12 kg Stainless-Steel Tank
The A12 feeder combines professional stainless-steel construction with 12 kg / 2.5 gal of PVA glue capacity.
Pizzi Glue Feed System with 1 Nozzle
CA$999.99
Out of stock
SKU
9012
Product Type
Pressurized PVA glue feed system
Product Family
A12 range
Tank Construction
Stainless steel
Glue Capacity
12 kg / 2.5 gal
Maximum Pressure
5 bar / 75 psi
Included Applicator
1 × standard 0002 glue gun
Included Nozzle
1 × universal pointed,1.5 mm
Glue Feed System
With 1 Gun & Universal Nozzle
Pressurized PVA Glue Feeder
Pizzi code 9012 is an A12 pressurized PVA glue-feed system with a 12 kg stainless-steel tank, one standard 0002 applicator gun, and one universal pointed nozzle for controlled manual glue delivery.
9012Exact Product Code
12 kg / 2.5 galGlue Capacity
5 bar / 75 psiMaximum Pressure
1 × 0002Standard Glue Guns
Pressurized PVA Glue Feeder
A single-applicator A12 system with a stainless-steel tank, one straight-grip glue gun, hose, and universal pointed nozzle.
PizziA12 Range1 Applicator GunCode 9012
Designed for PVA adhesives with recommended Brookfield viscosity from 3,000 to 15,000 mPa·s at 20°C / 68°F.
Main Product Description
Pizzi code 9012 is the single-gun configuration of the A12 pressurized glue-feeder range for professional PVA adhesive application.
The stainless-steel tank holds 12 kg / 2.5 gal of glue and operates at a maximum pressure of 5 bar / 75 psi for steady extrusion through both applicators.
The system includes one standard straight-grip 0002 glue gun with adjustable flow, one universal pointed nozzle, and the connected delivery hose. Other interchangeable Pizzi nozzles can be fitted for application-specific work.
Technical Specifications
A12 Range · Product Code 9012
- Pizzi
- Pressurized PVA Glue Feed System
- 9012
- A12 Range
- Stainless Steel
- 12 kg / 2.5 gal
- 5 bar / 75 psi
- 1 × Standard 0002
- 1 × Universal Pointed, 1.5 mm
- 3,000–15,000 mPa·s at 20°C / 68°F
- 9012
- 12 kg / 2.5 gal
- Single-Operator Glue Application · Cabinet and Furniture Assembly · Dowel and Mortise Gluing
- Designed for PVA adhesives with recommended Brookfield viscosity from 3,000 to 15,000 mPa·s at 20°C / 68°F.
Best Fit Applications
Single-Operator Glue Application
Cabinet and Furniture Assembly
Dowel and Mortise Gluing
Edge, Groove, and Surface Gluing
Custom Interchangeable Nozzle Work
Product Highlights
Single Applicator Configuration
One standard 0002 glue gun provides controlled adhesive delivery from a dedicated A12 feeder connection.
Universal Nozzle Included
The applicator is configured with a universal pointed 1.5 mm nozzle, with other Pizzi nozzles available for specialized tasks.
Compatibility & Installation Notes
Use code 9012 with PVA adhesives within the published 5 bar / 75 psi maximum pressure and recommended viscosity range. Follow Pizzi operating and depressurization guidance. The trolley, alternate nozzles, compressed-air supply, and adhesive are not represented as included.
Controlled Glue Delivery from One A12 Feeder
Pizzi code 9012 combines a 12 kg stainless-steel pressure tank with one standard glue gun and universal pointed nozzle.
The single-applicator layout supports efficient, controlled PVA glue delivery across varied woodworking and assembly tasks.
