Downcut Top-Edge Control
The spiral geometry directs cutting pressure downward to help reduce top-surface chipping in laminated and finished materials.
Royce Ayr 2-Flute Downcut Spiral Router Bit 5/32" (3.97mm)
CA$999.99
Out of stock
SKU
R57-22244
Product Type
2-Flute Downcut Spiral Router Bit
Series
R57-222/322 Downcut Spiral 2 Flute
Cutting Diameter
5/32 in (3.97 mm)
Cutting Length
5/8 in (15.88 mm)
Shank
1/4 in (6.35 mm)
Overall Length
2 in (50.8 mm)
Flutes
2
Geometry
Downcut Spiral
Construction
Solid Carbide
Application
Solid Wood,Wood Composites,Laminated Material,Some Plastics
2-Flute
Downcut Spiral
Router Bit
Compact solid-carbide downcut spiral router bit designed for clean top-edge routing in solid wood, wood composites, laminated materials, and selected plastics. Its 5/32-inch cutting diameter, 5/8-inch cutting length, 1/4-inch shank, and 2-inch overall length support detailed grooves, dados, profiles, and small-diameter CNC machining.
D=5/32 in3.97 mm Diameter
CL=5/8 in15.88 mm Cutting Length
Sh=1/4 in6.35 mm Shank
OAL=2 in50.8 mm Overall Length
Downcut Spiral Router Bit
This compact production tool combines two downcut spiral flutes, solid-carbide construction, and a precision 1/4-inch shank for controlled routing where top-surface edge quality matters.
Solid Carbide2 FlutesDowncut SpiralSKU R57-22244
Designed for compatible CNC routers and routing equipment using precision 1/4-inch collets or approved toolholding assemblies.
Main Product Description
The Royce Ayr 2-Flute Downcut Spiral Router Bit R57-22244 is part of the R57-222/322 downcut spiral family. It is designed for routing solid wood, wood composites, laminated panels, and selected plastics, using downcut geometry that directs cutting pressure toward the workpiece surface.
The 0.1563-inch cutting diameter and 0.625-inch cutting length support smaller grooves, dados, profiles, and detailed routing passes. The downcut action helps control top-surface chipping in laminated, composite, and finished materials where upper-edge quality is a priority.
The 0.250-inch shank and compact 2.000-inch overall length suit compatible CNC routers and routing equipment. Correct collet condition, minimum practical projection, verified runout, suitable spindle direction, RPM, feed rate, cutting depth, workholding, and chip evacuation are essential for maintaining finish quality and tool life.
Technical Specifications
Downcut Spiral Bit R57-22244
- Royce Ayr
- 2-Flute Downcut Spiral Router Bit
- R57-22244
- R57-222/322 Downcut Spiral 2 Flute
- Solid Carbide CNC Router Tooling
- 5/32 in / 0.1563 in (3.97 mm)
- 5/8 in / 0.625 in (15.88 mm)
- 1/4 in / 0.250 in (6.35 mm)
- 2 in / 2.000 in (50.8 mm)
- 2
- Not Specified by Supplied Source
- Solid Carbide · Downcut Spiral
- Solid Wood, Wood Composites, Laminated Materials, and Selected Plastics
- CNC Routers and Routing Equipment with Precision 1/4-Inch Collets
Best Fit Applications
Clean Top-Edge Routing
Small Grooves & Dados
Laminated Panel Routing
Cabinet & Millwork Details
Selected Plastic Machining
Product Highlights
Compact 5/32-Inch Diameter
The small cutting diameter and 5/8-inch cutting length support detailed grooves, profiles, and controlled routing passes.
Solid-Carbide Construction
The carbide body supports rigidity, cutting-edge retention, and repeatable dimensions in compatible production applications.
Compatibility & Installation Notes
Confirm that the router, spindle, and toolholder accept an exact 1/4-inch (6.35 mm) shank. Inspect and clean the collet, collet nut, and tool shank, minimize unsupported projection, verify runout, and confirm spindle direction before machining. Match RPM, feed speed, plunge method, and cutting depth to the selected material, and maintain effective chip evacuation because downcut geometry can pack chips in deeper grooves.
Improve Small-Diameter Top-Edge Quality
The Royce Ayr 2-Flute Downcut Spiral Router Bit R57-22244 provides a compact solid-carbide solution for detailed routing in solid wood, wood composites, laminated materials, and selected plastics.
Its 5/32-inch diameter, 5/8-inch cutting length, 1/4-inch shank, and 2-inch overall length support clean top-edge machining when correctly held and operated within suitable cutting parameters.
