Downcut Material Control
The downcut design directs cutting force toward the work surface to assist material hold-down during compatible routing operations.
Royce Ayr Solid Carbide Downcut "O" Flute Router Bit - 1/4" Diameter x 3/4" Cut
CA$999.99
Out of stock
SKU
R62-71505
Product Type
1-Flute "O"Flute Downcut Spiral Bit
Diameter
1/4 in (6.35 mm)
Cutting Edge
3/4 in (19.05 mm)
Shank
1/4 in (6.35 mm)
Cutting Geometry
1 Flute / "O"Style Downcut
Application
Soft Plastics,CNC Nesting,Material Hold-Down
Single-Flute O-Flute Downcut
Soft-Plastic Router Bit
O-Flute Soft-Plastic Downcut
Solid-carbide O-flute downcut router bit designed for routing soft plastics. Its 1/4-inch cutting diameter, 3/4-inch cutting edge, 1/4-inch shank, and 2-1/2-inch overall length provide a balanced format for profiling, slotting, trimming, and CNC nesting applications where downward cutting force can assist material hold-down.
D=1/4 in6.35 mm Diameter
CE=3/4 in19.05 mm Cutting Edge
Sh=1/4 in6.35 mm Shank
OAL=2-1/2 in63.5 mm Overall Length
O-Flute Soft-Plastic Downcut
This single-flute solid-carbide tool uses polished O-flute geometry and a downcut design to support controlled chip formation while applying downward cutting force to compatible soft-plastic materials.
Solid Carbide1 FluteO-Flute DowncutSKU R62-71505
Designed for compatible CNC routers using a precision 1/4-inch (6.35 mm) collet or approved toolholding system with sufficient clearance for the 2-1/2-inch overall length.
Main Product Description
The Royce Ayr Single-Flute O-Flute Soft-Plastic Downcut Router Bit R62-71505 is engineered for routing soft plastics in compatible CNC systems. Its 0.250-inch cutting diameter and 0.750-inch cutting edge provide a practical configuration for profiling, slotting, trimming, nesting, and controlled material removal in suitable plastic applications.
The single-flute O-flute geometry provides generous chip space, while the downcut form directs cutting force toward the work surface to assist material hold-down. This can improve workpiece stability during routing when the tool is used with suitable feeds, speeds, workholding, and chip extraction.
The 0.250-inch shank and 2.500-inch overall length require a compatible precision collet or approved toolholder. Before production, verify collet condition, runout, tool projection, spindle speed, feed rate, depth per pass, workholding, plastic compatibility, and chip extraction.
Technical Specifications
O-Flute Soft-Plastic Downcut R62-71505
- Royce Ayr
- Single-Flute O-Flute Soft-Plastic Downcut Router Bit
- R62-71505
- 1 Flute Downcut O Style Soft Plastic
- Solid Carbide
- 0.250 in / 1/4 in (6.35 mm)
- 0.750 in / 3/4 in (19.05 mm)
- 0.250 in / 1/4 in (6.35 mm)
- 2.500 in / 2-1/2 in (63.5 mm)
- 1
- O-Flute Downcut
- Solid Micro-Grain Carbide
- Material Compatibility: Soft Plastics · Machine Type: Compatible CNC Router
- Designed for compatible CNC routers using a precision 1/4-inch (6.35 mm) collet or approved toolholding system with sufficient clearance for the 2-1/2-inch overall length.
Best Fit Applications
Soft-Plastic Profiling
Plastic Sheet Routing
Nested Plastic Parts
Component Trimming
CNC Plastic Slotting
Product Highlights
Single-Flute O-Flute Geometry
The large flute space supports controlled chip formation while routing suitable soft-plastic materials.
Balanced 1/4-Inch Tool Format
The 1/4-inch diameter and shank with a 3/4-inch cutting edge suit profiling, slotting, trimming, and nesting work.
Compatibility & Installation Notes
Confirm that the CNC router spindle or toolholder accepts an exact 1/4-inch (6.35 mm) shank and provides sufficient clearance for the 2-1/2-inch (63.5 mm) overall length. Inspect the collet and nut, minimize unsupported tool projection, verify runout, and establish spindle speed, feed rate, depth per pass, workholding, soft-plastic compatibility, and chip extraction according to the machine and approved shop procedures.
Improve Soft-Plastic Material Control
The Royce Ayr Single-Flute O-Flute Soft-Plastic Downcut Router Bit R62-71505 provides a solid-carbide solution for routing soft plastics. Its 1/4-inch diameter, 3/4-inch cutting edge, 1/4-inch shank, single-flute geometry, and 2-1/2-inch overall length support profiling, slotting, trimming, nesting, and production routing.
The downcut design assists material hold-down when the tool is correctly held and operated within suitable soft-plastic machining parameters.
