Royce Ayr 2-Flute Straight Solid Carbide Router Bit - 1/2" Dia x 1" Cut x 3" OAL
2-Flute General-Purpose
Upcut Spiral Router Bit
Right-hand, two-flute solid-carbide upcut spiral router bit for general-purpose routing in solid wood, wood composites, and selected plastics. Its 3/4-inch cutting diameter, 1-5/8-inch cutting edge, 3/4-inch shank, and 4-inch overall length support efficient chip evacuation in compatible CNC routing systems.
Main Product Description
The Royce Ayr 2-Flute General-Purpose Upcut Spiral Router Bit R52-32838 is intended for general-purpose routing in solid wood, wood composites, and selected plastics. Its 0.7500-inch cutting diameter and 1.625-inch cutting edge provide the capacity required for profiling, grooving, slotting, and other production CNC operations.
The two-flute upcut spiral geometry carries chips upward and away from the cutting zone, supporting good chip evacuation and reducing chip recutting in properly configured operations. The tool is manufactured for right-hand rotation and should be matched to the spindle direction and toolholding system.
The 0.750-inch shank and 4.000-inch overall length require a compatible precision collet or approved toolholder. Collet condition, runout, tool projection, spindle speed, feed rate, depth per pass, workholding, and dust or chip extraction should be established for the material and machine.
Best Fit Applications
Product Highlights
Upcut Chip Evacuation
Two upcut spiral flutes carry chips away from the cutting zone to support cleaner material removal and reduce chip recutting.
Production-Scale Cutting Capacity
The 3/4-inch diameter and 1-5/8-inch cutting edge provide useful capacity for general-purpose profiling, grooving, and slotting.
Rigid 3/4-Inch Toolholding
The matching 3/4-inch shank supports secure precision toolholding in compatible CNC spindle and collet systems.
Compatibility & Installation Notes
Confirm that the CNC spindle or router toolholder accepts an exact 3/4-inch (19.05 mm) shank and provides sufficient clearance for the 4-inch (101.6 mm) overall length. Inspect the collet and nut, minimize unsupported tool projection, verify right-hand rotation and runout, and establish spindle speed, feed rate, depth per pass, workholding, and chip extraction according to the material, machine, and approved shop procedures.
Improve General-Purpose Chip Evacuation
The Royce Ayr 2-Flute General-Purpose Upcut Spiral Router Bit R52-32838 provides a solid-carbide solution for routing solid wood, wood composites, and selected plastics. Its 3/4-inch diameter, 1-5/8-inch cutting edge, 3/4-inch shank, and 4-inch overall length support general-purpose CNC profiling, grooving, and slotting.
Two-flute upcut spiral geometry promotes effective chip removal when the tool is correctly held and operated within suitable machining parameters.
