Controlled Downcut Geometry
The downcut flute direction helps maintain top-side control during profiling, trimming, slotting, and pocketing passes.
Royce Ayr Double Flute Hard Plastic & Aluminum Downcut Router Bit 1/4" (6.35mm)
CA$999.99
In stock
SKU
R57-02405
Product Type
Double-Flute Downcut Router Bit
Diameter
1/4 in (6.35 mm)
Cutting Edge
3/4 in (19.05 mm)
Shank
1/4 in (6.35 mm)
Overall Length
2-1/2 in (63.5 mm)
Flutes
2
Rotation
Right-Hand (RH)
Construction
Solid Carbide Tooling
Application
Hard Plastics,Aluminum,Pocketing,Profiling,Trimming
Catalog Note
End Mill Finish Intended to Improve Bottom Finish in Pocketing
Double-Flute Downcut
Router Bit
Double-Flute Downcut Router Bit
Solid-carbide two-flute downcut router bit designed for controlled CNC routing in hard plastics and aluminum. Its 1/4-inch cutting diameter, 3/4-inch cutting edge, 1/4-inch shank, and 2-1/2-inch overall length support profiling, trimming, slotting, and pocketing where top-side control and improved pocket-bottom finish are required.
D=1/4 in6.35 mm Diameter
CE=3/4 in19.05 mm Cutting Edge
Sh=1/4 in6.35 mm Shank
OAL=2-1/2 in63.5 mm Overall Length
Double-Flute Downcut Router Bit
This precision tool combines a solid-carbide body, two right-hand downcut flutes, and a compact 1/4-inch cutting diameter for controlled machining in compatible hard-plastic and aluminum applications.
Solid Carbide2 FlutesRH DowncutSKU R57-02405
Designed for compatible CNC routers and industrial spindle systems using precision 1/4-inch collets or approved toolholding assemblies.
Main Product Description
The Royce Ayr Double-Flute Downcut Router Bit R57-02405 is part of the R57-024 / R57-124 hard-plastic and aluminum downcut series. It is designed for precision CNC routing where controlled top-side cutting action and a clean pocket-bottom finish are important.
Its 0.2500-inch cutting diameter and 0.750-inch cutting edge support compact profiling, trimming, slotting, and pocketing operations. The downcut geometry directs cutting pressure toward the workpiece, while the two-flute configuration supports controlled chip formation in suitable plastic and non-ferrous applications.
Royce Ayr identifies this family as providing an end-mill-style finish for improved pocket bottoms. The 0.250-inch shank, right-hand rotation, solid-carbide construction, and 2.500-inch overall length require precise collet condition, verified runout, suitable RPM, feed rate, plunge rate, depth-per-pass, workholding, and chip evacuation.
Technical Specifications
Downcut Router Bit R57-02405
- Royce Ayr
- Double-Flute Downcut CNC Router Bit
- R57-02405
- R57-024 / R57-124 Double Flute Hard Plastic and Aluminum Downcut
- 0.2500 in / 1/4 in (6.35 mm)
- 0.750 in / 3/4 in (19.05 mm)
- 0.250 in / 1/4 in (6.35 mm)
- 2.500 in / 2-1/2 in (63.5 mm)
- 2
- Double-Flute Downcut
- RH / Right Hand
- Solid Carbide
- Coating: Not Specified by Source · Material Compatibility: Hard Plastics and Aluminum · Catalog Note: End-Mill-Style Finish for Improved Pocket Bottoms · Machine Interface: CNC Routers with Precision 1/4-Inch Collets
- Designed for compatible CNC routers and industrial spindle systems using precision 1/4-inch collets or approved toolholding assemblies.
Best Fit Applications
Hard Plastic Routing
Aluminum Profiling
Precision Pocketing
Small-Diameter Trimming
Non-Ferrous Component Machining
Product Highlights
Improved Pocket-Bottom Finish
The tool family is designed to produce an end-mill-style floor finish in compatible pocketing applications.
Compact 1/4-Inch Geometry
The 1/4-inch cutting diameter and shank support detailed CNC work where compact feature sizes and controlled cutting are required.
Compatibility & Installation Notes
Confirm that the spindle and toolholder accept an exact 1/4-inch (6.35 mm) shank and that right-hand rotation matches the programmed cutting direction. Inspect and clean the collet, collet nut, and tool shank, verify runout, and establish suitable RPM, feed speed, plunge rate, and depth-per-pass. For aluminum and hard plastics, maintain effective chip evacuation and confirm whether air blast, coolant, or another shop-approved thermal-control method is required.
Improve Compact Routing and Pocket Finish
The Royce Ayr Double-Flute Downcut Router Bit R57-02405 provides a compact solid-carbide solution for precision CNC routing in hard plastics and aluminum.
Its 1/4-inch diameter, 3/4-inch cutting edge, 1/4-inch shank, two right-hand flutes, and 2-1/2-inch overall length support controlled profiling, trimming, slotting, and pocketing when correctly applied.
