Leitz Diamaster Pro PCD Shank Cutter D10xCE22xSh12xOAL40 Z2 RH
Diamaster Pro PCD Shank
Cutter
High-performance industrial polycrystalline diamond shank cutter with optimized axial-shear geometry. Engineered for long service intervals and clean edge quality during demanding CNC sizing, jointing, and nesting operations in abrasive composite wood materials.
Main Product Description
The Leitz Diamaster Pro PCD Shank Cutter L191090 is engineered for high-capacity industrial manufacturing where abrasive engineered wood products rapidly wear conventional cutting materials. Its polycrystalline diamond cutting edges support extended service intervals and stable cutting geometry during demanding CNC sizing, nesting, and jointing operations.
Built with a 10 mm cutting diameter, 22 mm cutting-edge height, 12 mm straight shank, and 40 mm overall length, the tool combines a compact working profile with rigid spindle engagement. The high-tensile premium matrix-steel body helps limit resonance and deflection while supporting accurate cutting under sustained production loads.
The Z2 right-hand cutting configuration uses optimized shear and clearance angles to improve chip flow and reduce edge damage on coated and fibrous panel surfaces. This geometry is well suited to nested-base manufacturing, automated panel sizing, and precision routing in MDF, HPL, particleboard, and multi-ply veneer plywood.
Best Fit Applications
Product Highlights
PCD Wear Resistance
Polycrystalline diamond cutting edges resist abrasive composite cores and help maintain stable cutting geometry across long production runs.
Compact, Rigid Profile
The 10 mm diameter and 40 mm overall length help limit deflection while transferring spindle energy efficiently into the cut.
Optimized Chip Flow
Advanced gullet and shear geometry support rapid chip evacuation, helping reduce recutting and heat exposure on decorative surfaces.
Compatibility & Installation Notes
Confirm that the CNC spindle and toolholding system accept a clean, precise 12 mm shank before installation. Verify right-hand rotation, maximum spindle speed, feed rate, axial pass depth, workpiece hold-down, and dust extraction against machine and material requirements. Protect the PCD cutting edges from screws, clamps, steel alignment pins, and other impact hazards.
Extend High-Wear CNC Production
The Leitz Diamaster Pro PCD Shank Cutter L191090 is designed for industrial furniture production and commercial millwork operations processing abrasive composite panels. Its 10 mm cutting diameter, 22 mm cutting-edge height, Z2 geometry, 12 mm shank, and 40 mm overall length support accurate sizing and routing across repeated CNC cycles.
Combining polycrystalline diamond cutting edges with a compact, high-tensile steel body, this cutter helps reduce tool-change frequency, preserve edge quality, and maintain predictable output on compatible CNC routers and machining centers.
