Single-Flute O-Flute Geometry
The large single-flute chip space supports efficient chip formation and evacuation when routing compatible soft-plastic materials.
Royce Ayr Solid Carbide Up-Cut O-Flute Router Bit - 1/8" Diameter x 1/2" Cut
CA$999.99
In stock
SKU
R63-71706
Product Type
1-Flute "O"Flute Upcut Spiral Bit
Diameter
1/8 in (3.175 mm)
Cutting Edge
1/2 in (12.7 mm)
Shank
1/4 in (6.35 mm)
Overall Length
2 in (50.8 mm)
Cutting Geometry
1 Flute / "O"Style Upcut
Application
Soft Plastics,CNC Routing
Single-Flute O-Flute Upcut
Soft-Plastic Router Bit
O-Flute Soft-Plastic Upcut
Solid-carbide, right-hand O-flute upcut router bit designed for routing soft plastics. Its 1/8-inch cutting diameter, 1/2-inch cutting edge, 1/4-inch shank, and 2-inch overall length combine with single-flute geometry and an upcut form that supports effective chip removal in compatible CNC routing applications.
D=1/8 in3.175 mm Diameter
CE=1/2 in12.7 mm Cutting Edge
Sh=1/4 in6.35 mm Shank
OAL=2 in50.8 mm Overall Length
O-Flute Soft-Plastic Upcut
This single-flute solid-carbide tool uses O-flute cutting geometry and a right-hand upcut design to support clean chip evacuation while routing compatible soft-plastic materials.
Solid Carbide / HW1 FluteRight-Hand UpcutSKU R63-71706
Designed for compatible CNC routers using a precision 1/4-inch (6.35 mm) collet or approved toolholding system with sufficient clearance for the 2-inch overall length.
Main Product Description
The Royce Ayr Single-Flute O-Flute Soft-Plastic Upcut Router Bit R63-71706 is engineered for routing soft plastics in compatible CNC systems. Its 0.1250-inch cutting diameter and 0.500-inch cutting edge provide a compact configuration for profiling, slotting, trimming, and controlled material removal in sign-making and clad-panel applications.
The single-flute O-flute geometry creates a large chip space, while the upcut form carries chips away from the cutting zone. Royce Ayr identifies this series specifically for soft plastics and notes that the upcut design provides good chip removal.
The 0.250-inch shank and 2.000-inch overall length require a compatible precision collet or approved toolholder. Before production, verify collet condition, runout, right-hand spindle rotation, tool projection, spindle speed, feed rate, depth per pass, workholding, plastic compatibility, and chip extraction.
Technical Specifications
O-Flute Soft-Plastic Upcut R63-71706
- Royce Ayr
- Single-Flute O-Flute Soft-Plastic Upcut Router Bit
- R63-71706
- O-Flute Soft Plastic Upcut
- HW / Solid Carbide
- 0.1250 in / 1/8 in (3.175 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 0.250 in / 1/4 in (6.35 mm)
- 2.000 in / 2 in (50.8 mm)
- 1
- O-Flute Upcut
- RH / Right Hand
- Material Compatibility: Soft Plastics · Primary Industry: Sign Making & Clad Paneling · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 1/4-inch (6.35 mm) collet or approved toolholding system with sufficient clearance for the 2-inch overall length.
Best Fit Applications
Soft-Plastic Profiling
Sign-Making Components
Clad-Panel Routing
Plastic Slotting
CNC Plastic Trimming
Product Highlights
Upcut Chip Removal
The right-hand upcut design carries chips away from the cutting zone to support cleaner routing and reduce chip recutting.
Compact 1/4-Inch Shank Format
The 1/4-inch shank, 1/8-inch cutting diameter, and 2-inch overall length suit detailed CNC plastic-routing operations.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 1/4-inch (6.35 mm) shank and provides sufficient clearance for the 2-inch (50.8 mm) overall length. Inspect the collet and nut, minimize unsupported tool projection, verify right-hand rotation and runout, and establish spindle speed, feed rate, depth per pass, workholding, plastic compatibility, and chip extraction according to the machine and approved shop procedures.
Improve Soft-Plastic Chip Control
The Royce Ayr Single-Flute O-Flute Soft-Plastic Upcut Router Bit R63-71706 provides a solid-carbide solution for routing soft plastics. Its 1/8-inch diameter, 1/2-inch cutting edge, 1/4-inch shank, single-flute geometry, and 2-inch overall length support profiling, slotting, trimming, and production routing.
O-flute cutting geometry and an upcut form support effective chip removal when the tool is correctly held and operated within suitable plastic-machining parameters.
