Advanced PCD Cutting Edges
Polycrystalline diamond provides high abrasion resistance and helps preserve cutting geometry during prolonged composite-panel production.
Leitz Diamaster Pro Diamond Router Bit - D8xCE22xSk12x40xZ2 Right-Hand
CA$999.99
Out of stock
SKU
L191089
Brand
Leitz Tooling Systems
Product Type
Diamaster Pro PCD Diamond Router Bit
Article Number
L191089
Cutting Diameter
8 mm
Cutting Edge (CE)
22 mm
Shank Dimension
12 mm x 40 mm
Rotation
Right-Hand (RH)
Cutting Geometry
Z2 Polycrystalline Diamond (PCD)
Applications
High-speed sizing,nesting,and routing of abrasive composite panels
Diamaster Pro
PCD
Router Bit
High-performance polycrystalline diamond router bit engineered for high-speed sizing, nesting, and routing in abrasive composite panel materials. Designed for precision CNC machinery requiring long service intervals and consistently clean machined edges.
D=8 mmCutting Diameter
CE=22 mmCutting Edge
Sk=12 x 40 mmShank Specification
Z2 RHGeometry / Rotation
Diamaster Pro PCD Router Bit
This industrial CNC router tool uses polycrystalline diamond cutting edges and a rigid steel body to support clean, repeatable processing of abrasive engineered panels.
PCD Cutting EdgesZ2 GeometryRight-Hand RotationSKU L191089
Designed for compatible CNC routers and machining centers using a 12 mm cylindrical shank, precision collet, or approved chuck-adaptor system.
Main Product Description
The Leitz Diamaster Pro PCD Router Bit L191089 is engineered for industrial panel processing where abrasive substrates rapidly wear conventional cutting materials. Its polycrystalline diamond cutting edges provide strong abrasion resistance and support extended service intervals during demanding CNC sizing, nesting, and routing operations.
Featuring an 8 mm cutting diameter, 22 mm cutting-edge length, and a 12 mm diameter by 40 mm long cylindrical shank, the tool combines compact cutting geometry with rigid spindle engagement. The precision-formed shank supports low runout when installed in a clean, correctly sized collet or compatible chuck-adaptor system.
The Z2 continuous or segmented cutting arrangement and right-hand rotation support controlled chip evacuation across a range of feed conditions. The dense tool-steel body helps limit vibration under cutting load, making the tool well suited to nested manufacturing, automated jointing cuts, panel sizing, and other high-wear CNC production tasks.
Technical Specifications
Diamaster Pro L191089
- Leitz Tooling Systems
- Diamaster Pro PCD Router Bit
- L191089
- Diamaster Pro
- Polycrystalline Diamond (PCD)
- 8 mm
- 22 mm
- 12 mm Diameter x 40 mm Length
- G2.5 Optimized for High-Speed Spindles
- Z2 Continuous / Segmented Array
- RH / Right-Hand
- Premium Heavy-Density Tool Steel
- MDF and HDF Panel Nesting, Laminated Particleboard Sizing, High-Pressure Laminates, Solid-Surface Milling, Multi-Ply Plywood Routing
- CNC Routers, Machining Centers, Chuck Adaptors
Best Fit Applications
MDF and HDF Panel Nesting
Laminated Particleboard Sizing
High-Pressure Laminates
Solid-Surface Milling
Multi-Ply Plywood Routing
Product Highlights
Vibration-Damped Steel Core
The dense tool-steel body helps reduce micro-vibration under chip load, protecting edge integrity and supporting consistent finish quality.
Precision-Formed Shank
The accurately manufactured 12 mm cylindrical shank supports low runout and balanced radial-force transfer into compatible toolholders.
Compatibility & Installation Notes
Confirm that the CNC spindle and toolholding system accept a 12 mm metric shank before installation. Verify right-hand rotation, permissible spindle speed, feed rate, and chip-load settings against the machine, toolholder, and material requirements. Ensure workpieces are securely held and keep the PCD cutting edges clear of screws, metal fixtures, alignment pins, and other impact hazards.
Extend High-Wear CNC Production
The Leitz Diamaster Pro PCD Router Bit L191089 is built for industrial furniture production and commercial millwork operations that process abrasive composite panels. Its 8 mm cutting diameter, 22 mm cutting-edge length, Z2 geometry, and 12 x 40 mm shank support accurate CNC sizing and routing across repeated production cycles.
Combining polycrystalline diamond cutting edges with a rigid, vibration-resistant steel body, this tool helps reduce replacement frequency, preserve edge quality, and maintain predictable output on compatible CNC routers and machining centers.
