Aero-Acoustically Tuned
Engineered body geometry helps reduce cutting noise while improving chip movement and dust-extraction performance.
Leitz Whispercut Pro PCD Jointing Cutter Head D70x48x30 Z2+2
CA$999.99
Out of stock
SKU
L192222
Brand
Leitz Tooling Systems
Product Series
Whispercut Pro Diamond Jointing
Article Number
L192222
Diameter (D)
70 mm
Cutting Length (CE)
48 mm
Bore Diameter (d)
30 mm + 2 Keyways
Cutting Geometry
Z2 + Z2 Dual-Wing Axial Shear
Cutting Material
Premium Polycrystalline Diamond (PCD)
WhisperCut Pro Jointing Head
Leitz
Industrial Tooling Systems
Industrial polycrystalline diamond jointing head engineered for high-throughput edgebanding and pre-milling. Aero-acoustic body geometry, axial-shear cutting action, and a Z2+2 configuration support quiet operation, clean panel edges, and extended service intervals.
D=70 mmCutting Diameter
CE=48 mmCutting Length
d=30 mm + 2KWBore / Keyways
Z2 + 2Cutting Configuration
WhisperCut Pro Jointing Head
This monoblock industrial cutterhead combines PCD cutting edges with controlled shear geometry and aero-acoustic body design for clean, low-noise panel jointing.
PCD Cutting EdgesZ2 + 2 Geometry30 mm + 2 KeywaysSKU L192222
Designed for compatible edgebanders and industrial pre-milling or jointing aggregates using a 30 mm bore with dual-keyway drive engagement.
Main Product Description
The Leitz WhisperCut Pro PCD Jointing Head L192222 is engineered for premium edgebanding and pre-milling operations where clean, straight panel edges are essential. Its 70 mm cutting diameter, 48 mm cutting length, and Z2+2 PCD configuration support accurate jointing across abrasive board materials including MDF, HDF, and melamine-faced panels.
The monoblock steel body uses structured aero-acoustic geometry to reduce operational noise while managing chip and dust movement through the cutting zone. Controlled axial-shear action helps minimize tear-out on upper and lower panel surfaces, supporting a consistent edge before adhesive and edgeband application.
A 30 mm bore with two keyways provides positive drive engagement in compatible industrial aggregates. The balanced body and resharpenable PCD cutting design are intended for continuous production environments where reduced vibration, predictable finish quality, and multiple service cycles improve tooling efficiency.
Technical Specifications
WhisperCut Pro L192222
- Leitz Tooling Systems
- WhisperCut Pro Jointing Head
- L192222
- Industrial Tooling Systems
- Polycrystalline Diamond (PCD)
- 70 mm
- 48 mm
- 30 mm + 2 Keyways
- Z2 + 2
- Pre-Milling / Jointing
- Balanced Monoblock Steel Body
- Axial-Shear PCD Jointing Configuration
- Service Design: Resharpenable Multi-Stage PCD Tooling
- Designed for compatible edgebanders and industrial pre-milling or jointing aggregates using a 30 mm bore with dual-keyway drive engagement.
Best Fit Applications
Industrial Edgebanding Lines
Pre-Milling Aggregates
Abrasive Laminated Panels
MDF and HDF Jointing
High-Speed Panel Profiling
Product Highlights
High-Shear PCD Geometry
The Z2+2 diamond configuration applies controlled axial shear to produce clean panel edges with reduced tear-out.
Resharpenable Design
The PCD cutting system is built for multiple professional service cycles in high-production manufacturing environments.
Compatibility & Installation Notes
Confirm that the machine aggregate accepts a 70 mm jointing head with a 30 mm bore and two-keyway drive pattern. Ensure both keyways are fully seated before tightening, verify the approved rotation direction and manufacturer spindle-speed limit, and inspect the PCD cutting edges for wear or material buildup before production. Power down and lock out the machine during installation, removal, or servicing.
Improve Edgebanding Edge Preparation
The Leitz WhisperCut Pro PCD Jointing Head L192222 is designed for industrial edgebanding lines that require smooth, consistent panel edges before adhesive and edgeband application. Its 70 mm diameter, 48 mm cutting length, Z2+2 geometry, and 30 mm dual-keyway bore support stable production on compatible pre-milling and jointing aggregates.
Combining aero-acoustic body engineering, polycrystalline diamond cutting edges, and a balanced monoblock construction, this tool helps reduce noise, vibration, edge defects, and service interruptions during high-throughput panel processing.
