Four Reversible Cutting Edges
The verified insert format provides four cutting edges with two fixing holes for secure positioning in a compatible tool body.
Klein KleinDIA® Four-Edge Reversible Carbide Insert, 30 x 12 x 1.5mm
CA$999.99
In stock
SKU
Z055.329.NKD
Product Type
Four-Edge Reversible Carbide Insert
Family
Klein Z055.KD
Nominal Size
30 x 12 x 1.5 mm
Official Dimensions
29.5 mm length · 12 mm width · 1.5 mm thickness
Edge Geometry
Four reversible cutting edges · 35° edge angle
Fixing Pattern
Two fixing holes · 14 mm centre spacing
Carbide Grade
HC05 HW carbide
Coating
KleinDIA® DLC anti-friction coating · Approximately 1 micron
Applications
MDF/HDF,plywood,chipboard,hardwood,and softwood
Four-Edge
KleinDIA® Insert
HW Reversible Insert
A Klein Z055.KD four-edge reversible HW carbide insert with KleinDIA® DLC anti-friction coating. Item Z055.329.NKD has a nominal 30 x 12 x 1.5 mm format, an official total length of 29.5 mm, two fixing holes on 14 mm centres, a 35° edge angle, and HC05 carbide grade.
29.5 mmOfficial Length (L)
12 mmInsert Width (B)
1.5 mmThickness (C)
4Cutting Edges
HW Reversible Insert
The Z055.KD family combines a four-edge reversible carbide format with a thin KleinDIA® DLC coating developed to reduce friction, abrasion, material adhesion, and heat generation in compatible production applications.
HW CarbideKleinDIA® DLC4 EdgesSKU Z055.329.NKD
Replacement insert only. Match the exact 29.5 x 12 x 1.5 mm dimensions, 14 mm fixing-hole centres, two-hole layout, 35° edge angle, insert pocket, clamping hardware, and tool-body requirements before installation.
Main Product Description
Klein Z055.329.NKD is one exact Item within the Z055.KD family of KleinDIA®-coated standard reversible HW inserts. The official Item row specifies 29.5 mm total length, 12 mm width, 1.5 mm thickness, 14 mm fixing-hole spacing, a 35° edge angle, two fixing holes, four usable cutting edges, and HC05 carbide grade.
KleinDIA® is a Diamond-Like Carbon anti-friction surface treatment rather than a PCD cutting edge. SISTEMI applies an approximately 1 micron coating at low temperature so the underlying carbide geometry is retained. The coating is specified with high hardness, strong wear resistance, low friction, and low material adhesion to support chip flow, finish quality, and reduced maintenance in suitable production work.
Official application guidance includes MDF/HDF, plywood, softwood, hardwood, and chipboard. The insert must be installed only in a compatible body designed for its exact dimensions, hole spacing, edge geometry, and clamping arrangement. The tool body, screws, and installation hardware are not implied to be included with this replacement insert.
Technical Specifications
Family Z055.KD · SKU Z055.329.NKD
- Klein · KleinDIA®
- Four-Edge Reversible Carbide Insert
- Z055.329.NKD
- SISTEMI KleinDIA® Insert Tooling
- Z055.KD
- 30 x 12 x 1.5 mm
- 29.5 mm official Item-row value
- 12 mm
- 1.5 mm
- 14 mm
- 35°
- 4 reversible edges
- Fixing Holes: 2 · Carbide Grade: HC05 · Active Cutting Material: HW / Tungsten Carbide · Coating: KleinDIA® DLC anti-friction coating · Coating Thickness: Approximately 1 micron · Coating Hardness: HV 0.025: 2500–3100 · Official Materials: MDF/HDF, plywood, softwood, hardwood, chipboard
- Replacement insert only. Match the exact 29.5 x 12 x 1.5 mm dimensions, 14 mm fixing-hole centres, two-hole layout, 35° edge angle, insert pocket, clamping hardware, and tool-body requirements before installation.
Best Fit Applications
MDF / HDF Processing
Plywood Machining
Chipboard Production
Hardwood Processing
Softwood Processing
Product Highlights
KleinDIA® DLC Surface Treatment
The approximately 1 micron anti-friction coating is designed to improve wear resistance, reduce heat and adhesion, and support cleaner chip evacuation.
Exact HC05 Production Format
Item Z055.329.NKD combines HC05 carbide with 29.5 x 12 x 1.5 mm dimensions, 14 mm hole centres, and a 35° edge angle.
Compatibility & Installation Notes
Replacement insert only; the tool body and clamping hardware are sold separately unless a Titan listing explicitly states otherwise. Confirm SKU Z055.329.NKD and match the exact 29.5 x 12 x 1.5 mm dimensions, 14 mm fixing-hole centres, two-hole layout, 35° geometry, insert pocket, screw specification, and body compatibility. Installation, pocket cleaning, insert seating, fastener condition, and tightening must follow the tool-body manufacturer’s procedure; do not substitute a visually similar insert or use damaged clamping components.
Coated Carbide Production Performance
Klein Z055.329.NKD combines a four-edge HC05 carbide insert with a verified 29.5 x 12 x 1.5 mm format, two fixing holes, 14 mm centres, a 35° edge angle, and KleinDIA® DLC coating.
Correct body compatibility, pocket condition, seating, clamping hardware, and installation procedure are essential to achieving the intended finish, chip flow, wear resistance, and service life.
