Compact 3/16-Inch Cutting Format
The 3/16-inch cutting diameter and 3/4-inch cutting edge support smaller grooves, slots, trimming cuts, templates, and detailed routing work.
Royce Ayr 2 Flute Straight Wood & Plastic Router Bit 3/16" (4.76mm)
CA$999.99
In stock
SKU
R56-21103
Product Type
2 Flute Straight Wood &Plastic Router Bit
Diameter
3/16 in (4.76 mm)
Cutting Edge Length
3/4 in (19.05 mm)
Shank
1/4 in (6.35 mm)
Overall Length
2 in (50.8 mm)
Cutting Geometry
2 Flutes / Straight Flute
Application
Solid Wood Routing,Hard Plastic Routing,Slotting,Trimming,Template Routing,Detail Routing
2-Flute
Straight Wood & Plastic
Router Bit
Solid-carbide, two-flute straight router bit for general-purpose routing in solid wood and hard plastic. Its compact 3/16-inch cutting diameter, 3/4-inch cutting edge, 1/4-inch shank, and 2-inch overall length support controlled slotting, trimming, template routing, and detail machining.
D=3/16 in4.76 mm Diameter
CEL=3/4 in19.05 mm Cutting Edge
Sh=1/4 in6.35 mm Shank
OAL=2 in50.8 mm Overall Length
Straight Wood & Plastic Router Bit
This general-purpose solid-carbide tool combines two straight flutes with a compact 3/16-inch cutting diameter for controlled routing in solid wood and hard plastic.
Solid Carbide2 FlutesStraight FluteSKU R56-21103
Designed for compatible CNC routers and routing equipment using precision 1/4-inch collets or approved toolholding assemblies.
Main Product Description
The Royce Ayr 2-Flute Straight Wood & Plastic Router Bit R56-21103 is designed for clean, controlled routing where straight-flute geometry is required. Its 0.1875-inch cutting diameter and 0.750-inch cutting edge provide a compact format for smaller grooves, slots, trimming cuts, templates, and detailed routing in solid wood and hard plastic.
Two straight flutes provide a neutral cutting action rather than the upward or downward force created by spiral geometries. The 0.250-inch shank fits precision 1/4-inch collets, while the solid-carbide construction supplies the rigidity and edge retention needed for accurate routing when feed rate, spindle speed, cut depth, and chip evacuation are correctly established.
With a 2.000-inch overall length, this tool is suited to compatible CNC and industrial routing equipment. Confirm toolholder condition, minimize unsupported projection, verify clearance, and match the machining parameters to the material and application before production use.
Technical Specifications
Straight Router Bit R56-21103
- Royce Ayr
- 2-Flute Straight Wood & Plastic Router Bit
- R56-21103
- R56-211 Straight Wood & Plastic
- Solid Carbide / Straight-Flute Geometry
- 0.1875 in / 3/16 in (4.76 mm)
- 0.750 in / 3/4 in (19.05 mm)
- 0.250 in / 1/4 in (6.35 mm)
- 2.000 in / 2 in (50.8 mm)
- 2
- Not Specified by Supplied Source
- Solid Carbide · Straight Flute
- Solid Wood and Hard Plastic
- CNC Routers and Routing Equipment with 1/4-Inch Collets
Best Fit Applications
Solid Wood Routing
Hard Plastic Routing
Small-Diameter Slotting
Template & Detail Routing
Trimming Operations
Product Highlights
Neutral Straight-Flute Geometry
Two straight flutes provide controlled cutting action without the upward or downward force associated with spiral router-bit geometries.
Solid-Carbide Rigidity
The solid-carbide construction supports edge retention, dimensional control, and stable routing when the tool is correctly held and operated.
Compatibility & Installation Notes
Confirm that the spindle, router, collet, and toolholder accept an exact 1/4-inch (6.35 mm) shank. Inspect the collet and nut for wear or contamination, minimize unsupported tool projection, and verify clearance for the 2-inch overall length before machining. Straight-flute tooling should not be substituted for upcut, downcut, or compression geometry unless the required edge finish and chip movement are appropriate. Establish spindle speed, feed rate, pass depth, chip evacuation, guarding, and workholding for the material and machine.
Control Small-Diameter Routing Operations
The Royce Ayr 2-Flute Straight Wood & Plastic Router Bit R56-21103 provides a compact solid-carbide solution for general-purpose routing in solid wood and hard plastic. Its 3/16-inch diameter, 3/4-inch cutting edge, 1/4-inch shank, and 2-inch overall length support repeatable slotting, trimming, template, and detail-routing work.
Two straight flutes provide neutral cutting action and controlled material removal when the tool is installed in a suitable 1/4-inch collet and operated within appropriate machining parameters.
