8 kg Lined A8 Tank
The A8 feeder combines a coated iron pressure vessel, full inner plastic lining, and chromed brass lid with 8 kg / 1.5 gal capacity.
Pizzi Glue Feed System with Nozzle
CA$999.99
Out of stock
SKU
9001
Product Type
Pressurized PVA glue feed system
Product Family
A8 range
Tank Construction
Coated iron with full plastic lining
Glue Capacity
8 kg / 1.5 gal
Maximum Pressure
5 bar / 75 psi
Included Applicator
1 × standard 0002 glue gun
Included Nozzle
1 × universal pointed,1.5 mm
Glue Feed System
With Glue Gun & Universal Nozzle
Pressurized PVA Glue Feeder
Pizzi code 9001 is an A8 pressurized PVA glue-feed system with an 8 kg lined iron tank, one standard 0002 applicator gun, and one universal pointed nozzle for controlled manual glue delivery.
9001Exact Product Code
8 kg / 1.5 galGlue Capacity
5 bar / 75 psiMaximum Pressure
1 × 0002Standard Glue Gun
Pressurized PVA Glue Feeder
A single-applicator A8 system with a coated iron tank, full inner plastic lining, chromed brass lid, straight-grip glue gun, hose, and universal pointed nozzle.
PizziA8 Range1 Applicator GunCode 9001
Designed for PVA adhesives with recommended Brookfield viscosity from 3,000 to 15,000 mPa·s at 20°C / 68°F.
Main Product Description
Pizzi code 9001 is the single-gun configuration of the A8 pressurized glue-feeder range for professional PVA adhesive application.
The coated iron tank has a full inner plastic lining and chromed brass lid, holds 8 kg / 1.5 gal of glue, and operates at a maximum pressure of 5 bar / 75 psi.
The system includes one standard straight-grip 0002 glue gun with adjustable flow, one universal pointed nozzle, and the connected delivery hose. Other interchangeable Pizzi nozzles can be fitted for application-specific work.
Technical Specifications
A8 Range · Product Code 9001
- Pizzi
- Pressurized PVA Glue Feed System
- 9001
- A8 Range
- Coated Iron with Full Plastic Lining
- Chromed Brass
- 8 kg / 1.5 gal
- 5 bar / 75 psi
- 1 × Standard 0002
- 1 × Universal Pointed, 1.5 mm
- 3,000–15,000 mPa·s at 20°C / 68°F
- 9001
- Single-Operator Glue Application · Cabinet and Furniture Assembly · Dowel and Mortise Gluing
- Designed for PVA adhesives with recommended Brookfield viscosity from 3,000 to 15,000 mPa·s at 20°C / 68°F.
Best Fit Applications
Single-Operator Glue Application
Cabinet and Furniture Assembly
Dowel and Mortise Gluing
Edge, Groove, and Surface Gluing
Custom Interchangeable Nozzle Work
Product Highlights
Single Applicator Configuration
One standard 0002 glue gun provides controlled adhesive delivery from a dedicated A8 feeder connection.
Universal Nozzle Included
The applicator is configured with a universal pointed 1.5 mm nozzle, with other Pizzi nozzles available for specialized tasks.
Compatibility & Installation Notes
Use code 9001 with PVA adhesives within the published 5 bar / 75 psi maximum pressure and recommended viscosity range. Follow Pizzi operating and depressurization guidance. The trolley, alternate nozzles, compressed-air supply, and adhesive are not represented as included.
Controlled Glue Delivery from One A8 Feeder
Pizzi code 9001 combines an 8 kg lined iron pressure tank with one standard glue gun and universal pointed nozzle.
The single-applicator layout supports efficient, controlled PVA glue delivery across varied woodworking and assembly tasks.
