Dedicated Lock Mortise Geometry
Designed for CNC router mortising on the side of doors where controlled lock-set pocket machining is required.
Royce Ayr Lock Mortise Tool Upcut 3/8" (9.53mm)
CA$999.99
Out of stock
SKU
R60-01732
Product Type
3 Flute Lock Mortise Upcut Tool
Cutting Diameter
3/8 in (9.53 mm)
Cutting Edge
1-1/8 in (28.58 mm)
Dimension b1
1 in (25.4 mm)
Dimension b2
3 in (76.2 mm)
Shank
3/8 in (9.53 mm)
Overall Length
4 in (101.6 mm)
Flutes
3
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
CNC Door Lock Set Mortising
3-Flute Lock Mortise
Upcut Tool
Lock Mortise Upcut Tool
Uncoated HW solid-carbide right-hand 3-flute lock-mortise upcut tool designed for CNC machining on the side of doors for lock-set installation. Its serrated tooth geometry helps reduce cutting horsepower requirements, while the spinback design provides relief for deep mortise cutting. The tool features a 3/8-inch cutting diameter, 1-1/8-inch cutting edge, matching 3/8-inch shank, and 4-inch overall length.
D=3/8 in9.53 mm Diameter
CE=1-1/8 in28.58 mm Cutting Edge
b1=1 in25.4 mm Dimension
OAL=4 in101.6 mm Overall Length
Lock Mortise Upcut Tool
This dedicated door-machining tool combines HW solid-carbide construction, three upcut flutes, right-hand rotation, serrated tooth geometry, and spinback relief for repeatable deep lock-mortise production.
HW / Solid Carbide3 FlutesRH UpcutSKU R60-01732
Designed for compatible CNC routers using a precision 3/8-inch collet or approved toolholding assembly, right-hand spindle rotation, and sufficient tool reach and clearance for deep door-lock mortising.
Main Product Description
The Royce Ayr 3-Flute Lock Mortise Upcut Tool R60-01732 is a solid-carbide CNC router tool built for door and millwork production. It is designed for mortising the side of doors to hold lock sets, making it a specialized option for machining door-hardware pockets and deep lock mortises.
The serrated tooth design is intended to minimize the horsepower required to cut, while the spinback design provides relief during deep mortise machining. Its 3/8-inch cutting diameter, 1-1/8-inch cutting edge, 1-inch b1 dimension, 3-inch b2 dimension, matching 3/8-inch shank, and 4-inch overall length suit compatible smaller-diameter lock-mortising setups.
This uncoated HW solid-carbide tool uses three upcut flutes and right-hand rotation. It is suited to window-and-door production, moulding and millwork, stairs and railings, and related applications requiring repeatable lock-pocket machining. RPM/feed data and country of origin are not specified by the supplied source.
Technical Specifications
Lock Mortise Upcut Tool R60-01732
- Royce Ayr
- 3-Flute Lock Mortise Upcut Tool
- R60-01732
- Precision CNC Tooling / Solid Carbide Tooling
- CNC Router
- 0.3750 in / 3/8 in (9.53 mm)
- 1.125 in / 1-1/8 in (28.58 mm)
- 1.000 in / 1 in (25.4 mm)
- 3.000 in / 3 in (76.2 mm)
- 0.375 in / 3/8 in (9.53 mm)
- 4.000 in / 4 in (101.6 mm)
- 3
- Cut Direction: Upcut · Cutting Geometry: Lock Mortise Geometry with Serrated Tooth Design and Spinback Relief · Rotation: RH / Right-Hand · Cutting Material: HW / Solid Carbide · Coating: None · RPM / Feed Data: Not Specified by Supplied Source · Country of Origin: Not Specified by Supplied Source · Primary Application: Mortising the Side of Doors to Hold Lock Sets · Industry Suitability: Window & Door; Moulding & Millwork; Stairs & Railings · Machine Interface: CNC Routers with Compatible 3/8-Inch Collets or Toolholders and RH Rotation
- Designed for compatible CNC routers using a precision 3/8-inch collet or approved toolholding assembly, right-hand spindle rotation, and sufficient tool reach and clearance for deep door-lock mortising.
Best Fit Applications
CNC Door Lock Mortising
Lock-Set Pocket Machining
Deep Mortise Cutting
Window & Door Production
Millwork, Stair & Railing Work
Product Highlights
Spinback Relief
The spinback design provides relief for deep mortise cutting and supports the reach and clearance requirements of door-lock machining.
Compact 3/8-Inch Format
The 3/8-inch diameter and shank, 1-1/8-inch cutting edge, and 4-inch overall length suit compatible lock-mortising setups.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 3/8-inch (9.53 mm) shank and support right-hand rotation. Verify collet condition, runout, tool projection, programmed mortise depth, available clearance, feed speed, RPM, cutting depth, door material, guarding, dust extraction, and hold-down before machining. Select lock-mortise tooling according to the lock hardware, mortise depth, machine power, and safe toolholder engagement.
Improve Door Lock Mortising
The Royce Ayr 3-Flute Lock Mortise Upcut Tool R60-01732 provides an uncoated HW solid-carbide solution for repeatable CNC machining of lock-set pockets on the sides of doors.
Its 3/8-inch cutting diameter and shank, 1-1/8-inch cutting edge, serrated tooth design, spinback relief, right-hand upcut geometry, and 4-inch overall length support specialized deep-mortise production when correctly held and operated.
