Controlled Downcut Geometry
The downcut flute direction helps maintain top-side control during detailed routing, profiling, and pocketing passes.
Royce Ayr Double Flute Hard Plastic & Aluminum Downcut Router Bit 1/8" (3.175mm)
CA$999.99
In stock
SKU
R57-02401
Product Type
Double-flute downcut CNC router bit
Application
Hard plastics and aluminum routing
Cutting Diameter
0.1250 in / 1/8 in (3.175 mm)
Cutting Edge
0.500 in / 1/2 in (12.7 mm)
Shank
0.250 in / 1/4 in (6.35 mm)
Overall Length
2.000 in / 2 in (50.8 mm)
Flutes
2
Rotation
RH
Double-Flute Downcut
Router Bit
Double-Flute Downcut Router Bit
Solid-carbide two-flute downcut router bit designed for detailed routing, trimming, profiling, and pocketing in hard plastics and aluminum. Its 1/8-inch cutting diameter, 1/2-inch cutting edge, 1/4-inch shank, and 2-inch overall length support precise small-diameter machining where top-side control and pocket-bottom finish are important.
D=1/8 in3.175 mm Diameter
CE=1/2 in12.7 mm Cutting Edge
Sh=1/4 in6.35 mm Shank
OAL=2 in50.8 mm Overall Length
Double-Flute Downcut Router Bit
This precision tool combines a solid-carbide body, two right-hand downcut flutes, and a compact 1/8-inch cutting diameter for controlled machining in compatible hard-plastic and aluminum applications.
Solid Carbide2 FlutesRH DowncutSKU R57-02401
Designed for compatible CNC routers and industrial spindle systems using precision 1/4-inch collets or approved toolholding assemblies.
Main Product Description
The Royce Ayr Double-Flute Downcut Router Bit R57-02401 is designed for CNC routing in hard plastics and aluminum where top-side control and a clean pocket-bottom finish are required. Its 0.1250-inch cutting diameter and 0.500-inch cutting edge support detailed trimming, profiling, slotting, and pocketing operations.
The downcut geometry directs cutting pressure toward the workpiece and helps control the upper surface during machining. Royce Ayr identifies this family as providing an end-mill-style finish for improved pocket bottoms, making it well suited to detail work where clean floor finish and controlled edge quality are priorities.
The 0.250-inch shank, two cutting flutes, right-hand rotation, and 2.000-inch overall length are intended for precision CNC routing systems. Correct collet condition, verified runout, suitable spindle speed, feed rate, plunge rate, depth-per-pass, chip evacuation, and workholding are essential for controlling heat and maintaining dimensional accuracy.
Technical Specifications
Downcut Router Bit R57-02401
- Royce Ayr
- Double-Flute Downcut CNC Router Bit
- R57-02401
- R57-024/124 Double Flute Hard Plastic and Aluminum Downcut
- 0.1250 in / 1/8 in (3.175 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 0.250 in / 1/4 in (6.35 mm)
- 2.000 in / 2 in (50.8 mm)
- 2
- Double-Flute Downcut
- RH / Right Hand
- Solid Carbide
- Material Compatibility: Hard Plastics and Aluminum · Catalog Note: End-Mill-Style Finish for Improved Pocket Bottoms · Machine Interface: CNC Routers with Precision 1/4-Inch Collets
- Designed for compatible CNC routers and industrial spindle systems using precision 1/4-inch collets or approved toolholding assemblies.
Best Fit Applications
Hard Plastic Routing
Aluminum Profiling
Detailed Pocketing
Small-Diameter Trimming
Precision Slotting
Product Highlights
Improved Pocket-Bottom Finish
The tool family is designed to produce an end-mill-style floor finish in compatible pocketing applications.
Compact Precision Geometry
The 1/8-inch cutting diameter supports detailed CNC work where smaller profiles and controlled feature sizes are required.
Compatibility & Installation Notes
Confirm that the spindle and toolholder accept an exact 1/4-inch (6.35 mm) shank and that right-hand rotation matches the programmed cutting direction. Inspect and clean the collet, collet nut, and tool shank, verify runout, and establish suitable RPM, feed speed, plunge rate, and depth-per-pass. For aluminum and hard plastics, maintain effective chip evacuation and confirm whether air blast, coolant, or other shop-approved thermal-control methods are required.
Improve Detail Routing and Pocket Finish
The Royce Ayr Double-Flute Downcut Router Bit R57-02401 provides a compact solid-carbide solution for detailed CNC routing in hard plastics and aluminum.
Its 1/8-inch diameter, 1/2-inch cutting edge, 1/4-inch shank, two right-hand flutes, and 2-inch overall length support precision profiling, trimming, slotting, and pocketing when correctly applied.
