Royce Ayr 2-Flute Chipbreaker Compression Router Bit — 3/8 in (9.53 mm)
2-Flute Chipbreaker Compression
Router Bit
A solid-carbide, right-hand chipbreaker compression CNC router bit designed for laminated or veneered wood and wood composites where controlled top and bottom edge finish is critical.
Main Product Description
The Royce Ayr R60-11002 is a 2-flute chipbreaker compression router bit from Royce Ayr’s solid carbide CNC tooling range. It is designed for routing laminated or veneered wood and wood composites where both the top and bottom finish matter.
The compression geometry uses upward and downward shearing action to help reduce chipping on laminated surfaces. The chipbreaker design also helps control furring or tearout in plywood cores, making this tool a practical choice for cabinet and casegoods production, nested-based panel work, and CNC routing applications where edge quality and material control are important.
With a 3/8 in (9.53 mm) cutting diameter, 1-1/8 in (28.58 mm) cutting edge, 0.495 in (12.57 mm) upcut length, 3/8 in (9.53 mm) shank, right-hand rotation, and 3 in (76.2 mm) overall length, R60-11002 is suited to CNC router setups that require a smaller-diameter compression chipbreaker tool for veneered, laminated, plywood, or composite panel materials. Confirm the machine, toolholder, RPM, feed rate, cutting depth, and material setup before use.
Best Fit Applications
Product Highlights
Compression Edge Control
The compression cutting action combines upward and downward shear to help reduce chipping on laminated surfaces where both panel faces matter.
Chipbreaker Performance
The chipbreaker design helps control furring or tearout in plywood core materials during cabinet, casegoods, and nested panel production.
Compact 3/8-Inch CNC Tool
The 3/8-inch diameter, 1-1/8-inch cutting edge, 0.495-inch upcut length, and 3/8-inch shank suit CNC setups needing a smaller compression chipbreaker tool.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 3/8-inch (9.53 mm) shank. Verify right-hand rotation, cutting direction, tool projection, available clearance, guarding, dust extraction, RPM, feed speed, pass depth, and hold-down before machining. Material suitability should also be confirmed against the actual laminated, veneered, plywood, or composite panel being cut.
Control Both Panel Faces
The Royce Ayr 2-Flute Chipbreaker Compression Router Bit R60-11002 is built for laminated or veneered wood and wood composites where top and bottom edge finish is critical. Compression cutting action helps reduce surface chipping, while the chipbreaker design supports control of furring and tearout in plywood core materials.
Its 3/8-inch cutting diameter, 1-1/8-inch cutting edge, 0.495-inch upcut length, 3/8-inch shank, right-hand rotation, and 3-inch overall length make it a strong fit for compatible CNC router setups in cabinet, casegoods, and nested-based panel production.
