Burr-Style Cutting Geometry
The burr cutting form supports controlled trimming and profiling in fiberglass and other reinforced plastic materials.
Royce Ayr Solid Carbide Fiberglass Burr - 1/4" Dia x 3/4" Cut x 1/4" Shank
CA$999.99
Out of stock
SKU
R67-02601B
Product Type
Solid Carbide Fiberglass Burr
Diameter
1/4 in (6.35 mm)
Cutting Edge
3/4 in (19.05 mm)
Shank
1/4 in (6.35 mm)
Overall Length
2-1/2 in (63.5 mm)
Cutting Geometry
Diamond Burr Cut
Construction
Solid Carbide Tooling Category
Application
Fiberglass,Carbon Fiber,Composites,Abrasive Plastics
Solid Carbide Fiberglass
Burr Tool
Fiberglass Burr Tool
Solid-carbide, right-hand burr-style router tool designed for fiberglass and other reinforced plastic materials. Its 1/4-inch cutting diameter, 3/4-inch cutting edge, 1/4-inch shank, and 2-1/2-inch overall length provide a compact format for trimming, profiling, slotting, and edge cleanup.
D=1/4 in6.35 mm Diameter
CE=3/4 in19.05 mm Cutting Edge
Sh=1/4 in6.35 mm Shank
OAL=2-1/2 in63.5 mm Overall Length
Fiberglass Burr Tool
This solid-carbide burr-style tool is intended for routing fiberglass and other reinforced plastics, providing controlled cutting action for trimming and profiling abrasive composite materials.
Solid Carbide / HWBurr GeometryRight-HandSKU R67-02601B
Designed for compatible CNC routers and precision routing systems using an exact 1/4-inch (6.35 mm) collet or approved toolholding assembly.
Main Product Description
The Royce Ayr Solid Carbide Fiberglass Burr Tool R67-02601B is designed for routing fiberglass and other reinforced plastic materials. Its 0.2500-inch cutting diameter and 0.750-inch cutting edge provide a compact configuration for trimming, profiling, slotting, and edge-cleanup operations.
The burr-style cutting form engages reinforced fibers across multiple cutting points, supporting controlled material removal in abrasive composite applications. The tool should be matched to appropriate spindle speed, feed rate, pass depth, workholding, and extraction for the material being machined.
The 0.250-inch shank and 2.500-inch overall length require a compatible precision collet or approved toolholder. Before production, verify collet condition, runout, right-hand spindle rotation, tool projection, machine clearance, workholding, and dust or chip collection.
Technical Specifications
Fiberglass Burr Tool R67-02601B
- Royce Ayr
- Solid Carbide Fiberglass Burr Tool
- R67-02601B
- Fiberglass Burr Tool
- HW / Solid Carbide
- 0.2500 in / 1/4 in (6.35 mm)
- 0.750 in / 3/4 in (19.05 mm)
- 0.250 in / 1/4 in (6.35 mm)
- 2.500 in / 2-1/2 in (63.5 mm)
- Burr Style
- RH / Right Hand
- Fiberglass and Other Reinforced Plastics
- Machine Interface: Compatible CNC Routers and Precision Routing Systems
- Designed for compatible CNC routers and precision routing systems using an exact 1/4-inch (6.35 mm) collet or approved toolholding assembly.
Best Fit Applications
Fiberglass Trimming
Reinforced Plastic Routing
Composite Panel Profiling
Slotting & Edge Cleanup
CNC Production Routing
Product Highlights
Compact Composite-Routing Format
The 1/4-inch diameter, 3/4-inch cutting edge, and 2-1/2-inch overall length suit detailed composite-routing operations.
Precision 1/4-Inch Toolholding
The 1/4-inch shank and right-hand rotation provide clear setup requirements for compatible CNC and precision routing systems.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 1/4-inch (6.35 mm) shank and provides sufficient clearance for the 2-1/2-inch (63.5 mm) overall length. Inspect the collet and nut, minimize unsupported tool projection, verify right-hand rotation and runout, and establish spindle speed, feed rate, depth per pass, workholding, and dust or chip extraction according to the reinforced-plastic material, machine, and approved shop procedures.
Improve Fiberglass Routing Control
The Royce Ayr Solid Carbide Fiberglass Burr Tool R67-02601B provides a solid-carbide solution for routing fiberglass and other reinforced plastic materials. Its 1/4-inch diameter, 3/4-inch cutting edge, 1/4-inch shank, and 2-1/2-inch overall length support trimming, profiling, slotting, and edge-cleanup operations.
Burr-style cutting geometry and precise 1/4-inch toolholding support repeatable composite routing when the tool is correctly installed and operated within suitable machining parameters.
