Adjustable Conical Kerf
The conical tooth profile supports continuous scoring-width adjustment from 4.8 mm to 5.6 mm through controlled aggregate-depth changes.
Leitz Premium Conical Scoring Saw Blade 180mm x 4.8-5.6mm x 45mm x 36-Tooth
CA$999.99
In stock
SKU
L165634
Product Type
Premium Conical Scoring Saw Blade
Diameter
180 mm
Kerf Range
4.8 - 5.6 mm
Bore Size
45 mm
Tooth Count
36T
Tooth Geometry
KON (Conical)
Construction
Premium Sub-Micron Grade Carbide
Application
Chip-Free Scoring of Double-Sided Melamine,Laminates,HPL,and Veneered Panels
Leitz Conical Scoring Saw
Blade
Conical Scoring Saw
Premium carbide-tipped conical scoring saw blade engineered to create a controlled counter-rotational score ahead of the primary sizing cut. Designed to reduce exit-face blowout and edge chipping on double-sided laminates, melamine, and veneered panels.
D=180 mmBlade Diameter
K=4.8–5.6 mmKerf Range
B=45 mmBore Size
Z=36TTooth Count
Conical Scoring Saw
This heavy-duty scoring blade uses conical tooth geometry and premium sub-micron carbide tips to maintain stable, controlled scoring paths during continuous automated panel sizing.
Sub-Micron CarbideKON Geometry4.8–5.6 mm KerfSKU L165634
Designed for compatible automated panel-sizing equipment and industrial beam saws using a 180 mm scoring blade, 45 mm bore, and depth-adjustable conical scoring aggregate.
Main Product Description
The Leitz Premium Conical Scoring Saw Blade L165634 is engineered for integration into heavy production lines, beam saws, and automated industrial panel-sizing systems. Operating ahead of the main sizing blade, the scoring tool creates a precise pre-cut that helps protect fragile surface coatings from exit-face chipping and cosmetic damage.
Built with a 180 mm diameter, adjustable 4.8 mm to 5.6 mm kerf range, 45 mm industrial bore, 3.5 mm plate-body thickness, and 36 precisely pitched teeth, the blade supports controlled scoring-width adjustment through aggregate spindle depth. This conical configuration reduces the setup time associated with split scoring systems that require shims or component changes.
Laser-cut expansion slots help manage thermal deformation and acoustic resonance during continuous production. Premium sub-micron carbide tips provide resistance to abrasive panel binders, dense adhesive layers, and coated surfaces, supporting predictable scoring geometry and extended intervals between regrinding cycles.
Technical Specifications
Conical Scoring Saw L165634
- Leitz
- Premium Conical Scoring Saw Blade
- L165634
- Conical Industrial Scoring
- 180 mm
- 4.8 mm – 5.6 mm
- 45 mm
- 36 Teeth (36T)
- KON / Conical Configuration
- 3.5 mm
- Premium Sub-Micron Grade Carbide
- Automated Panel-Sizing Equipment and Industrial Beam Saws
- Manufacturing Origin: Germany
- Designed for compatible automated panel-sizing equipment and industrial beam saws using a 180 mm scoring blade, 45 mm bore, and depth-adjustable conical scoring aggregate.
Best Fit Applications
Industrial Beam Saws
Double-Sided Melamine
High-Pressure Laminates
Veneered MDF Processing
Automated Panel Plants
Product Highlights
Vibration-Controlled Plate
Precision balancing and laser-cut expansion slots help limit heat distortion, resonance, and tracking movement under sustained spindle loads.
Premium Resin Resistance
Sub-micron carbide tips resist abrasive binders, dense adhesive layers, and coated panel surfaces during repeated industrial scoring cycles.
Compatibility & Installation Notes
Confirm that the scoring aggregate accepts a 180 mm blade with a 45 mm bore and supports the required 4.8 mm to 5.6 mm scoring-width range. Adjust aggregate depth so the scoring path matches or slightly exceeds the main saw kerf. Verify mounting surfaces, rotation direction, spindle-speed limits, flange condition, guards, and machine interlocks before operation.
Preserve Premium Panel Edges
The Leitz Premium Conical Scoring Saw Blade L165634 is built for commercial panel lines that require predictable scoring width and clean lower-face edges. Its 180 mm diameter, 36-tooth layout, 45 mm bore, and adjustable conical kerf support accurate processing of melamine, HPL, and veneered engineered panels.
Combining premium sub-micron carbide, a 3.5 mm tensioned plate body, and depth-adjustable KON geometry, this scoring blade helps reduce chip-out, setup interruptions, and finishing rework on compatible beam-saw and automated panel-sizing systems.
