Top-Surface Downcut Action
Downcut geometry directs cutting force toward the work surface to support cleaner top edges in laminated and veneered materials.
Royce Ayr Solid Carbide 4-Flute Downcut 1/2"
CA$999.99
Out of stock
SKU
R60-71102
Product Type
4 Flute Down Cut Solid Carbide Router Bit
Diameter
1/2 in (12.7 mm)
Cutting Edge
1-5/8 in (41.3 mm)
Shank
1/2 in (12.7 mm)
Overall Length
4 in (101.6 mm)
Flutes
4 Flute Down Cut
Construction
Premium Solid Carbide
Quadruple-Flute Combination Downcut
Router Bit
Combination Downcut Router Bit
Solid-carbide, right-hand combination downcut router bit engineered for laminated or veneered wood and wood composites where top-surface finish is critical. Its 1/2-inch cutting diameter, 1-5/8-inch cutting edge, 1/2-inch shank, four-flute geometry, and 4-inch overall length support high-quality production routing with a combined roughing and finishing action.
D=1/2 in12.7 mm Diameter
CE=1-5/8 in41.275 mm Cutting Edge
Sh=1/2 in12.7 mm Shank
OAL=4 in101.6 mm Overall Length
Combination Downcut Router Bit
This four-flute solid-carbide tool combines roughing and finishing geometry with downcut action to support cleaner top surfaces in laminated or veneered wood and compatible wood-composite materials.
Solid Carbide / HW4 FlutesCombination DowncutSKU R60-71102
Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system with sufficient clearance for the 4-inch overall length.
Main Product Description
The Royce Ayr Quadruple-Flute Combination Downcut Router Bit R60-71102 is designed for routing laminated or veneered wood and wood composites when top-surface finish is critical. Its downcut action directs cutting force toward the work surface, helping control top-edge breakout during compatible profiling, sizing, and production-routing operations.
The four-flute combination geometry integrates roughing and finishing action in one tool. This configuration is intended to support faster production feed rates while maintaining a refined top finish, provided the machine, workholding, spindle power, and cutting parameters are suitable for the application.
The 0.5000-inch cutting diameter, 1.625-inch cutting edge, 0.500-inch shank, and 4.000-inch overall length require a compatible precision collet or approved toolholder. Before machining, verify collet condition, runout, right-hand spindle rotation, tool projection, spindle speed, feed rate, depth per pass, workholding, and chip extraction.
Technical Specifications
Combination Downcut R60-71102
- Royce Ayr
- Quadruple-Flute Combination Downcut Router Bit
- R60-71102
- Quadruple Flute Combination Downcut
- HW / Solid Carbide
- 0.5000 in / 1/2 in (12.7 mm)
- 1.625 in / 1-5/8 in (41.275 mm)
- 0.500 in / 1/2 in (12.7 mm)
- 4.000 in / 4 in (101.6 mm)
- 4
- Combination Downcut Rougher / Finisher
- RH / Right Hand
- Construction: Solid Carbide · Material Compatibility: Laminated or Veneered Wood and Wood Composites · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 1/2-inch (12.7 mm) collet or approved toolholding system with sufficient clearance for the 4-inch overall length.
Best Fit Applications
Laminated Panel Routing
Veneered Wood Profiling
Top-Finish-Critical Cuts
Wood-Composite Sizing
Production CNC Routing
Product Highlights
Combined Roughing and Finishing
The four-flute combination design integrates roughing and finishing action in one tool for efficient production machining.
Production-Ready Tool Format
The 1/2-inch diameter and shank, 1-5/8-inch cutting edge, and 4-inch overall length suit compatible industrial CNC routing systems.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 1/2-inch (12.7 mm) shank and provides sufficient clearance for the 4-inch (101.6 mm) overall length. Inspect the collet and nut, minimize unsupported tool projection, verify right-hand rotation and runout, and establish spindle speed, feed rate, depth per pass, workholding, and chip extraction for the laminated, veneered, or composite material being machined.
Improve Top-Surface Finish in Production Routing
The Royce Ayr Quadruple-Flute Combination Downcut Router Bit R60-71102 provides a four-flute solid-carbide solution for routing laminated or veneered wood and wood composites where the visible top surface requires controlled edge quality.
Its combination rougher-finisher geometry and downcut action support productive CNC machining when the tool is correctly held and operated within suitable feed, speed, workholding, and chip-extraction parameters.
