Royce Ayr 2-Flute Straight Carbide 1/2
2-Flute Straight Carbide
Router Bit
Premium-grade solid-carbide router bit with two straight flutes for general-purpose machining in solid wood, MDF, composite panels, and compatible plastics. Its 1/2-inch cutting diameter, 1-inch cutting edge, 1/2-inch shank, and 3-inch overall length support controlled slotting, dadoing, profiling, and production routing.
Main Product Description
The Royce Ayr 2-Flute Straight General-Purpose Router Bit R56-11814 is a reliable production tool for slotting, dadoing, profiling, and general-purpose routing. Its straight-flute geometry provides neutral axial cutting action, making it suitable for operations where aggressive upward or downward material force is not desired.
The 0.5000-inch cutting diameter, 1.000-inch cutting edge, and rigid 0.500-inch shank support accurate depth control and consistent sidewall tracking in solid wood, MDF, composite panels, and compatible plastics. The two-flute format balances chip clearance with finish quality for day-to-day industrial machining.
Premium-grade solid-carbide construction supports edge retention and dimensional consistency during repeated production cycles. Before machining, verify collet condition, runout, tool projection, spindle speed, feed rate, depth per pass, workholding, and dust or chip extraction.
Best Fit Applications
Product Highlights
Straight-Flute Geometry
Provides neutral axial cutting action for clean vertical routing without the aggressive lift forces associated with spiral geometries.
Balanced Two-Flute Design
Two cutting flutes support efficient chip clearance and consistent finish quality during routine production cycles.
Premium Carbide Construction
The rigid solid-carbide body supports edge retention, dimensional consistency, and dependable performance in professional CNC routing.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 1/2-inch (12.7 mm) shank and provides sufficient clearance for the 3-inch (76.2 mm) overall length. Clean and inspect the collet and nut, minimize unsupported tool projection, verify right-hand rotation and runout, and establish feed rate, spindle speed, depth per pass, workholding, and dust or chip extraction for the material being machined.
Improve General-Purpose Routing Consistency
The Royce Ayr 2-Flute Straight General-Purpose Router Bit R56-11814 provides a rigid solid-carbide solution for slotting, dadoing, profiling, and everyday production routing. Its 1/2-inch diameter, 1-inch cutting edge, 1/2-inch shank, and 3-inch overall length suit a broad range of cabinet, furniture, panel, and architectural-millwork operations.
Straight two-flute cutting action supports controlled material engagement and consistent dimensions when the tool is correctly held and operated within suitable machining parameters.
