8 kg Lined A8 Tank
The A8 feeder combines a coated iron pressure vessel, full inner plastic lining, and chromed brass lid with 8 kg / 1.5 gal capacity.
Pizzi Glue Feed System with 2 Nozzles
CA$999.99
Out of stock
SKU
9002
Product Type
Pressurized PVA glue feed system
Product Family
A8 range
Tank Construction
Coated iron with full plastic lining
Glue Capacity
8 kg / 1.5 gal
Maximum Pressure
5 bar / 75 psi
Included Applicators
2 × standard 0002 glue guns
Included Nozzles
2 × universal pointed,1.5 mm
Glue Feed System
With 2 Guns & Universal Nozzles
Pressurized PVA Glue Feeder
Pizzi code 9002 is an A8 pressurized PVA glue-feed system with an 8 kg lined iron tank, two standard 0002 applicator guns, and two universal pointed nozzles for controlled manual glue delivery.
9002Exact Product Code
8 kg / 1.5 galGlue Capacity
5 bar / 75 psiMaximum Pressure
2 × 0002Standard Glue Guns
Pressurized PVA Glue Feeder
A two-operator A8 system with a coated iron tank, full inner plastic lining, chromed brass lid, two straight-grip glue guns, hoses, and universal pointed nozzles.
PizziA8 Range2 Applicator GunsCode 9002
Designed for PVA adhesives with recommended Brookfield viscosity from 3,000 to 15,000 mPa·s at 20°C / 68°F.
Main Product Description
Pizzi code 9002 is the two-gun configuration of the A8 pressurized glue-feeder range for professional PVA adhesive application.
The coated iron tank has a full inner plastic lining and chromed brass lid, holds 8 kg / 1.5 gal of glue, and operates at a maximum pressure of 5 bar / 75 psi.
The system includes two standard straight-grip 0002 glue guns with adjustable flow, two universal pointed nozzles, and the connected delivery hoses. Other interchangeable Pizzi nozzles can be fitted for application-specific work.
Technical Specifications
A8 Range · Product Code 9002
- Pizzi
- Pressurized PVA Glue Feed System
- 9002
- A8 Range
- Coated Iron with Full Plastic Lining
- Chromed Brass
- 8 kg / 1.5 gal
- 5 bar / 75 psi
- 2 × Standard 0002
- 2 × Universal Pointed, 1.5 mm
- 3,000–15,000 mPa·s at 20°C / 68°F
- 9002
- Two-Operator Glue Application · Cabinet and Furniture Assembly · Dowel and Mortise Gluing
- Designed for PVA adhesives with recommended Brookfield viscosity from 3,000 to 15,000 mPa·s at 20°C / 68°F.
Best Fit Applications
Two-Operator Glue Application
Cabinet and Furniture Assembly
Dowel and Mortise Gluing
Edge, Groove, and Surface Gluing
Custom Interchangeable Nozzle Work
Product Highlights
Dual Applicator Configuration
Two standard 0002 glue guns allow two work positions or two application setups to operate from the same feeder.
Universal Nozzles Included
Each applicator is configured with a universal pointed 1.5 mm nozzle, with other Pizzi nozzles available for specialized tasks.
Compatibility & Installation Notes
Use code 9002 with PVA adhesives within the published 5 bar / 75 psi maximum pressure and recommended viscosity range. Follow Pizzi operating and depressurization guidance. The trolley, alternate nozzles, compressed-air supply, and adhesive are not represented as included.
Two Glue Stations from One A8 Feeder
Pizzi code 9002 combines an 8 kg lined iron pressure tank with two standard glue guns and universal pointed nozzles.
The dual-applicator layout supports efficient, controlled PVA glue delivery across varied woodworking and assembly tasks.
