Compression Edge Control
Upward and downward shearing action helps reduce chipping on both faces of compatible laminated and veneered panels.
Royce Ayr 2 Flute Compression Spiral Ultimax Router Bit 1/2" (12.7mm)
CA$999.99
Out of stock
SKU
R60-11402UM
Product Type
2 Flute Compression Spiral Ultimax Router Bit
Series
R60-114 Compression 2 Flutes
Cutting Diameter
1/2 in (12.7 mm)
Cutting Edge
7/8 in (22.23 mm)
Upcut Length
1/2 in (12.7 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3 in (76.2 mm)
Flutes
2
Construction
Solid Carbide Router Bit
Coating
Ultimax / UM
Application
Laminated,Veneered and Wood Composite Panel Routing
2-Flute
Ultimax
Compression Spiral Bit
A 1/2-inch (12.7 mm) Ultimax-coated, solid-carbide compression spiral router bit for CNC routing laminated or veneered wood and wood composites where clean top and bottom edges are required.
D=1/2 in12.7 mm Diameter
CE=7/8 in22.23 mm Cutting Edge
Sh=1/2 in12.7 mm Shank
OAL=3 in76.2 mm Overall Length
Ultimax Compression Spiral Bit
This coated compression tool combines upward and downward shearing action to help control chipping on both faces of laminated, veneered, and compatible wood-composite panels.
Solid Carbide2 FlutesUltimax / UMSKU R60-11402UM
Designed for compatible CNC routers using precision 1/2-inch collets or approved toolholding systems for nested-routing and panel-processing applications.
Main Product Description
The Royce Ayr 2-Flute Ultimax Compression Spiral Router Bit R60-11402UM is designed for CNC routing laminated or veneered wood and wood-composite panels where clean top and bottom edges are required. Its compression geometry combines upward and downward shearing action to help reduce chipping on both panel faces.
The Ultimax / UM coating is identified for reducing friction, increasing edge hardness, improving coating adhesion, and supporting tool life in nested-routing applications. Solid-carbide construction provides a rigid cutting body for repeatable panel-processing work.
The tool has a 0.500-inch cutting diameter, 0.875-inch cutting edge, 0.500-inch upcut length, 0.500-inch shank, and 3.000-inch overall length. Correct collet condition, tool projection, spindle speed, feed rate, pass depth, and material hold-down are essential for maintaining edge quality and service life.
Technical Specifications
Ultimax Compression Bit R60-11402UM
- Royce Ayr
- 2-Flute Ultimax Compression Spiral Router Bit
- R60-11402UM
- R60-114 Compression 2 Flutes
- Solid Carbide / Precision CNC Tooling
- 0.500 in / 1/2 in (12.7 mm)
- 0.875 in / 7/8 in (22.23 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 3.000 in / 3 in (76.2 mm)
- 2
- Not Specified by Supplied Source
- Solid Carbide Router Bit · Compression Spiral with Upward and Downward Shearing Action · Ultimax / UM Coating
- Laminated Wood, Veneered Wood, Plywood, and Wood Composites
- Compatible CNC Routers Using 1/2-Inch Collets
Best Fit Applications
Laminated Panel Routing
Veneered Panel Routing
Nested-Based Manufacturing
Plywood & Composite Processing
Cabinet & Millwork Production
Product Highlights
Ultimax Coating
The UM coating is identified for reduced friction, increased edge hardness, improved adhesion, and extended service life in nested-routing work.
Compact 1/2-Inch Format
The 1/2-inch diameter and shank, 7/8-inch cutting edge, and 3-inch overall length suit compatible compact panel-routing operations.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, nut, and toolholder accept an exact 1/2-inch (12.7 mm) shank. Inspect toolholding components for wear or contamination, minimize unsupported tool projection, and verify runout before machining. Establish spindle speed, feed rate, cutting depth, ramp strategy, and hold-down according to the actual panel construction and machine capability.
Improve Two-Sided Panel Edge Quality
The Royce Ayr 2-Flute Ultimax Compression Spiral Router Bit R60-11402UM provides a coated solid-carbide solution for laminated, veneered, plywood, and wood-composite panel production. Its compression geometry is designed to support clean top and bottom edges in compatible CNC routing applications.
The 1/2-inch diameter, 7/8-inch cutting edge, 1/2-inch upcut section, 1/2-inch shank, and 3-inch overall length create a compact configuration for nested-routing and cabinet-component machining when the tool is correctly held and operated within suitable parameters.
