Compression Edge Quality
The compression geometry combines upward and downward shearing action to help reduce chipping on laminated surfaces where both panel faces matter.
Royce Ayr 2 Flute Chipbreaker Compression Router Bit 5/8" (15.88mm)
CA$999.99
Out of stock
SKU
R60-11007
Product Type
2 Flute Chipbreaker Compression Router Bit
Series
R60-110 Chipbreaker Compression
Cutting Diameter
5/8 in (15.88 mm)
Cutting Edge
2-1/4 in (57.15 mm)
Upcut Length
0.990 in (25.15 mm)
Shank
5/8 in (15.88 mm)
Overall Length
5 in (127 mm)
Flutes
2
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Laminated,Veneered,Plywood and Wood Composite Panels
2-Flute
Chipbreaker Compression
Router Bit
A larger-diameter solid-carbide, right-hand chipbreaker compression CNC router bit designed for laminated or veneered wood and wood composites where controlled top and bottom edge quality is critical.
D=5/8 in15.88 mm Diameter
CE=2-1/4 in57.15 mm Cutting Edge
Upcut=0.990 in25.15 mm Upcut Length
OAL=5 in127 mm Overall Length
Chipbreaker Compression Router Bit
This larger-diameter production tool combines compression cutting action with chipbreaker geometry to support controlled top and bottom edge quality in laminated, veneered, plywood, and compatible composite panel materials.
Solid Carbide2 FlutesRight-HandSKU R60-11007
Designed for compatible CNC routers using precision 5/8-inch collets or approved toolholding systems for cabinet, casegoods, and panel-processing production.
Main Product Description
The Royce Ayr R60-11007 is a 2-flute chipbreaker compression router bit from the Royce Ayr solid carbide CNC tooling range. It is designed for routing laminated or veneered wood and wood composites when both the top and bottom finish matter.
The compression geometry combines upward and downward shearing action to help reduce chipping on laminated surfaces, while the chipbreaker design helps prevent furring or tearout in plywood core material. This makes the tool a strong fit for cabinet shops, casegoods manufacturers, and CNC departments cutting laminated panels, veneered panels, plywood, and composite sheet goods.
With a 5/8 in (15.88 mm) cutting diameter, 2-1/4 in (57.15 mm) cutting edge, 0.990 in (25.15 mm) upcut length, 5/8 in (15.88 mm) shank, and 5 in (127 mm) overall length, this tool is suited to CNC routing work where a larger-diameter compression bit is required for panel processing, cabinet parts, casegoods components, and laminated sheet goods.
Technical Specifications
Chipbreaker Compression R60-11007
- Royce Ayr
- 2-Flute Chipbreaker Compression Router Bit
- R60-11007
- R60-110 Chipbreaker Compression
- Precision CNC Tooling / Solid Carbide Tooling
- 0.6250 in / 5/8 in (15.88 mm)
- 2.250 in / 2-1/4 in (57.15 mm)
- 0.625 in / 5/8 in (15.88 mm)
- 5.000 in / 5 in (127 mm)
- 2
- RH / Right Hand
- HW / Solid Carbide · Uncoated
- Panel Routing Where Top and Bottom Edge Quality Is Critical
- CNC Router
Best Fit Applications
Laminated Panel Routing
Veneered Panel Routing
Plywood Core Machining
Cabinet & Casegoods Production
Large-Diameter Panel Processing
Product Highlights
Chipbreaker Core Control
The chipbreaker design helps reduce furring or tearout in plywood core material during CNC panel routing.
Large-Diameter CNC Tool
The 5/8-inch cutting diameter, 2-1/4-inch cutting edge, 0.990-inch upcut length, and 5-inch overall length suit larger compression-cutting applications.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 5/8-inch (15.88 mm) shank. Verify right-hand rotation, cutting direction, tool projection, available clearance, guarding, dust extraction, RPM, feed speed, pass depth, cutting strategy, and part hold-down before machining. Material suitability should be confirmed against the actual panel construction, veneer or laminate surface, plywood core, adhesive content, and finish requirements.
Large-Format Edge Control
The Royce Ayr 2-Flute Chipbreaker Compression Router Bit R60-11007 is built for CNC routing laminated or veneered wood and wood composites where top and bottom edge finish is critical. Compression cutting action helps reduce surface chipping, while the chipbreaker design supports control of furring and tearout in plywood core materials.
Its 5/8-inch cutting diameter, 2-1/4-inch cutting edge, 0.990-inch upcut length, 5/8-inch shank, right-hand rotation, and 5-inch overall length make it a strong fit for compatible CNC router setups requiring a larger-diameter compression tool for cabinet, casegoods, and panel-processing production.
