PCD Wear Resistance
Polycrystalline diamond cutting edges resist abrasive composite cores and help maintain stable geometry across extended production runs.
Leitz Diamaster Pro Diamond Shank Cutter D14xCE16xSh20xOAL50 2-Tooth Right-Hand
CA$999.99
Out of stock
SKU
L191093
Product Type
Polycrystalline Diamond (PCD) Shank Cutter
Diameter
14 mm
Cutting Edge (CE)
16 mm
Shank (Sk)
20 mm
Overall Length (OAL)
50 mm
Rotation
Right-Hand (RH)
Flute Geometry
Z2 (2 Continuous PCD Flutes)
Construction
Premium Density Polycrystalline Diamond Tips / High-Tensile Steel Body
Application
High-volume nesting,jointing,and sizing of MDF,particleboard,and laminated panel products.
Diamaster Pro
PCD
Shank Cutter
High-performance industrial polycrystalline diamond shank cutter with optimized axial-shear geometry. Engineered for extended service life and clean edge quality during demanding CNC sizing, jointing, and nesting operations in abrasive composite wood materials.
D=14 mmCutting Diameter
CE=16 mmCutting Edge
Sk=20 mmShank Diameter
OAL=50 mmOverall Length
Diamaster Pro PCD Cutter
This industrial CNC cutter combines polycrystalline diamond cutting edges with a rigid high-tensile steel body for stable, repeatable machining of abrasive engineered panels.
PCD Cutting EdgesZ2 GeometryRight-Hand RotationSKU L191093
Designed for compatible CNC routers and machining centers using a precise 20 mm cylindrical shank with approved heavy-duty collet, hydraulic-chuck, or shrink-fit toolholding.
Main Product Description
The Leitz Diamaster Pro PCD Shank Cutter L191093 is engineered for high-capacity industrial manufacturing where abrasive engineered wood products rapidly wear conventional cutting materials. Its polycrystalline diamond cutting edges support long production intervals and stable edge geometry during demanding CNC sizing, nesting, and jointing operations.
Built with a 14 mm cutting diameter, 16 mm cutting-edge height, 20 mm straight shank, and 50 mm overall length, the tool provides a rigid working profile for high-load machining. The high-tensile premium matrix-steel body helps limit resonance and deflection while maintaining accurate engagement in compatible heavy-duty toolholders.
The Z2 right-hand cutting configuration uses optimized shear and clearance angles to improve chip flow and reduce edge damage on coated and fibrous panel surfaces. This geometry is well suited to nested-base manufacturing, automated panel sizing, and precision routing in MDF, HPL, particleboard, and multi-ply veneer plywood.
Technical Specifications
Diamaster Pro L191093
- Leitz
- Diamaster Pro PCD Cutter
- L191093
- Diamaster Pro
- Polycrystalline Diamond (PCD)
- 14 mm
- 16 mm
- 20 mm
- 50 mm
- Z2
- RH (Right Hand)
- High-Tensile Premium Matrix Steel
- CNC Nesting and Panel Sizing, Medium-Density Fiberboard, High-Pressure Laminates, Raw and Melamine Particleboard, Multi-Ply Veneer Plywood
- Designed for compatible CNC routers and machining centers using a precise 20 mm cylindrical shank with approved heavy-duty collet, hydraulic-chuck, or shrink-fit toolholding.
Best Fit Applications
CNC Nesting and Panel Sizing
Medium-Density Fiberboard
High-Pressure Laminates
Raw and Melamine Particleboard
Multi-Ply Veneer Plywood
Product Highlights
Heavy-Duty Shank Stability
The 20 mm shank and compact 50 mm overall length help reduce deflection while transferring spindle power efficiently into the cut.
Optimized Chip Flow
Advanced gullet and shear geometry support rapid chip evacuation, helping reduce recutting and heat exposure on decorative surfaces.
Compatibility & Installation Notes
Confirm that the CNC spindle and toolholding system accept a clean, precise 20 mm shank before installation. Verify right-hand rotation, maximum spindle speed, feed rate, axial pass depth, workpiece hold-down, vacuum clamping, and dust extraction against machine and material requirements. Protect the PCD cutting edges from screws, clamps, steel alignment pins, and other impact hazards.
Strengthen High-Load CNC Production
The Leitz Diamaster Pro PCD Shank Cutter L191093 is designed for industrial furniture production and commercial millwork operations processing abrasive composite panels. Its 14 mm cutting diameter, 16 mm cutting-edge height, Z2 geometry, 20 mm shank, and 50 mm overall length support stable sizing and routing across repeated CNC cycles.
Combining polycrystalline diamond cutting edges with a rigid, high-tensile steel body, this cutter helps reduce tool-change frequency, preserve edge quality, and maintain predictable output on compatible CNC routers and machining centers.
