Clean Top-Surface Finish
The downcut geometry directs cutting pressure into the material to help reduce upper-edge lifting and surface tear-out.
Royce Ayr 2-Flute Downcut Spiral Router Bit 1/4" (6.35mm) – 1"
CA$999.99
Out of stock
SKU
R57-22214
Product Type
2-Flute Downcut Spiral CNC Router Bit
Series
R57-222/322 Downcut Spiral 2 Flute
Cutting Diameter
1/4 in (6.35 mm)
Cutting Edge
1 in (25.4 mm)
Shank
1/4 in (6.35 mm)
Overall Length
2-1/2 in (63.5 mm)
Flutes
2
Cut Type
Downcut Spiral
Tool Material
Solid Carbide
Application
Wood,Wood Composites,Laminates,Veneers,Plywood,Hardwoods,Softwoods,Some Plastics
2-Flute
Downcut Spiral
Router Bit
Solid-carbide downcut spiral router bit designed for clean top-surface CNC routing in solid wood, wood composites, laminates, veneers, plywood, hardwoods, softwoods, and selected plastics. Its 1/4-inch cutting diameter, 1-inch cutting edge, 1/4-inch shank, and 2-1/2-inch overall length support nested parts, dadoes, grooves, pockets, profiles, and general routing.
D=1/4 in6.35 mm Diameter
CE=1 in25.4 mm Cutting Edge
Sh=1/4 in6.35 mm Shank
OAL=2-1/2 in63.5 mm Overall Length
Downcut Spiral Router Bit
This production tool combines solid-carbide construction, two downcut spiral flutes, and a precision 1/4-inch shank for routing applications where upper-edge quality and controlled cutting pressure are priorities.
Solid Carbide2 FlutesDowncut SpiralSKU R57-22214
Designed for compatible CNC routers and routing equipment using a precision 1/4-inch collet or approved toolholding assembly.
Main Product Description
The Royce Ayr 2-Flute Downcut Spiral Router Bit R57-22214 is designed for CNC routing applications where the top face of the workpiece requires a clean, controlled finish. Its downcut geometry directs cutting pressure into the material, helping reduce upper-edge lifting and surface tear-out during routing.
The 1/4-inch cutting diameter, 1-inch cutting edge, matching 1/4-inch shank, and 2-1/2-inch overall length provide a practical format for cabinet shops, millwork operations, CNC departments, and panel-processing environments producing nested parts, dadoes, grooves, pockets, profiles, and general routed components.
The supplied source identifies solid-carbide construction and lists solid wood, wood composites, laminates, veneers, plywood, hardwoods, softwoods, and some plastics as compatible applications. Rotation, coating, RPM limit, and country of origin are not specified by the supplied source and should be verified before ordering, programming, or production use.
Technical Specifications
Downcut Spiral Bit R57-22214
- Royce Ayr
- 2-Flute Downcut Spiral Router Bit
- R57-22214
- R57-222/322 Downcut Spiral 2 Flute
- Solid Carbide CNC Router Tooling
- 1/4 in (6.35 mm)
- 1 in (25.4 mm)
- 1/4 in (6.35 mm)
- 2-1/2 in (63.5 mm)
- 2
- Not Specified by Supplied Source
- Solid Carbide · Downcut Spiral
- Solid Wood, Wood Composites, Laminates, Veneers, Plywood, Hardwoods, Softwoods, and Selected Plastics
- CNC Routers and Routing Equipment with Compatible 1/4-Inch Collets or Toolholders
Best Fit Applications
Clean Top-Edge CNC Routing
Cabinet & Millwork Parts
Laminates, Veneers & Plywood
Dados, Grooves & Pockets
Wood & Composite Routing
Product Highlights
General 1/4-Inch CNC Utility
The 1/4-inch diameter, 1-inch cutting edge, and matching shank provide a practical format for common CNC routing operations.
Broad Wood-Based Material Range
The supplied data lists solid wood, composites, laminates, veneers, plywood, hardwoods, softwoods, and selected plastics.
Compatibility & Installation Notes
Confirm that the spindle, collet, and toolholder accept an exact 1/4-inch (6.35 mm) shank and provide adequate clearance for the 2-1/2-inch overall length and required projection. Rotation, coating, RPM limit, and country of origin are not specified by the supplied source, so verify those details before ordering, programming, or installation. Inspect and clean the collet, minimize unsupported projection, verify runout, and match spindle speed, feed rate, cut depth, workholding, and dust or chip evacuation to the selected material.
Improve Clean Top-Surface Routing
The Royce Ayr 2-Flute Downcut Spiral Router Bit R57-22214 provides a solid-carbide solution for clean top-surface routing across compatible wood, composite, laminate, veneer, plywood, and selected plastic applications.
Its 1/4-inch cutting diameter, 1-inch cutting edge, matching shank, two-flute downcut geometry, and 2-1/2-inch overall length support practical CNC production when correctly held and operated.
