatibility & Installation Notes
Use a clean, undamaged precision 1/4-inch collet or compatible holder with adequate shank engagement and minimum practical projection. Confirm that the plastic grade is suitable for the Series 5800 harder-plastic geometry, and verify machine clearance for the 3/8-inch cutting length and 2-1/2-inch overall length. Upcut geometry can lift inadequately secured parts, so confirm workholding, sheet support, entry strategy, feed rate, spindle speed, chip extraction, and toolpath direction before production. Remove the tool from service if its cutting edges or shank are damaged.
Compact O-Flute Cutting for Harder Plastics
Vortex Tool 5830 combines solid-carbide construction, double-edge O-flute geometry, upcut chip direction, and polished uncoated flutes in a compact 1/4-inch cutting configuration.
Correct material selection, collet fit, tool projection, workholding, programmed entry, cutting parameters, and chip evacuation are essential for smooth CNC routing in compatible acrylic, phenolic, and harder-plastic applications.
