High-Helix Upcut Geometry
The upcut geometry helps move chips upward and out of the cut where efficient evacuation is a priority.
Royce Ayr 3 Flute Upcut High Helix Ripper 3/4" (19.05mm)
CA$999.99
Out of stock
SKU
R60-01709
Product Type
3 Flute Upcut High Helix Ripper Router Bit
Series
High Helix Ripper Upcut
Cutting Diameter
3/4 in (19.05 mm)
Cutting Edge
1-5/8 in (41.28 mm)
Shank
3/4 in (19.05 mm)
Overall Length
4 in (101.6 mm)
Flutes
3
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Chip Evacuation,Difficult Wood Grain Routing,CNC Routing
3-Flute Upcut High Helix
Ripper Router Bit
Heavy Upcut High Helix Ripper Bit
Uncoated HW solid-carbide right-hand 3-flute high-helix upcut ripper router bit designed for heavier CNC routing where chip evacuation, controlled material removal, and reduced cutting load are important. Its 3/4-inch cutting diameter, 1-5/8-inch cutting edge, matching 3/4-inch shank, and 4-inch overall length support larger-diameter production work in moulding, millwork, construction components, stairs, railings, and related wood-routing applications.
D=3/4 in19.05 mm Diameter
CE=1-5/8 in41.28 mm Cutting Edge
Sh=3/4 in19.05 mm Shank
OAL=4 in101.6 mm Overall Length
Heavy Upcut High Helix Ripper Bit
This larger-format production tool combines HW solid-carbide construction, three high-helix upcut flutes, right-hand rotation, and serrated ripper tooth geometry to support chip evacuation and controlled cutting through difficult wood grain.
HW / Solid Carbide3 FlutesRH High Helix UpcutSKU R60-01709
Designed for compatible CNC routers using a precision 3/4-inch collet or approved toolholding assembly with right-hand spindle rotation and adequate power and clearance for the larger cutting diameter.
Main Product Description
The Royce Ayr 3-Flute Upcut High Helix Ripper Router Bit R60-01709 is designed for CNC routing applications where chip evacuation and controlled material removal are important. Its serrated tooth design is intended to help reduce tear-out in difficult wood grains while lowering the horsepower required to cut.
The high-helix upcut geometry helps move chips upward and away from the cut, supporting production routing where evacuation is a priority. The 3/4-inch cutting diameter, 1-5/8-inch cutting edge, matching 3/4-inch shank, and 4-inch overall length provide a heavy-duty format for larger-diameter roughing, ripping, profiling, and material-removal work.
This uncoated HW solid-carbide tool uses three high-helix upcut flutes and right-hand rotation. It is associated with moulding and millwork, construction-industry components, stairs, railings, and compatible wood-routing applications. Series material indicators include HW, SW, FB, and PL. RPM/feed data and country of origin are not specified by the supplied source.
Technical Specifications
High-Helix Upcut Ripper Bit R60-01709
- Royce Ayr
- 3-Flute Upcut High Helix Ripper Router Bit
- R60-01709
- High Helix Ripper Upcut
- CNC Router
- 0.7500 in / 3/4 in (19.05 mm)
- 1.625 in / 1-5/8 in (41.28 mm)
- 0.750 in / 3/4 in (19.05 mm)
- 4.000 in / 4 in (101.6 mm)
- 3
- Upcut
- High Helix
- Tooth Design: Serrated Ripper-Style Tooth Design · Rotation: RH / Right-Hand · Cutting Material: HW / Solid Carbide · Coating: None · RPM / Feed Data: Not Specified by Supplied Source · Country of Origin: Not Specified by Supplied Source · Series Material Indicators: HW, SW, FB, and PL · Listed Industries: Moulding & Millwork; Construction Industry; Stairs & Railings · Primary Applications: CNC Routing, Roughing, Ripping, Chip Evacuation, Difficult-Grain Machining, and Production Material Removal
- Designed for compatible CNC routers using a precision 3/4-inch collet or approved toolholding assembly with right-hand spindle rotation and adequate power and clearance for the larger cutting diameter.
Best Fit Applications
Heavy CNC Wood Routing
Upcut Chip Evacuation
Difficult Grain Roughing
Moulding & Millwork Production
Stair, Railing & Construction Parts
Product Highlights
Serrated Ripper Tooth Design
The serrated tooth form is intended to reduce tear-out in difficult wood grains while lowering cutting horsepower demand.
Heavy 3/4-Inch Format
The 3/4-inch diameter and shank, 1-5/8-inch cutting edge, and 4-inch overall length support larger-diameter CNC routing.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 3/4-inch (19.05 mm) shank and support right-hand rotation. Verify spindle power, collet condition, runout, tool projection, available clearance, programmed cutting depth, RPM, feed speed, chipload, material suitability, workholding, guarding, and dust or chip extraction. Because this is an upcut tool, confirm that the lifting action is appropriate for the part, fixture, spoilboard, hold-down method, and required top-edge finish.
Improve Heavy High-Helix Routing
The Royce Ayr 3-Flute Upcut High Helix Ripper Router Bit R60-01709 provides an uncoated HW solid-carbide solution for heavier CNC routing where chip evacuation and controlled material removal matter.
Its 3/4-inch cutting diameter, 1-5/8-inch cutting edge, matching shank, three-flute high-helix upcut geometry, right-hand rotation, and 4-inch overall length support demanding production machining when correctly held and operated.
