Chip-Breaker Harmonic Control
Specialized chip-breaker geometry is intended to help reduce harmonics during routing of phenolic and fiber-reinforced plastic materials.
Royce Ayr 3-Flute Solid Carbide Low Helix Upcut Router Bit - 3/8" Diameter x 7/8" Cut
CA$999.99
Out of stock
SKU
R72-10004
Product Type
3 Flute Low Helix Up Cut Bit
Diameter
3/8 in (9.52 mm)
Cutting Length
7/8 in (22.2 mm)
Overall Length
3 in (76.2 mm)
Flutes
3
Material
Solid Carbide
Application
Phenolic,Plastics,Composites,High-Density Materials
3-Flute Low-Helix Upcut
Phenolic Spiral Router Bit
Phenolic Upcut Spiral Bit
Solid-carbide, right-hand, three-flute low-helix upcut spiral router bit designed for phenolic and other fiber-reinforced plastics. Its 3/8-inch cutting diameter, 7/8-inch cutting edge, 3/8-inch shank, and 3-inch overall length combine with chip-breaker geometry to support stable routing and effective chip evacuation in compatible CNC applications.
D=3/8 in9.525 mm Diameter
CE=7/8 in22.225 mm Cutting Edge
Sh=3/8 in9.525 mm Shank
OAL=3 in76.2 mm Overall Length
Phenolic Upcut Spiral Bit
This three-flute solid-carbide tool combines low-helix upcut geometry with specialized chip-breakers intended to help reduce harmonics while routing phenolic and fiber-reinforced plastics.
Solid Carbide / HW3 FlutesRight-HandSKU R72-10004
Designed for compatible CNC routers using a precision 3/8-inch (9.525 mm) collet or approved toolholding assembly with sufficient clearance for the 3-inch overall length.
Main Product Description
The Royce Ayr 3-Flute Low-Helix Upcut Phenolic Spiral Router Bit R72-10004 is engineered for routing phenolic and other fiber-reinforced plastics. Its 0.3750-inch cutting diameter and 0.875-inch cutting edge provide a compact production format for profiling, slotting, trimming, and controlled material removal in composite-sheet applications.
The three-flute low-helix upcut geometry supports chip evacuation while maintaining stable cutting engagement. Royce Ayr specifies unique chip-breakers that help reduce harmonics during routing when the tool is matched to suitable spindle speed, feed rate, and workholding.
The 0.375-inch shank and 3.000-inch overall length require a compatible precision collet or approved toolholder. Before production, verify collet condition, runout, right-hand spindle rotation, tool projection, spindle speed, feed rate, depth per pass, workholding, material suitability, and chip extraction.
Technical Specifications
Phenolic Upcut Spiral R72-10004
- Royce Ayr
- 3-Flute Low-Helix Upcut Phenolic Spiral Router Bit
- R72-10004
- Phenolic Upcut
- HW / Solid Carbide
- 0.3750 in / 3/8 in (9.525 mm)
- 0.875 in / 7/8 in (22.225 mm)
- 0.375 in / 3/8 in (9.525 mm)
- 3.000 in / 3 in (76.2 mm)
- 3
- Low-Helix Upcut Spiral with Chip-Breakers
- RH / Right Hand
- Coating: None · Material Compatibility: Phenolic and Other Fiber-Reinforced Plastics · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 3/8-inch (9.525 mm) collet or approved toolholding assembly with sufficient clearance for the 3-inch overall length.
Best Fit Applications
Phenolic Sheet Routing
Fiber-Reinforced Plastics
Composite Panel Profiling
Slotting & Trimming
CNC Production Routing
Product Highlights
Three-Flute Low-Helix Geometry
The three-flute low-helix upcut form balances controlled cutting engagement with upward chip evacuation in compatible CNC applications.
Compact 3/8-Inch Tool Format
The matching 3/8-inch cutting diameter and shank support secure precision toolholding for detailed composite-sheet routing.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 3/8-inch (9.525 mm) shank and provides sufficient clearance for the 3-inch (76.2 mm) overall length. Inspect the collet and nut, minimize unsupported tool projection, verify right-hand rotation and runout, and establish spindle speed, feed rate, depth per pass, workholding, material suitability, and chip extraction according to the machine and approved shop procedures.
Improve Phenolic Routing Stability
The Royce Ayr 3-Flute Low-Helix Upcut Phenolic Spiral Router Bit R72-10004 provides a solid-carbide solution for routing phenolic and other fiber-reinforced plastics. Its 3/8-inch diameter, 7/8-inch cutting edge, 3/8-inch shank, three-flute geometry, and 3-inch overall length support profiling, slotting, trimming, and production routing.
Low-helix upcut geometry supports chip evacuation, while the specialized chip-breakers help control harmonics when the tool is correctly held and operated within suitable machining parameters.
