Ballnose Carving Geometry
The rounded cutting profile supports smooth contour transitions and sculpted three-dimensional surface machining.
Royce Ayr 1/2" Diameter x 1" Cut 2-Flute Straight Carbide Router Bit
CA$999.99
Out of stock
SKU
R52-33417
Product Type
2 Flute Straight General Purpose Router Bit
Diameter
1/2 in (12.7 mm)
Cutting Edge
1 in (25.4 mm)
Shank
1/2 in (12.7 mm)
Overall Length
3 in (76.2 mm)
Rotation
Right-Hand (RH)
Cutting Geometry
2 Flutes / Straight Flute
Construction
Solid Carbide Tooling Category
Application
Solid Wood Routing,MDF Routing,Slotting,Dadoing
2-Flute Upcut Ballnose
Router Bit
Upcut Ballnose Router Bit
General-purpose solid-carbide upcut ballnose router bit for solid wood and wood composites. Its 3/4-inch cutting diameter, 3-1/2-inch cutting edge, 3/4-inch shank, 4-1/2-inch b1 dimension, and 6-inch overall length support deep carving, contouring, profiling, and sculpted CNC machining.
D=3/4 in19.05 mm Diameter
CE=3-1/2 in88.9 mm Cutting Edge
Sh=3/4 in19.05 mm Shank
OAL=6 in152.4 mm Overall Length
Upcut Ballnose Router Bit
This long-reach production tool combines a solid-carbide body, two right-hand upcut flutes, and a ballnose cutting profile for carving, contouring, and deep three-dimensional routing.
Solid Carbide2 FlutesRH UpcutSKU R52-33417
Designed for compatible CNC routers and industrial spindle systems using precision 3/4-inch collets or approved toolholding assemblies.
Main Product Description
The Royce Ayr 2-Flute General-Purpose Upcut Ballnose Router Bit R52-33417 is engineered for carving and contouring solid wood and wood composites. Its 0.7500-inch cutting diameter and 3.500-inch cutting edge provide extended machining reach for sculpted surfaces, deep profiles, and three-dimensional CNC components.
The ballnose tip supports smooth radius transitions and flowing surface geometry, while the right-hand upcut spiral moves chips away from the cutting zone. Two cutting flutes distribute the machining load and support stable chip formation in properly configured CNC routing systems.
The 0.750-inch shank, 4.500-inch b1 dimension, and 6.000-inch overall length require precise toolholding and conservative setup. Correct collet condition, minimum practical projection, verified runout, suitable spindle speed, feed rate, and depth-per-pass are essential for controlling deflection, heat, and surface quality.
Technical Specifications
Upcut Ballnose R52-33417
- Royce Ayr
- 2-Flute General-Purpose Upcut Ballnose Router Bit
- R52-33417
- General-Purpose Upcut Ballnose
- 0.7500 in / 3/4 in (19.05 mm)
- 3.500 in / 3-1/2 in (88.9 mm)
- 4.500 in / 4-1/2 in (114.3 mm)
- 0.750 in / 3/4 in (19.05 mm)
- 6.000 in / 6 in (152.4 mm)
- 2
- Upcut Spiral Ballnose
- RH / Right Hand
- Coating: None · Cutting Material: HW / Solid Carbide · Material Compatibility: Solid Wood and Wood Composites · Machine Interface: CNC Routers with Precision 3/4-Inch Collets
- Designed for compatible CNC routers and industrial spindle systems using precision 3/4-inch collets or approved toolholding assemblies.
Best Fit Applications
3D CNC Carving
Deep Contour Routing
Sculpted Wood Components
Radius Profile Machining
Architectural Millwork
Product Highlights
Efficient Upcut Chip Flow
Right-hand upcut flutes move chips away from deep cutting zones to reduce recutting during carving and profiling passes.
Extended Solid-Carbide Reach
The 6-inch overall length and 3-1/2-inch cutting edge provide reach for demanding deep-profile CNC applications.
Compatibility & Installation Notes
Confirm that the spindle and toolholder accept an exact 3/4-inch (19.05 mm) shank. Because this tool has a 6-inch overall length and extended cutting edge, minimize unsupported projection and verify that the machine, spindle, collet, workholding, and programmed engagement are suitable. Inspect and clean all toolholding surfaces, verify runout, and establish spindle speed, feed rate, stepover, and depth-per-pass according to the material and machine conditions.
Expand Deep-Carving Capability
The Royce Ayr 2-Flute General-Purpose Upcut Ballnose Router Bit R52-33417 provides an extended-reach solid-carbide solution for carved furniture parts, architectural millwork, moulds, patterns, and sculpted wood components.
Its 3/4-inch diameter, 3-1/2-inch cutting edge, 3/4-inch shank, and 6-inch overall length support deep contour machining when the tool is correctly held and operated within suitable cutting parameters.
