Leitz QuattroForm Profile Cutter D70x6.8x16 Z3 R3/1.3/2/F45deg
QuattroForm Profile Cutter
High-performance carbide profiling tool engineered for precision edge shaping and repeatable multi-radius geometry. Its Z3 cutting configuration supports stable high-RPM machining, consistent profile quality, and dependable service life in industrial wood and MDF processing.
Main Product Description
The Leitz QuattroForm Profile Cutter L193903 is designed for demanding edge-profiling applications in solid wood and wood-based panels. Its 70 mm diameter, 6.8 mm cutting width, 16 mm bore, and Z3 tooth arrangement support controlled cutting action and stable profile formation across repeated production cycles.
The multi-radius profile geometry identified as R3 / 1.3 / 2 / F45° enables manufacturers to reproduce a defined compound contour consistently across solid wood, MDF, and furniture components. This geometry is suited to applications where dimensional repeatability and visual uniformity are critical across large batch runs.
A robust steel body and premium-grade carbide cutting edges support wear resistance, vibration control, and dependable surface quality at production spindle speeds. Correct toolholding, spindle-speed selection, feed programming, and regular edge inspection help preserve profile integrity and extend service intervals.
Best Fit Applications
Product Highlights
Defined Multi-Radius Profile
The R3 / 1.3 / 2 / F45° geometry reproduces a compound edge contour with consistent dimensional accuracy.
Stable Z3 Cutting Action
Three cutting edges distribute the machining load to support smooth cutting and repeatable surface quality in production use.
Carbide Wear Resistance
Premium carbide cutting edges help maintain profile definition when machining solid wood and abrasive engineered panels.
Compatibility & Installation Notes
Confirm that the machine spindle, arbor, and guarding accept a 70 mm profile cutter with a 16 mm bore. Verify the approved rotation direction, spindle-speed range, feed rate, and projection before operation. Ensure the cutter is fully seated and secured, and inspect the carbide cutting edges for wear, chipping, or resin buildup before each production run.
Maintain Consistent Profile Geometry
The Leitz QuattroForm Profile Cutter L193903 is built for manufacturers requiring repeatable edge geometry across solid wood, MDF, and furniture components. Its 70 mm diameter, 6.8 mm width, 16 mm bore, and Z3 cutting arrangement support stable production profiling on compatible machinery.
Combining a defined multi-radius contour, rigid steel body, and carbide cutting edges, this cutter helps preserve finish quality, dimensional consistency, and production efficiency across repeated profiling cycles.
