Dual Dosing Adjustment
Independent glue-flow and dispensing-time controls support constant, repeatable adhesive quantities.
Pizzi Glue Feed System with Metered Delivery
CA$999.99
Out of stock
SKU
0165
Product Type
Pressurized metered glue-dosing system
Construction
Entirely stainless steel
Tank Capacity
12 kg
Maximum Pressure
5 bar
Glue Gun
1 gun with anatomic grip
Dosing Control
Glue flow and dispensing time
Adhesive Range
PVA only · 3,000–15,000 mPa·s at 20°C
Glue Feed System with Metered Delivery
Pizzi easyAPP · Complete Code 0165 System
Pressurized Metered System
Pizzi easyAPP code 0165 is a stainless-steel pressurized system for metered PVA glue dosing. Its dual-adjustment control regulates glue flow and dispensing time for repeatable application through one anatomic-grip gun.
0165Exact Product Code
12 kgTank Capacity
5 barMaximum Pressure
PVAAdhesive Type
Pressurized Metered System
A complete stainless-steel PVA glue-feed system with a 12 kg tank and one anatomic-grip metered-delivery gun.
PizzieasyAPP12 kg TankCode 0165
Intended for controlled PVA dosing in repetitive assembly work. Flow and dispensing time are independently adjustable.
Main Product Description
Pizzi easyAPP code 0165 is a pressurized glue-feed system engineered for metered PVA adhesive dosing. The complete system is made entirely of stainless steel and uses a 12 kg-capacity tank.
Glue quantity is managed through two adjustment functions: glue-flow regulation and dispensing-time control. Together they support constant, repeatable dosing during production and assembly work.
The system includes one glue gun with an anatomic grip and dual-function glue application. Its Pizzi nozzle interface supports application-specific attachments for holes, slots, tenons, mortises, dowels, and related joinery.
Technical Specifications
easyAPP Metered Glue Feed System · Product Code 0165
- Pizzi
- Pressurized Metered Glue-Dosing System
- 0165
- Metered PVA Glue Application
- Pizzi easyAPP
- Entirely Stainless Steel
- 12 kg
- 5 bar
- 1
- Anatomic Grip
- Glue Flow and Dispensing Time
- PVA Adhesives Only
- Recommended Viscosity: 3,000–15,000 mPa·s Brookfield · Reference Temperature: 20°C (68°F)
- Intended for controlled PVA dosing in repetitive assembly work. Flow and dispensing time are independently adjustable.
Best Fit Applications
Dowel and Hole Dosing
Slot Glue Application
Tenon and Mortise Gluing
Repeatable Batch Dosing
Furniture and Joinery Assembly
Product Highlights
Stainless-Steel System
The complete pressure system is made entirely of stainless steel for professional production use.
Anatomic-Grip Glue Gun
One dual-function glue gun with an anatomic grip provides controlled hand placement at the workpiece.
Compatibility & Installation Notes
Confirm exact code 0165 before ordering. This system is specified for PVA adhesives only, with a recommended Brookfield viscosity of 3,000–15,000 mPa·s at 20°C (68°F). Maximum operating pressure is 5 bar. Verify the required application nozzle, pneumatic supply, installation accessories, and adhesive separately; do not assume accessories shown in contextual imagery are included unless stated in the quotation.
Controlled PVA Delivery for Repeatable Assembly Work
Pizzi easyAPP code 0165 combines a 12 kg stainless-steel pressure tank, metering controls, and one anatomic-grip glue gun in a complete PVA dosing system.
Adjustable glue flow and dispensing time help standardize adhesive quantity across dowels, holes, slots, tenons, mortises, and other repeatable gluing tasks.
