Royce Ayr 2-Flute Chipbreaker Compression Router Bit — 3/4 in (19.05 mm)
2-Flute Chipbreaker Compression
Router Bit
A heavy-duty solid-carbide, right-hand chipbreaker compression CNC router bit designed for laminated or veneered wood and wood composites where controlled top and bottom edge quality is critical.
Main Product Description
The Royce Ayr R60-11008 is a 2-flute chipbreaker compression router bit from the Royce Ayr solid carbide CNC tooling range. It is designed for routing laminated or veneered wood and wood composites when both the top and bottom finish matter.
The compression geometry combines upward and downward shearing action to help reduce chipping on laminated surfaces, while the chipbreaker design helps prevent furring or tearout in plywood core material. This makes the tool a strong fit for cabinet shops, casegoods manufacturers, and CNC departments cutting laminated panels, veneered panels, plywood, and composite sheet goods.
With a 3/4 in (19.05 mm) cutting diameter, 1-7/8 in (47.63 mm) cutting edge, 0.825 in (20.96 mm) upcut length, 3/4 in (19.05 mm) shank, and 4 in (101.6 mm) overall length, this tool is suited to CNC routing work where a heavy-duty compression bit is required for panel processing, cabinet parts, casegoods components, and laminated sheet goods.
Best Fit Applications
Product Highlights
Compression Edge Quality
The compression geometry combines upward and downward shearing action to help reduce chipping on laminated surfaces where both panel faces matter.
Chipbreaker Core Control
The chipbreaker design helps reduce furring or tearout in plywood core material during CNC panel routing.
Heavy-Duty CNC Tool
The 3/4-inch cutting diameter, 1-7/8-inch cutting edge, 0.824-inch upcut length, and 4-inch overall length suit heavier compression-cutting applications.
Compatibility & Installation Notes
Confirm that the CNC router spindle, collet, and toolholder accept an exact 3/4-inch (19.05 mm) shank. Verify right-hand rotation, cutting direction, tool projection, available clearance, guarding, dust extraction, RPM, feed speed, pass depth, cutting strategy, and part hold-down before machining. Material suitability should be confirmed against the actual panel construction, veneer or laminate surface, plywood core, adhesive content, and finish requirements.
Large-Format Edge Control
The Royce Ayr 2-Flute Chipbreaker Compression Router Bit R60-11008 is built for CNC routing laminated or veneered wood and wood composites where top and bottom edge finish is critical. Compression cutting action helps reduce surface chipping, while the chipbreaker design supports control of furring and tearout in plywood core materials.
Its 3/4-inch cutting diameter, 1-7/8-inch cutting edge, 0.824-inch upcut length, 3/4-inch shank, right-hand rotation, and 4-inch overall length make it a strong fit for compatible CNC router setups requiring a heavy-duty compression tool for cabinet, casegoods, and panel-processing production.
