Uniform Thermal Clamping
Controlled shrink-fit contraction applies continuous radial grip around a compatible 20 mm h6 cylindrical tool shank.
Leitz Premium Shrink Fit Chuck HSK63F d20 A=75 L100
CA$999.99
Out of stock
SKU
L37710
Product Type
Premium Thermo Shrink Fit Chuck
Clamping Diameter
20 mm
Gauge Length (A)
75 mm
Body Length (L)
100 mm
Shank Interface
HSK 63F
Balancing Quality
G2.5 at 24,000 RPM premium tolerance
Application
High-speed CNC routing,heavy-duty milling,precision nesting,solid wood and composite machining
Leitz Shrink Fit
Chuck HSK63F
Thermo Shrink Fit Chuck
Precision thermal shrink-fit toolholder engineered for rigid clamping, controlled concentricity, and stable high-speed CNC machining. Its 20 mm clamping bore, 75 mm gauge length, 100 mm body length, and HSK63F spindle interface support accurate retention of compatible cylindrical tooling shanks.
d=20 mmClamping Bore
A=75 mmGauge Length
L=100 mmBody Length
HSK63FSpindle Connection
Thermo Shrink Fit Chuck
This monoblock hot-work-steel toolholder uses controlled thermal expansion and contraction to clamp compatible 20 mm h6 cylindrical tool shanks with high rigidity and low runout.
Hot-Work Steel20 mm BoreG2.5 BalancedSKU L37710
Designed for compatible industrial CNC machining centers with HSK63F spindle receivers and approved induction-heating equipment for thermal tool insertion and removal.
Main Product Description
The Leitz HSK63F Shrink Fit Chuck L37710 is developed for CNC machining centers requiring a rigid, concentric connection between the spindle and cutting tool. Inductive heating expands the 20 mm clamping bore for tool insertion; controlled cooling then creates uniform radial clamping around a compatible h6 cylindrical shank.
The toolholder combines a 75 mm gauge length with a 100 mm body length to provide useful reach while maintaining a slim external profile for machining clearance. Its monoblock premium hot-work-steel construction helps control vibration and supports stable retention during high-speed routing, profiling, nesting, and edge-machining operations.
The supplied specifications identify runout accuracy of less than or equal to 0.003 mm and fine balancing to G2.5 at 24,000 RPM parameters. When installed and maintained correctly, this configuration supports precise use of compatible 20 mm solid-carbide or PCD tooling shanks while helping protect cutting edges, spindle bearings, and finished-part quality.
Technical Specifications
Shrink Fit Chuck L37710
- Leitz
- Premium Thermo Shrink Fit Chuck
- L37710
- Precision CNC Toolholders / Clamping Systems
- 20 mm
- 75 mm
- 100 mm
- HSK63F
- High-Stress-Resistance Premium-Grade Hot-Work Steel
- Less Than or Equal to 0.003 mm Runout Accuracy
- Fine-Balanced G2.5 at 24,000 RPM Parameters
- Industrial CNC Machining Units Matching HSK63F Receivers
- Shank Suitability: 20 mm h6-Tolerance Cylindrical Solid-Carbide / PCD Tooling Shanks
- Designed for compatible industrial CNC machining centers with HSK63F spindle receivers and approved induction-heating equipment for thermal tool insertion and removal.
Best Fit Applications
High-Speed CNC Nesting
Heavy-Duty Wood Milling
Precision Profile Finishing
PCD Tooling Retention
Multi-Axis CNC Machining
Product Highlights
Low-Runout Toolholding
The monoblock HSK63F construction supports concentric tool retention and helps reduce vibration at high spindle speed.
Slimline Machining Access
The 75 mm gauge projection and streamlined body improve clearance for deeper profiles and complex CNC toolpaths.
Compatibility & Installation Notes
Use only with compatible HSK63F spindle receivers, approved 20 mm h6 cylindrical tool shanks, and a dedicated induction-heating system suitable for steel shrink-fit chucks. Operators must be trained in thermal clamping procedures. Keep the HSK contact faces and clamping bore clean, follow the specified heating and cooling cycle, and verify tool seating, balance, runout, and machine-speed limits before operation.
Strengthen the Spindle-to-Tool Interface
The Leitz HSK63F Shrink Fit Chuck L37710 provides a rigid thermal-clamping interface for precision CNC production. Its 20 mm bore, 75 mm gauge length, 100 mm body length, and HSK63F spindle connection support compatible solid-carbide and PCD tooling used in demanding routing and profiling applications.
Premium hot-work-steel construction, low-runout retention, and G2.5 balancing help improve cutting stability, surface quality, and tooling performance when the chuck is heated, installed, cooled, and maintained according to approved operating procedures.
