Extended 3-Inch Cutting Edge
The 3-inch cutting edge and 6-inch overall length provide extended reach for compatible larger-format CNC routing operations.
Royce Ayr Double Flute Compression Router Bit 3/4" (19.05mm)
CA$999.99
Out of stock
SKU
R60-11419
Product Type
Double Flute Compression Router Bit
Series
Double Flute Compression
Cutting Diameter
3/4 in (19.05 mm)
Cutting Edge
3 in (76.2 mm)
Upcut Length
0.890 in (22.61 mm)
Shank
3/4 in (19.05 mm)
Overall Length
6 in (152.4 mm)
Flutes
2
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Laminated,Veneered and Wood-Composite CNC Routing
2-Flute Compression Spiral
Router Bit
Extended Double-Flute Compression
Large-format solid-carbide compression spiral router bit for laminated or veneered wood and wood composites where top and bottom finish is critical. Its 3/4-inch cutting diameter, 3-inch cutting edge, 0.890-inch upcut section, 3/4-inch shank, and 6-inch overall length provide extended reach for compatible CNC routing systems.
D=3/4 in19.05 mm Diameter
CE=3 in76.2 mm Cutting Edge
UC=0.890 in22.606 mm Upcut Length
OAL=6 in152.4 mm Overall Length
Extended Double-Flute Compression
This two-flute solid-carbide tool combines upward and downward shearing action to support clean routing on both faces of compatible laminated, veneered, and wood-composite panels.
Solid Carbide / HW2 FlutesCompression SpiralSKU R60-11419
Designed for compatible CNC routers using a precision 3/4-inch (19.05 mm) collet or approved toolholding system. The 0.890-inch upcut section must be positioned correctly within the material for the intended compression effect.
Main Product Description
The Royce Ayr 2-Flute Compression Spiral Router Bit R60-11419 belongs to Royce Ayr's Double Flute Compression series. It is intended for routing laminated or veneered wood and wood composites when finished top and bottom edges are important.
Its compression geometry combines upward and downward cutting action to prevent chipping on laminated faces. The 0.890-inch (22.606 mm) upcut section must be matched to the material thickness and programmed cut depth so the compression transition remains correctly positioned within the workpiece.
The 0.7500-inch cutting diameter, 3.000-inch cutting edge, 0.750-inch shank, and 6.000-inch overall length require rigid, low-runout toolholding and adequate machine clearance. Before machining, verify collet condition, right-hand rotation, tool projection, spindle speed, feed rate, pass depth, workholding, and chip extraction.
Technical Specifications
Double-Flute Compression R60-11419
- Royce Ayr
- 2-Flute Compression Spiral Router Bit
- R60-11419
- Double Flute Compression
- HW / Solid Carbide
- 0.7500 in / 3/4 in (19.05 mm)
- 3.000 in / 3 in (76.2 mm)
- 0.890 in (22.606 mm)
- 0.750 in / 3/4 in (19.05 mm)
- 6.000 in / 6 in (152.4 mm)
- 2
- Compression Spiral
- Rotation: RH / Right Hand · Coating: None · Material Compatibility: Laminated or Veneered Wood and Wood Composites · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 3/4-inch (19.05 mm) collet or approved toolholding system. The 0.890-inch upcut section must be positioned correctly within the material for the intended compression effect.
Best Fit Applications
Laminated Panel Routing
Veneered Panel Routing
Wood-Composite Machining
Large-Format CNC Routing
Extended-Reach Panel Work
Product Highlights
Heavy 3/4-Inch Shank
The 3/4-inch shank requires compatible industrial CNC toolholding with suitable rigidity, clearance, and low runout.
Verified Compression Zone
The 0.890-inch upcut section must be matched carefully to material thickness and programmed cutting depth.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 3/4-inch (19.05 mm) shank and provides sufficient clearance for the 6-inch (152.4 mm) overall length. Inspect the collet and nut, minimize unsupported projection, verify right-hand rotation and runout, and establish suitable spindle speed, feed rate, pass depth, workholding, and chip extraction. Position the 0.890-inch (22.606 mm) upcut section and compression transition correctly within the material.
Extend Large-Format Compression Routing
The Royce Ayr 2-Flute Compression Spiral Router Bit R60-11419 provides a solid-carbide solution for laminated, veneered, and wood-composite routing where top and bottom finish is critical.
Its 3/4-inch diameter and shank, 3-inch cutting edge, 0.890-inch upcut section, two-flute compression geometry, and 6-inch overall length suit compatible CNC systems when correctly held and operated.
