3/8-Inch Straight Cutter
The verified cutting diameter and 1-1/8-inch cutting edge support practical routing, trimming, pocketing, and slotting work.
Royce Ayr 2-Flute Straight Wood & Plastic Router Bit 3/8" (9.53mm)
CA$999.99
In stock
SKU
R56-31112
Product Type
2-Flute Straight Router Bit
Diameter
3/8 in (9.53 mm)
Cutting Edge
1-1/8 in (28.58 mm)
Shank
3/8 in (9.53 mm)
Overall Length
3 in (76.2 mm)
Flutes
2
Rotation
Right-Hand (RH)
Material
HW
Coating
None
Application
Solid Wood Routing,Hard Plastic Routing,Straight-Sided Cuts,Pocketing,Dado-Style Routing
2-Flute
Straight-Flute
Router Bit
HW solid-carbide straight-flute router bit designed for general-purpose CNC routing in solid wood and hard plastic. Its 3/8-inch cutting diameter, 1-1/8-inch cutting edge, 3/8-inch shank, and 3-inch overall length support controlled routing, trimming, pocketing, slotting, and straight-sided profile work.
D=3/8 in9.53 mm Diameter
CE=1-1/8 in28.58 mm Cutting Edge
Sh=3/8 in9.53 mm Shank
OAL=3 in76.2 mm Overall Length
Straight-Flute Router Bit
This production tool combines HW solid-carbide construction, two straight cutting flutes, right-hand rotation, and a precision 3/8-inch shank for controlled routing in compatible wood and hard-plastic applications.
HW / Solid Carbide2 FlutesRH RotationSKU R56-31112
Designed for compatible CNC routers and routing equipment using precision 3/8-inch collets or approved toolholding assemblies.
Main Product Description
The Royce Ayr 2-Flute Straight-Flute General Wood and Plastic Router Bit R56-31112 is designed for general-purpose routing in solid wood and hard plastic. Its straight-flute geometry provides neutral axial cutting action compared with upcut, downcut, or compression spiral tools, making it useful where controlled straight-sided cutting is required.
The 0.3750-inch cutting diameter and 1.125-inch cutting edge support routing, trimming, pocketing, slotting, and profile work. The matching 0.375-inch shank and 3.000-inch overall length provide a stable format for compatible CNC router collets and toolholding systems.
This uncoated HW solid-carbide tool uses two flutes and right-hand rotation. Correct collet condition, minimum practical projection, verified runout, suitable RPM, feed rate, depth-per-pass, workholding, and chip evacuation are essential for maintaining finish quality, dimensional control, and reliable tool life.
Technical Specifications
Straight-Flute Bit R56-31112
- Royce Ayr
- 2-Flute Straight-Flute Router Bit
- R56-31112
- Straight Flute General Wood and Plastic
- HW / Solid Carbide CNC Router Tooling
- 0.3750 in / 3/8 in (9.53 mm)
- 1.125 in / 1-1/8 in (28.58 mm)
- 0.375 in / 3/8 in (9.53 mm)
- 3.000 in / 3 in (76.2 mm)
- 2
- RH / Right Hand
- HW / Solid Carbide · Straight Flute · Uncoated
- Solid Wood and Hard Plastic
- CNC Routers with Precision 3/8-Inch Collets
Best Fit Applications
General CNC Routing
Solid Wood Machining
Hard Plastic Routing
Pocketing & Slotting
Cabinet & Millwork Profiles
Product Highlights
Neutral Straight-Flute Action
The straight geometry provides controlled sidewall cutting without the axial chip direction of spiral tooling.
Wood & Hard-Plastic Use
The official Royce Ayr series is specified for general-purpose routing in solid wood and hard plastic.
Compatibility & Installation Notes
Confirm that the spindle and toolholder accept an exact 3/8-inch (9.53 mm) shank and provide adequate clearance for the 3-inch overall length and required projection. Inspect and clean the collet, collet nut, and tool shank, minimize unsupported projection, verify runout, and confirm right-hand rotation before machining. Match RPM, feed rate, depth-per-pass, workholding, and chip evacuation to the selected wood or hard-plastic material.
Control Straight-Sided CNC Routing
The Royce Ayr 2-Flute Straight-Flute General Wood and Plastic Router Bit R56-31112 provides an uncoated HW solid-carbide solution for controlled routing in solid wood and hard plastic.
Its 3/8-inch diameter, 1-1/8-inch cutting edge, matching shank, two-flute geometry, right-hand rotation, and 3-inch overall length support repeatable production machining when correctly held and operated.
