Two-Sided Edge Control
Upward and downward shearing action helps reduce chipping on the top and bottom faces of compatible panel materials.
Royce Ayr Double Flute Compression Router Bit 1/2" (12.7mm) – Right-Hand – 2-Flute – 1-3/4"
CA$999.99
Out of stock
SKU
R60-11413
Product Type
Double Flute Compression CNC Router Bit
Series
R60-114 Double Flute Compression
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
1-3/4 in (44.45 mm)
Upcut Length
3/4 in (19.05 mm)
Shank
1/2 in (12.7 mm)
Overall Length
4 in (101.6 mm)
Flutes
2
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Laminated,Veneered and Wood-Composite Panel Routing
2-Flute Compression
Spiral Router Bit
Compression Router Bit
A solid-carbide right-hand compression spiral router bit for CNC routing laminated, veneered, and wood-composite panels where clean top and bottom edges are required. Its 1/2-inch cutting diameter and shank, 1-3/4-inch cutting edge, 3/4-inch upcut section, and 4-inch overall length provide a balanced production-routing format.
D=1/2 in12.7 mm Diameter
CE=1-3/4 in44.45 mm Cutting Edge
Up=3/4 in19.05 mm Upcut
OAL=4 in101.6 mm Overall Length
Compression Router Bit
This production tool combines solid-carbide construction, two compression flutes, and right-hand rotation to help control chipping on both faces of compatible laminated, veneered, and composite panels.
Solid Carbide2 FlutesRight-HandSKU R60-11413
Designed for compatible CNC routers using precision 1/2-inch collets or approved toolholding systems. Match the 3/4-inch upcut section and 1-3/4-inch cutting edge to the panel thickness and programmed cutting depth.
Main Product Description
The Royce Ayr 2-Flute Compression Spiral Router Bit R60-11413 is designed for CNC routing laminated panels, veneered wood products, and compatible wood-composite materials. Its compression geometry combines upward and downward shearing action to help reduce chipping on both faces of the workpiece.
The tool features a 0.5000-inch cutting diameter, 1.750-inch cutting edge, 0.750-inch upcut section, 0.500-inch shank, two flutes, right-hand rotation, no coating, and a 4.000-inch overall length. This configuration offers a balanced combination of cutting reach, rigidity, and edge control for compatible cabinet, millwork, and panel-processing applications.
The 3/4-inch upcut section must be positioned correctly for the material thickness and programmed depth so the compression transition engages the workpiece as intended. Correct collet condition, tool projection, spindle speed, feed rate, pass strategy, hold-down, chip evacuation, and dust extraction remain essential for maintaining finish quality and tool life.
Technical Specifications
Compression Router Bit R60-11413
- Royce Ayr
- 2-Flute Compression Spiral Router Bit
- R60-11413
- R60-114 Double-Flute Compression
- 0.5000 in / 1/2 in (12.7 mm)
- 1.750 in / 1-3/4 in (44.45 mm)
- 0.750 in / 3/4 in (19.05 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 4.000 in / 4 in (101.6 mm)
- 2
- RH / Right Hand
- None
- Material: HW / Solid Carbide Tooling · Material Compatibility: Laminated Wood, Veneered Wood, and Wood Composites · Machine Interface: CNC Routers with Compatible 1/2-Inch Collets or Toolholders · Application: Panel Routing Where Top and Bottom Finish Is Critical · Country of Origin: Not Specified by Source
- Designed for compatible CNC routers using precision 1/2-inch collets or approved toolholding systems. Match the 3/4-inch upcut section and 1-3/4-inch cutting edge to the panel thickness and programmed cutting depth.
Best Fit Applications
Laminated Panel Routing
Veneered Wood Routing
Wood-Composite Machining
Cabinet & Casework Processing
Millwork Component Routing
Product Highlights
Balanced Cutting Reach
The 1-3/4-inch cutting edge supports compatible panel-routing applications requiring additional cutting depth.
Verified Upcut Section
The 3/4-inch upcut section should be matched carefully to panel thickness and programmed cutting depth.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 1/2-inch (12.7 mm) shank. Verify right-hand rotation, tool projection, runout, available clearance, guarding, dust extraction, hold-down, RPM, feed rate, pass strategy, and material thickness before machining. Position the 3/4-inch upcut section and remaining downcut geometry correctly for the intended through-cut, profile, or routing operation.
Balanced Two-Sided Panel Routing
The Royce Ayr 2-Flute Compression Spiral Router Bit R60-11413 provides a solid-carbide solution for CNC routing laminated, veneered, and composite panels where clean top and bottom edge quality is required. Its 1/2-inch diameter and shank, 1-3/4-inch cutting edge, 3/4-inch upcut section, and 4-inch overall length support balanced production-routing applications.
Two-flute compression geometry and right-hand rotation support controlled panel machining when the tool is correctly held, positioned through the material, and operated within suitable machining parameters.
