Upcut Chip Evacuation
The right-hand upcut spiral moves chips upward and is designed to support an excellent finish on the bottom face of compatible routed material.
Klein KleinDIA® 3-Tooth Upcut Solid Carbide Spiral Router Bit, 20mm Diameter x 75mm Cutting Length
CA$999.99
Out of stock
SKU
T344.201.RKD
Product Type
Z3 Upcut Solid-Carbide Finish/Roughing Spiral Router Bit
Family
Klein T344.KD
Cutting Geometry
Upcut spiral · Semi-finished chip-breaker · Right-hand rotation
Cutting Diameter
20 mm
Cutting Length
75 mm
Shank / Overall
20 mm shank · 130 mm overall length
Cutting Material
Solid carbide with KleinDIA® DLC anti-friction coating
Machine Fit
CNC machining centres,CNC routers,and point-to-point machines
Applications
Hardwood,softwood,MDF/HDF,chipboard,plywood,laminates,plastic-coated and mineral materials
Z3 Upcut
Finish/Roughing Router Bit
Solid-Carbide Upcut Spiral
A Klein T344.KD solid-carbide spiral router bit with a 20 mm cutting diameter, 75 mm cutting length, 20 mm shank, 130 mm overall length, three cutting edges, right-hand rotation, semi-finished chip-breaker geometry, and KleinDIA® DLC anti-friction coating for compatible CNC routing applications.
20 mmCutting Diameter (D)
75 mmCutting Length (B)
20 mmShank Diameter (S)
Z3Upcut · RH Rotation
Solid-Carbide Upcut Spiral
The T344.KD family combines right-hand upcut geometry, a semi-finished chip-breaker execution, polished cutting edges, and KleinDIA® coating for compatible CNC finish-and-roughing work.
Solid CarbideUpcut Z3KleinDIA®SKU T344.201.RKD
For compatible CNC machining centres, CNC routers, and point-to-point machines using a clean 20 mm toolholding system. Confirm right-hand rotation, projection, spindle condition, retaining-ring arrangement, RPM, feed, chip extraction, and workholding before production use.
Main Product Description
Klein T344.201.RKD is the exact 20 mm variant in the T344.KD KleinDIA® family of solid-carbide finish/roughing spiral router bits. The official Item row specifies a 20 mm cutting diameter, 75 mm cutting length, 130 mm overall length, 20 mm shank, three cutting edges, and right-hand rotation.
The right-hand upcut spiral carries chips upward and is intended to support an excellent finish on the bottom face of compatible workpieces. Its semi-finished chip-breaker execution bridges finishing and roughing duties for CNC machining centres, CNC routers, and point-to-point machines.
KleinDIA® is a diamond-like-carbon anti-friction coating applied over the solid-carbide tool. The official family data identifies reduced friction, lower heat and wear, improved chip evacuation, and greater wear resistance. Supported workpiece groups include hardwood, softwood, MDF/HDF, chipboard, plywood, laminated and paper-coated panels, plastic-coated materials, and mineral materials such as Corian®.
Technical Specifications
Family T344.KD · SKU T344.201.RKD
- Klein
- Solid-Carbide Finish/Roughing Spiral Router Bit
- T344.201.RKD
- SISTEMI CNC Solid-Carbide Tooling
- T344.KD
- Upcut
- 20 mm
- 75 mm
- 130 mm
- 20 mm
- 3
- Right-Hand (RH)
- Edge Execution: Semi-Finished Chip-Breaker · Active Cutting Material: Solid Carbide · Coating: KleinDIA® DLC Anti-Friction Coating · Coating Thickness: Approximately 1 Micron · Shank Feature: Seat for Seeger Retaining Ring · Machine Type: CNC Machining Centres / CNC Routers / Point-to-Point Machines
- For compatible CNC machining centres, CNC routers, and point-to-point machines using a clean 20 mm toolholding system. Confirm right-hand rotation, projection, spindle condition, retaining-ring arrangement, RPM, feed, chip extraction, and workholding before production use.
Best Fit Applications
CNC Finish / Roughing Operations
MDF / HDF & Chipboard
Plywood & Laminated Panels
Hardwood & Softwood
Corian® & Plastic-Coated Materials
Product Highlights
Semi-Finished Chip-Breaker
The verified semi-finished chip-breaker execution supports a practical balance between material removal and finish quality in compatible CNC work.
KleinDIA® DLC Coating
The anti-friction DLC coating is specified to reduce friction, heat, and wear while supporting smoother chip evacuation over the solid-carbide tool.
Compatibility & Installation Notes
Confirm the exact T344.201.RKD Item code rather than the family code T344.KD. Use a clean, compatible holder or collet for the 20 mm shank and verify right-hand spindle rotation, safe projection, retaining-ring arrangement, machine RPM limits, feed, cut depth, entry strategy, dust and chip extraction, workholding, and material support. The official family specifies a Seeger retaining-ring seat on diameters from 12 mm through 20 mm.
Coated Finish/Roughing Performance
Klein T344.201.RKD combines a 20 mm cutting diameter, 75 mm cutting length, 20 mm shank, 130 mm overall length, Z3 upcut geometry, semi-finished chip-breaking, and KleinDIA® coating for compatible CNC routing work.
Correct holder fit, spindle condition, projection, right-hand rotation, feed, RPM, extraction, toolpath, and workholding are essential to achieving the intended bottom-face finish and tool performance.
