Serrated Ripper Tooth Design
The serrated tooth form is intended to help control tear-out in difficult wood grains while reducing cutting horsepower demand.
Royce Ayr High Helix Ripper Downcut CNC Router Bit 5/8" (15.88mm)
CA$999.99
Out of stock
SKU
R60-01505
Product Type
High Helix Ripper Downcut CNC Router Bit
Series
High Helix Ripper Downcut
Cutting Diameter
5/8 in (15.88 mm)
Cutting Edge
1-5/8 in (41.28 mm)
Shank
5/8 in (15.88 mm)
Overall Length
4 in (101.6 mm)
Flutes
3
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Wood Routing,Moulding,Millwork,Stairs,Railings
3-Flute Downcut High Helix
Ripper Router Bit
High-Helix Downcut Ripper Bit
Uncoated HW solid-carbide right-hand 3-flute high-helix downcut ripper router bit designed for CNC routing where material hold-down, top-edge control, and reduced tear-out in difficult wood grains are important. Its 5/8-inch cutting diameter, 1-5/8-inch cutting edge, matching 5/8-inch shank, and 4-inch overall length support production routing in moulding, millwork, stair, railing, and construction-related wood-machining applications.
D=5/8 in15.88 mm Diameter
CE=1-5/8 in41.28 mm Cutting Edge
Sh=5/8 in15.88 mm Shank
OAL=4 in101.6 mm Overall Length
High-Helix Downcut Ripper Bit
This production tool combines HW solid-carbide construction, three high-helix downcut flutes, right-hand rotation, and serrated ripper tooth geometry to help control tear-out while supporting material hold-down.
HW / Solid Carbide3 FlutesRH High Helix DowncutSKU R60-01505
Designed for compatible CNC routers using a precision 5/8-inch collet or approved toolholding assembly with right-hand spindle rotation.
Main Product Description
The Royce Ayr 3-Flute Downcut High Helix Ripper Router Bit R60-01505 is part of Royce Ayr's solid-carbide CNC tooling range. It is designed for wood-routing applications where reduced tear-out, top-surface control, and material hold-down are important.
The serrated tooth design is intended to help control tear-out in difficult wood grains while reducing cutting horsepower demand. The downcut geometry directs cutting pressure toward the table, supporting cleaner top-side cutting and improved part stability when the machine setup, workholding, and toolpath are properly matched.
This uncoated HW solid-carbide tool uses three high-helix downcut flutes and right-hand rotation. Its 5/8-inch cutting diameter, 1-5/8-inch cutting edge, matching 5/8-inch shank, and 4-inch overall length suit production CNC work in moulding, millwork, stairs, railings, and construction-related wood machining. RPM, feed data, and country of origin are not specified by the supplied source and should be confirmed when required.
Technical Specifications
High-Helix Ripper Bit R60-01505
- Royce Ayr
- 3-Flute Downcut High Helix Ripper Router Bit
- R60-01505
- High Helix Ripper Downcut
- CNC Router
- 0.6250 in / 5/8 in (15.88 mm)
- 1.625 in / 1-5/8 in (41.28 mm)
- 0.625 in / 5/8 in (15.88 mm)
- 4.000 in / 4 in (101.6 mm)
- 3
- Downcut
- High Helix
- Tooth Design: Serrated Ripper-Style Tooth Design · Rotation: RH / Right-Hand · Cutting Material: HW / Solid Carbide · Coating: None · RPM / Feed Data: Not Specified by Supplied Source · Country of Origin: Not Specified by Supplied Source · Material Compatibility: Wood Applications and Difficult Wood Grains · Industry Categories: Construction Industry; Moulding & Millwork; Stairs & Railings · Primary Applications: CNC Routing, Downcut Ripping, Tear-Out Control, Material Hold-Down, Profiles, and Production Wood Machining
- Designed for compatible CNC routers using a precision 5/8-inch collet or approved toolholding assembly with right-hand spindle rotation.
Best Fit Applications
Difficult Wood Grain Routing
Moulding & Millwork Production
Stair & Railing Components
Construction Wood Machining
Downcut Material Hold-Down
Product Highlights
Downcut Hold-Down Geometry
The downcut geometry directs cutting pressure toward the table to support cleaner top-side cutting and improved part stability.
5/8-Inch Production Format
The 5/8-inch cutting diameter and shank with a 1-5/8-inch cutting edge suit compatible production CNC router setups.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 5/8-inch (15.88 mm) shank and support right-hand rotation. Verify collet condition, runout, tool projection, available clearance, programmed cutting depth, RPM, feed speed, chipload, material suitability, part hold-down, spoilboard condition, guarding, and dust extraction before production. Downcut geometry can improve top-edge control and stability, but chip evacuation and heat control must be matched to the material and toolpath.
Improve 5/8-Inch Downcut Routing
The Royce Ayr 3-Flute Downcut High Helix Ripper Router Bit R60-01505 provides an uncoated HW solid-carbide solution for production CNC routing where reduced tear-out and material hold-down are important.
Its 5/8-inch cutting diameter, 1-5/8-inch cutting edge, matching shank, three-flute high-helix downcut geometry, right-hand rotation, and 4-inch overall length support controlled wood machining when correctly held and operated.
